改进的五阶WENO-Z-格式

骆信; 吴颂平

doi:10.6052/0459-1879-19-249

改进的五阶WENO-Z-格式

doi: 10.6052/0459-1879-19-249

骆信,
吴颂平

北京航空航天大学航空科学与工程学院, 北京 100191

基金项目: 1) 国家自然科学基金资助项目(91530325)

详细信息

通讯作者:
吴颂平

中图分类号: V211.3
计量
- 文章访问数: 1225
- HTML全文浏览量: 129
- PDF下载量: 184
- 被引次数: 0
出版历程
- 收稿日期: 2019-09-04
- 刊出日期: 2019-11-18

AN IMPROVED FIFTH-ORDER WENO-Z+ SCHEME

School of Aeronautic Science and Engineering, Beihang University, Beijing 100191, China

摘要

摘要: WENO-Z$+\!$格式的性能提升依赖于新增项的作用,该项的作用是在WENO-Z格式的基础上进一步增大欠光滑子模板上的权重. 系数$\lambda$被设置用来调控该项的作用, 以避免负耗散. 本文指出了WENO-Z$+\!$格式的缺陷,其所采用$\lambda $的取值方式既不能充分发挥格式的潜力, 也未完全消除负耗散;提出$\lambda $的值应随当地流场数据变化,方能充分发挥新增项在降低数值耗散、提高分辨率上的潜力. 基于此,本文重新设计了$\lambda $的计算公式,该公式能自适应地调控新增项的作用: 只在欠光滑子模板上的权重容易过度增大的地方削弱该项的作用,以避免负耗散; 在其他地方则充分发挥新增项的作用,最大限度增大欠光滑子模板上的权重, 提高格式的分辨率.将使用该系数公式的新格式命名为WENO-Z++, 并对其数值性能进行了系统的研究.理论分析表明, 新格式在间断处具有基本无振荡(essentially non-oscillatory,ENO)特性和更低的数值耗散. 对近似色散关系(approximate dispersion relation,ADR)的研究表明,新格式有效地避免了因过度增大欠光滑子模板上的权重而带来的负耗散,其频谱特性也得到了显著提升.本文还推导了使新格式在极值点处也能保持最优阶的精度的参数设置.一系列求解Euler方程的数值试验表明,新格式的激波捕捉能力和对复杂流场结构的分辨率都显著优于原WENO-Z$+\!$格式.}
- WENO格式 /
- 频谱特性 /
- 高分辨率 /
- 数值耗散 /
- 激波捕捉 /
- 复杂流动
Abstract: The performance improvement of the WENO-Z+ scheme depends on the role of the additional term, which is added to the WENO-Z weights to increase the weights of less-smooth substencils further. Since the additional term may lead to negative dissipation by over increasing the weights of less-smooth substencils in smooth regions, the coefficient $\lambda $ is set to control the role of this term and needs to be carefully determined. In this paper, the defects of the method the WENO-Z+ scheme adopts to determine the value of $\lambda $ are pointed out: It can neither fully utilize the potential of the scheme nor effectively avoid negative dissipation. We propose that to take the full role of the additional term in reducing numerical dissipation and improving resolution ability, the value of $\lambda $ should change with the local data of the flow field. Based on this idea, we design a new calculation formula for $\lambda $, which can adjust the role of the additional term adaptively: Weaken the role of the additional term only where the weights of less-smooth substencils are easy to be excessively increased. The new scheme employing the new $\lambda $ formula is named WENO-Z++, and its numerical performance is systematically analyzed. Theoretical analysis indicates that the new scheme maintains essentially non-oscillatory (ENO) property and has lower numerical dissipation at discontinuities. The investigation of approximate dispersion relation (ADR) shows that the new scheme effectively avoids the negative dissipation caused by excessive increase of the weights of less-smoothed substencils, and its spectral properties are significantly improved. The parameters set that allow the new scheme keeping the optimal order of accuracy at extreme points is deduced. A series of numerical experiments for solving the Euler equations show that both the shock-capturing ability and resolution for complex flow structure of the new scheme are significantly better than those of the original WENO-Z+ scheme.
- WENO scheme /
- spectral property /
- high resolution /
- numerical dissipation /
- shock capturing /
- complex flow

HTML全文

参考文献(1)

1	Fu L, Tang Q. High-order low-dissipation targeted ENO schemes for ideal magnetohydrodynamics. Journal of Scientific Computing, 2019,80:692-716
2	Nonomura T, Fujii K. Characteristic finite-difference WENO scheme for multicomponent compressible fluid analysis: Overestimated quasi-conservative formulation maintaining equilibriums of velocity, pressure, and temperature. Journal of Computational Physics, 2017,340:358-388
3	Huang ZY, Lin G, Ardekani AM. A mixed upwind/central WENO scheme for incompressible two-phase flows. Journal of Computational Physics, 2019,387:455-480
4	Liu HP, Gao ZX, Jiang CW, et al. Numerical study of combustion effects on the development of supersonic turbulent mixing layer flows with WENO schemes. Computers and Fluids, 2019,189:82-93
5	童福林, 李新亮, 唐志共 . 激波与转捩边界层干扰非定常特性数值分析. 力学学报, 2017, 49:(1):93-104
5	( Tong Fulin, Li Xinliang, Tang Zhigong, Numerical analysis of unsteady motion in shock wave/transitional boundary layer interaction. Chinese Journal of Theoretical and Applied Mechanics, 2017,49(1):93-104 (in Chinese))
6	童福林, 李欣, 于长平等. 高超声速激波湍流边界层干扰直接数值模拟研究. 力学学报, 2018,50(2):197-208
6	( Tong Fulin, Li Xin, Yu Changping, et al. Direct numerical simulation of hypersonic shock wave and turbulent boundary layer interactions. Chinese Journal of Theoretical and Applied Mechanics, 2018,50(2):197-208 (in Chinese))
7	洪正, 叶正寅 . 各向同性湍流通过正激波的演化特征研究. 力学学报, 2018,50(6):1356-1367
7	( Hong Zheng, Ye Zhengyin, Study on evolution characteristics of isotropic turbulence passing through a normal shock wave. ChineseJournal of Theoretical and Applied Mechanics, 2018,50(6):1356-1367 (in Chinese))
8	Yu PX, Bai JQ, Yang H, et al. Interface flux reconstruction method based on optimized weight essentially non-oscillatory scheme. Chinese Journal of Aeronautics, 2018,31(5):1020-1029
9	Sirajuddin D, Hitchon WNG. A truly forward semi-Lagrangian WENO scheme for the Vlasov-Poisson system. Journal of Computational Physics, 2019,392:619-665
10	Lefèvre V, Garnica A, Lopez-Pamies O. A WENO finite-difference scheme for a new class of Hamilton-Jacobi equations in nonlinear solid mechanics. Computer Methods in Applied Mechanics and Engineering, 2019,349:17-44
11	Kumar S, Singh P. High order WENO finite volume approximation for population density neuron model. Applied Mathematics and Computation, 2019,356:173-189
12	Wang D, Byambaakhuu T. High-order Lax-Friedrichs WENO fast sweeping methods for the $S_{N}$ neutron transport equation. Nuclear Science and Engineering, 2019,193(9):982-990
13	Harten A, Engquist B, Osher S, et al. Uniformly high order accurate essentially non-oscillatory schemes, III. Journal of Computational Physics, 1987,71(2):231-303
14	Liu XD, Osher S, Chan T. Weighted essentially non-oscillatory schemes. Journal of Computational Physics, 1994,115(1):200-212
15	Jiang GS, Shu CW. Efficient implementation of weighted ENO schemes. Journal of Computational Physics, 1996,126(1):202-228
16	Henrick AK, Aslam TD, Powers JM. Mapped weighted essentially non-oscillatory schemes: Achieving optimal order near critical points. Journal of Computational Physics, 2005,207(2):542-567
17	Borges R, Carmona M, Costa B, et al. An improved weighted essentially non-oscillatory scheme for hyperbolic conservation laws. Journal of Computational Physics, 2008,227(6):3191-3211
18	Ha Y, Kim CH, Lee YJ, et al. An improved weighted essentially non-oscillatory scheme with a new smoothness indicator. Journal of Computational Physics, 2013,232(1):68-86
19	Kim CH, Ha YS, Yoon JH. Modified non-linear weights for fifth-order weighted essentially non-oscillatory schemes. Journal of Scientific Computing, 2016,67:299-323
20	Fan P, Shen YQ, Tian BL, et al. A new smoothness indicator for improving the weighted essentially non-oscillatory scheme. Journal of Computational Physics, 2014,269:329-354
21	Yan ZG, Liu HY, Mao ML, et al. New nonlinear weights for improving accuracy and resolution of weighted compact nonlinear scheme. Computers and Fluids, 2016,127:226-240
22	Yamaleev NK, Carpenter MH. Third-order energy stable WENO scheme. Journal of Computational Physics, 2009,228(8):3025-3047.
23	Yamaleev NK, Carpenter MH. A systematic methodology for constructing high-order energy stable WENO schemes. Journal of Computational Physics, 2009,228(11):4248-4272
24	Baeza A, Bürger R, Mulet P, et al. On the efficient computation of smoothness indicators for a class of WENO reconstructions. Journal of Scientific Computing, 2019,80:1240-1263
25	Bhise AA, Gande NR, Samala R, et al. An efficient hybrid WENO scheme with a problem independent discontinuity locator. International Journal for Numerical Methods in Fluids, 2019,91:1-28
26	Zhang SH, Zhu J, Shu CW. A brief review on the convergence to steady state solutions of Euler equations with high-order WENO schemes. Advances in Aerodynamics, 2019,1:16
27	Aràndiga F, Baeza A, Belda AM, et al. Analysis of WENO schemes for full and global accuracy. SIAM Journal on Numerical Analysis, 2011,49(2):893-915
28	Don WS, Borges R. Accuracy of the weighted essentially non-oscillatory conservative finite difference schemes. Journal of Computational Physics, 2013,250:347-372
29	Acker F, Borges RBDR, Costa B. An improved WENO-Z scheme. Journal of Computational Physics, 2016,313:726-753
30	Borges RBDR. Recent results on the improved WENO-Z+ scheme// Bittencourt ML eds. Lecture Notes in Computational Science and Engineering 119, Spectral and High Order Methods for Partial Differential Equations ICOSAHOM 2016 Rio de Janeiro, Brazil 2016, New York: Springer International Publishing, 2017: 547559
31	Xu WZ, Wu WG. An improved third-order WENO-Z scheme. Journal of Scientific Computing, 2018,75:1808-1841
32	Pirozzoli S. On the spectral properties of shock-capturing schemes. Journal of Computational Physics, 2006,219(2):489-497
33	Shu CW, Osher S. Efficient implementation of essentially non-oscillatory shock-capturing schemes, II. Journal of Computational Physics, 1989,83(1):32-78
34	Titarev VA, Toro EF. Finite-volume WENO schemes for three-dimensional conservation laws. Journal of Computational Physics, 2004,201(1):238-260
35	Lax PD. Weak solutions of nonlinear hyperbolic equations and their numerical computation. Communications on Pure and Applied Mathematics, 1954,7(1):159-193
36	Lax PD, Liu XD. Solution of two-dimensional Riemann problems of gas dynamics by positive schemes. SIAM Journal on Scientific Computing, 1998,19(2):319-340
37	Woodward P, Colella P. The numerical simulation of two-dimensional fluid flow with strong shocks. Journal of Computational Physics, 1984,54(1):115-173
38	Shi J, Zhang YT, Shu CW. Resolution of high order WENO schemes for complicated flow structures. Journal of Computational Physics, 2003,186(2):690-696
