NUMERICAL STUDY ON THE STABILITY AND CLOSURE POSITION OF VENTAILATED CAVITY WITH A SUPERSONIC TAIL JET

Zhao Xiaoyu; Xiang Min; Zhang Weihua; Liu Bo; Li Shangzhong

doi:10.6052/0459-1879-21-346

Volume 53 Issue 12

Dec. 2021

Turn off MathJax

Article Contents

Abstract

References

Chinese Journal of Theoretical and Applied Mechanics > 2021 > 53(12): 3298-3309. > DOI: 10.6052/0459-1879-21-346 CSTR: 32045.14.0459-1879-21-346

Zhao Xiaoyu, Xiang Min, Zhang Weihua, Liu Bo, Li Shangzhong. Numerical study on the stability and closure position of ventailated cavity with a supersonic tail jet. Chinese Journal of Theoretical and Applied Mechanics, 2021, 53(12): 3298-3309. DOI: 10.6052/0459-1879-21-346

Citation:

PDF (3326 KB)

NUMERICAL STUDY ON THE STABILITY AND CLOSURE POSITION OF VENTAILATED CAVITY WITH A SUPERSONIC TAIL JET

College of Aerospace Science and Engineering, National University of Defense Technology, Changsha 410073, China

Received Date: July 21, 2021
Accepted Date: October 10, 2021
Available Online: October 11, 2021

Graphical Abstract

Abstract

Abstract

For underwater supercavitation vehicles powered by jet propulsion, the stability and morphological control for ventilated cavity are the key issues. In this paper, we use the VOF coupled level set interface tracking method, the compressibility of the gas is considered. By changing jet strength and model length, a series of numerical simulations is studied on the interaction between ventailated cavity and supersonic tail jets, and focused on the stability and closed position of the cavity. The numerical results show that: (1) under the action of the supersonic tail jet, the interface of the ventilated cavity will experience expansion, necking, fracture and retraction, and then begin to periodically oscillate and deflate. The morphological length of the ventilated cavity is greatly reduced compared with that under the condition of no jet. (2) Strong shear on both sides of the gas-liquid interface may induce cavity instability and collapse, and this cavity instability mechanism mainly depends on two dimensionless parameters $\overline J$ (the ratio of jet thrust and cavitator resistance) and $\overline L$ (the ratio of the model length to the diameter of the cavitator). The larger $\overline J$ and the smaller $\overline L$ , the more easily the cavity is destabilized. On this basis, the critical curves for the two states of stability and instability in the calculation examples are further summarized. (3) The more stable the cavity, the lower the amplitude and frequency of the pressure fluctuation at the nozzle outlet. At this time, the ventilated cavity could provide stable ambience for the rocket engine. (4) For the condition of instability cavity, the cavity is closed at the nozzle outlet; while for the stable cavity, the length from the nozzle outlet to the closed position is only related to the parameter $\overline J$ , but not to the model length.
- ventailated cavity,
- tail jet,
- compressible,
- stability,
- numerical study

FullText(HTML)

References (30)

References

[1]	贾有军, 张胜敏, 尤俊峰等. 固体发动机水下点火尾流变化过程试验研究. 固体火箭技术, 2015, 38(5): 660-678 (Jia Youjun, Zhang Shengmin, You Junfeng, et al. Experimental research on the changing process of underwater ignition wake of solid rocket motor. Journal of Solid Rocket Technology, 2015, 38(5): 660-678 (in Chinese)
[2]	张春, 郁伟, 王宝寿. 水下超声速燃气射流的初期流场特性研究. 兵工学报, 2018, 39(5): 961-968 (Zhang Chun, Yu Wei, Wang baoshou. Research on the initial flow field characteristics of underwater supersonic gas jets. Acta Armamentarii, 2018, 39(5): 961-968 (in Chinese) doi: 10.3969/j.issn.1000-1093.2018.05.016
[3]	Olson BJ, Lele SK. A mechanism for unsteady separation in over-expanded nozzle flow. Phys Fluids, 2013, 25(11): 110809 doi: 10.1063/1.4819349
[4]	Shi HH, Guo Q, Wang Chao, et al. Oscillation flow induced by underwater supersonic gas jets. Shock Waves, 2010, 20(4): 347-352 doi: 10.1007/s00193-010-0270-2
[5]	Shi HH, Wang BY, Dai ZQ. Research on the mechanics of underwater supersonic gas jets. Sci. China Phys. Mech. Astron, 2010, 53: 527-535 doi: 10.1007/s11433-010-0150-x
[6]	Han S, Moon K, Ko S, et al. Feasibility study and demonstration of an underwater labscale hybrid rocket propulsion//53rd AIAA/ SAE/ASEE Joint Propulsion Conference. AIAA. Atlanta, 2017
[7]	唐云龙, 李世鹏, 谢侃等. 有相变的水下超音速燃气射流数值模拟. 哈尔滨工程大学学报, 2016, 37(9): 1237-1243 (Tang Yunlong, Li Shipeng, Xie Kan, et al. Numerical simulation of underwater supersonic gas jets with phase transitions. Journal of Harbin Engineering University, 2016, 37(9): 1237-1243 (in Chinese)
[8]	Fronzeo M, Kinzel M. An investigation of gas jets submerged in water//46th AIAA Fluid Dynamics Conference. AIAA, Washington DC , 2016
[9]	许昊, 王聪, 陆宏志等. 水下超声速气体射流诱导尾空泡实验研. 物理学报, 2018, 67: 014703 (Xu Hao, Wang Cong, Lu Hongzhi, et al. Experimental study on submerged supersonic gaseous jet induced tail cavity. Acta Physica Sinica, 2018, 67: 014703 (in Chinese) doi: 10.7498/aps.67.20171617
[10]	Xiang M, Zhao XY, Zhou HC. Transient dynamic analysis for the submerged gas jet in flowing water. European Journal of Mechanics - B/Fluids, 2021, 85: 351-360 doi: 10.1016/j.euromechflu.2020.09.009
[11]	张孝石, 许昊, 王聪等. 水流冲击超声速气体射流实验研究. 物理学报, 2017, 66: 054702 (Zhang Xiaoshi, Xu Hao, Wang Cong, et al. Experimental study on underwater supersonic gas jets in water flow. Acta Physica Sinica, 2017, 66: 054702 (in Chinese) doi: 10.7498/aps.66.054702
[12]	Zhang XY, Li SP, Yang BY, et al. Flow structures of over-expanded supersonic gaseous jets for deep-water propulsio. Ocean Engineering, 2020, 213: 107611 doi: 10.1016/j.oceaneng.2020.107611
[13]	王晓辉, 张珂, 褚学森等. 水下点火推进尾空泡振荡的研究. 船舶力学, 2020, 24(2): 136-144 (Wang Xiaohui, Zhang Ke, Chu Xuesen, et al. Research on the pressure oscillation process of tail bubble of underwater igniting propulsion. Journal of Ship Mechanics, 2020, 24(2): 136-144 (in Chinese) doi: 10.3969/j.issn.1007-7294.2020.02.002
[14]	Paryshev EV. Approximate mathematical models in high-speed hydrodynamics. Journal of Engineering Mathematics, 2006, 55: 41-64 doi: 10.1007/s10665-005-9026-x
[15]	Karlikov V, Reznichenko N, Khomyakov A, et al. A possible mechanism for the emergence of auto-oscillations in developed artificial cavitation flows and immersed gas jets. Fluid Dynamics, 1987, 22(3): 392-398 doi: 10.1007/BF01051919
[16]	Kinzel M, Money M, Krane M, et al. Jet-supercavity interaction: Insights from CFD//Proceedings of the 9th International Symposium on Cavitation (CAV2015), 2015
[17]	Kirschner I, Moeny M, Krane M, et al. Jet-supercavity interaction: insights from physics analysis//Proceedings of the 9th International Symposium on Cavitation (CAV2015), 2015
[18]	Moeny M, Krane M, Kirschner I, et al. Jet-supercavity interaction: insights from experiments//Proceedings of the 9th International Symposium on Cavitation (CAV2015), 2015
[19]	Kinzel M, Krane M, Kirschner I, et al. A numerical assessment of the interaction of a supercavitating flow with a gas jet. Ocean Engineering, 2017, 136: 304-313 doi: 10.1016/j.oceaneng.2017.03.042
[20]	周后村. 多相可压空化流数值模拟方法研究. [博士论文]. 长沙: 国防科技大学, 2019 Zhou Houcun. Numerical simulation method for multiphase compressible cavitating flow. [PhD Thesis]. Changsha: National University of Defense Technology, 2019 (in Chinese)
[21]	Song C. Pulsation of ventilated cavities. Journal Ship Research, 1962, 5(4): 8-20
[22]	Skidmore G, Lindau J, Brungart T, et al. Finite volume, computational fluid dynamics-based investigation of supercavity pulsations. Journal of Fluids Engineering, 2017, 139: 091301 doi: 10.1115/1.4036596
[23]	Bourlioux A. A coupled level-set volume-of-fluid method for tracking material interfaces//Proceedings 6th Annual Int Symp on Comp. Fluid Dynamics, Lake Tahoe, USA, 1995
[24]	Sussman M, Puckett EG. A coupled level set and volume-of-fluid method for computing 3D and axisymmetric incompressible two-phase flows. J. Comput. Phys., 2000, 162: 301-337 doi: 10.1006/jcph.2000.6537
[25]	Owis FM, Nayfeh AH. Computations of the compressible multiphase flow over the cavitating high-speed torpedo. ASME J. Fluids Eng., 2003, 125: 459-468 doi: 10.1115/1.1568358
[26]	Schauer TJ. An experimental study of a ventilated supercavitating vehicle. [Master Thesis]. University of Minnesota, 2003
[27]	Savchenko YN, Savchenko GY. Gas Flows in Ventilated Supercavities. Supercavitation Springer, 2012: 115-126
[28]	Wu Y, Liu Y, Shao SY, et al. On the internal fow of a ventilated supercavity. J. Fluid Mech., 2019, 62: 1135-1165 doi: 10.1017/jfm.2018.1006
[29]	Logvinovich GV. Hydrodynamics of Flows with Free Boundaries. 1969: 128 (in Russian)
[30]	赵承庆, 姜毅. 气体射流动力学. 北京: 北京理工大学出版社, 1988: 114 Zhao Chenqing, Jiang Yi. Gas Jet Dynamics. Beijing: Beijing University of Technology Press, 1998: 114 (in Chinese)
