航天器集群编队最优单脉冲机动

王伟; 袁建平; 罗建军

doi:10.6052/0459-1879-14-386

航天器集群编队最优单脉冲机动

王伟^1,2, ,,
袁建平^1,2,
罗建军^1,2

1.
西北工业大学航天学院, 西安710072
2. 航天飞行动力学技术重点实验室, 西安710072

基金项目: 国家自然科学基金资助项目(11072194,11472213).

详细信息

通讯作者:
王伟,博士研究生,主要研究方向:轨道动力学与控制,航天器相对运动.E-mail:418362467@qq.com

中图分类号: V412.4
计量
- 文章访问数: 01102
- HTML全文浏览量: 069
- PDF下载量: 01152
出版历程
- 收稿日期: 2014-12-03
- 修回日期: 2015-07-13
- 刊出日期: 2015-09-17

OPTIMAL SINGLE IMPULSE MANEUVER FOR SPACECRAFT CLUSTER FLIGHT

1.
School of Astronautics, Northwestern Polytechnical University, Xi'an 710072, China
2. National Key Laboratory of Aerospace Flight Dynamics, Xi'an 710072, China

Funds: The project was supported by the National Natural Science Foundation of China (11072194,11472213).

摘要

摘要: 对航天器集群编队最优单脉冲机动问题进行了研究. 针对不同的任务约束,基于非线性相对运动的周期性条件,以解析的思路分别研究了机动时刻给定和机动时刻未定情况下集群编队的最优单脉冲机动问题. 对于机动时刻给定的情况,从高斯变分方程和基于能量匹配条件的拉格朗日乘子法两个角度分别进行了探讨,将问题转化为对一元二次方程求极值或对一个单零点非线性方程求根;对于机动时刻未定的情况,将问题转化为对一个多零点非线性方程求根,通过傅里叶-贝塞尔级数展开可以得到任意高阶近似解. 对于每种情况,推导得到二范数意义下能量最省对应的最优参考长半轴,以及所施加的最优速度脉冲. 数值仿真验证了本文方法的正确性,并对仿真结果进行了解释和分析.
- 集群编队飞行 /
- 单脉冲机动 /
- 周期性条件 /
- 航天器相对运动
Abstract: The optimal single-impulse maneuver for spacecraft cluster flight is studied in this paper. Based on Gauss' variational equations, the optimal conditions and solutions for time-fixed and time-unfixed case are provided via the periodic condition of nonlinear relative motion. For the time-fixed case, the problem is also treated from the perspective of energy matching condition. In this case, the problem is transformed into seeking for the extremum of a quadratic equation or the solution of a single-root algebraic equation, and the optimal semimajor axis is derived, as well as the optimal velocity impulse. For the time-unfixed case, the problem can be solved by numerical algorithms or transformed into pursuing for the solution of a multi-root algebraic equation with the aid of Fourier-Bessel functions. In the end, the proposed method is validated by several carried out illustrating examples.
- cluster flight /
- single impulse maneuver /
- periodic condition /
- spacecraft relative motion

HTML全文

参考文献(19)

Vaddi SS, Vadali SR, Alfriend KT. Formation flying: accommodating nonlinearity and eccentricity perturbations. Journal of Guidance, Control, and Dynamics, 2003, 26(2): 214-223

Gurfil P. Relative motion between elliptic orbits: generalized boundedness conditions and optimal formation-keeping. Journal of Guidance, Control, and Dynamics, 2005, 28(4): 761-767

Kasdin NJ, Gurfil P, Kolemen E. Canonical modeling of relative spacecraft motion via epicyclic orbital elements. Celestial Mechanics and Dynamical Astronomy, 2005, 92(4): 337-370

Schaub H, Alfriend KT. J₂ Invariant relative orbits for spacecraft formations. Celestial Mechanics and Dynamical Astronomy, 2001, 79(2): 77-95

Xu M, Wang Y, Xu SJ. On the existence of J₂ invariant relative orbits from the dynamical system point of view. Celestial Mechanics and Dynamical Astronomy, 2012, 112(4): 427-444

Damaren CJ. Almost periodic relative orbits under J₂perturbations. Proceedings of the Institution of Mechanical Engineers. Part G, Journal of Aerospace Engineering, 2007, 221(5): 767-774

Guibout VM, Scheeres DJ. Spacecraft formation dynamics and design. Journal of Guidance, Control, and Dynamics, 2006, 29(1): 121-133

Sabatini M, Izzo D, Bevilacqua R. Special inclinations allowing minimal drift orbits for formation flying satellites. Journal of Guidance, Control, and Dynamics, 2008, 31(1): 94-100

Vadali SR, Sengupta P, Yan Hui, et al. Fundamental frequencies of satellite relative motion and control of formations. Journal of Guidance, Control, and Dynamics, 2008, 31(5): 1239-1248

Lara M, Gurfil P. Integrable approximation of J₂-perturbed relative orbits. Celestial Mechanics and Dynamical Astronomy, 2012, 114(3): 229-254

Martinusi V, Gurfil P. Solutions and periodicity of satellite relative motion under even zonal harmonics perturbations. Celestial Mechanics and Dynamical Astronomy, 2011, 111(4): 387-414

Vadali SR, Yan Hui, Alfriend KT. Formation maintenance and reconfiguration using impulsive control. AIAA/AAS Astrodynamics Specialist Conference and Exhibit, August 2008, Honolulu, Hawaii. AIAA 2008-7359

Beigelman I, Gurfil P. Optimal fuel-balanced impulsive formation-keeping for perturbed spacecraft orbits. Journal of Guidance, Control, and Dynamics, 2008, 31(5): 1266-1283

Mazal L, Mingotti G, Gurfil P. Optimal on-off cooperative maneuvers for long-term satellite cluster flight. Journal of Guidance, Control, and Dynamics, 2014, 37(2): 391-402

Marshal JA, Broucke ME. Formation of vehicles in cyclic pursuit. IEEE Transactions on Automatic Control, 2004, 49(11): 1963-1974

毕鹏,罗建军,张博. 一种基于一致性理论的航天器编队飞行协同控制方法. 宇航学报,2010,31(1):70-74 (Bi Peng, Luo Jianjun, Zhang Bo. Cooperated control algorithm for spacecraft formation flying. Journal of Astronautics, 2010, 31(1): 70-74 (in Chinese))

马广富,梅杰. 多星系统相对轨道的自适应协同控制. 控制理论与应用,2011,28(6):781-787 (Ma Guangfu, Mei Jie. Adaptive cooperative control for relative orbits of multi-satellite systems. Control Theory and Applications, 2011, 28(6): 781-787 (in Chinese))

Alfriend KT, Vadali SR, Gurfil P, et al. Spacecraft Formation Flying: Dynamics, Control and Navigation. Oxford: Butterworth-Heinemann Press, 2010. 124-126

Battin RH. An Introduction to the Mathematics and Methods of Astrodynamics. Broadway, New York: American Institute of Aeronautics and Astronautics, Inc., 1999. 206-212
