近圆参考轨道卫星编队洛仑兹力控制

彭超; 高扬

doi:10.6052/0459-1879-12-044

近圆参考轨道卫星编队洛仑兹力控制

doi: 10.6052/0459-1879-12-044

彭超^1,2,3,
高扬^2, ,

1.
中国科学院光电研究院, 北京 100094
2. 中国科学院空间应用工程与技术中心, 北京 100094
3. 中国科学院研究生院, 北京 100080

详细信息

通讯作者:
高扬

中图分类号: V412.4+1
计量
- 文章访问数: 2088
- HTML全文浏览量: 81
- PDF下载量: 899
- 被引次数: 0
出版历程
- 收稿日期: 2012-02-17
- 修回日期: 2012-04-19
- 刊出日期: 2012-09-18

NEAR-CIRCULAR LOW-EARTH-ORBIT SPACECRAFT FORMATION CONTROL WITH LORENTZ FORCE

Peng Chao^1,2,3,
Gao Yang^{2
, ,}

1.
Academy of Opto-Electronics, Chinese Academy of Sciences, Beijing 100094, China
2. Technology and Engineering Center for Space Utilization, Beijing 100094, China
2. Graduate University of the Chinese Academy of Sciences, Chinese Academy of Sciences, Beijing 100080, China

摘要

摘要: 基于运动电荷在磁场中切割磁力线受到洛仑兹力作用的物理规律,分析了两种带电模式对经典轨道根数长期变化的影响:(1)卫星恒定带电模式;(2)前半个轨道周期卫星带电、后半周期不带电的非恒定带电模式.恒定带电模式可以有效地改变轨道升交点赤经、近地点幅角以及平近点角,对轨道半长轴、偏心率和倾角几乎不产生长期影响;而非恒定带电模式则可以有效地改变轨道偏心率.基于洛仑兹力作用下轨道根数长期变化规律以及轨道根数差描述的带电副星相对于不带电主星的运动,提出了利用洛仑兹力以及两种带电模式实现地球低轨近圆参考轨道卫星编队的控制策略,包括编队绕飞椭圆大小重构与编队中心漂移控制,解析求解了副星所需的带电量,并利用数值仿真验证了洛仑兹力控制的可行性.需要指出的是,洛仑兹力轨道控制无需消耗推进工质.
- 带电卫星 /
- 地球磁场 /
- 洛仑兹力 /
- 卫星编队 /
- 轨道根数差 /
- 编队重构
Abstract: Based on the physical law that charged particle experiences Lorentz force in magnetic field,we have analyzed the long-term averaged changes in classical orbital elements with two different charging modes:(1) The spacecraft is charged constantly;(2) The spacecraft is charged in the first half orbital revolution and uncharged in the second half.It is found that,in the first mode,the long-term changes in the longitude of ascending node,argument of periapsis and mean anomaly,can be effectively controlled by Lorentz force,while semi-major axis,eccentricity,and inclination can not be.Meanwhile,the eccentricity can be varied in the second mode.Based on the averaged evolution of the orbital element difference between two spacecrafts in formation-one is charged deputy and the other is uncharged chief,we proposed a new propellantless means for formation control-adjusting the size of fly-around elliptical relative orbit and formation center,when the chief spacecraft's reference orbit is near-circular.The required charge-to-mass ratio for formation control is derived analytically and the effectiveness of Lorentz-force formation control is verified by numerical simulations.
- charged spacecraft /
- Earth magnetic field /
- Lorentz force /
- spacecraft formation /
- orbital element differences /
- formation control

HTML全文

参考文献(25)

Peck MA.Lorentz-actuated orbits:electrodynamic propulsion without a tether.NASA Institute for Advanced Concepts,Phase I Final Report,May 2006

Schaffer L,Burns JA.The dynamics of weakly charged dust:motion through Jupiter's gravitatinal and magnetic fields.Journal of Geophysical Research,1987,92:2264-2280

Hough ME.Lorentz force perturbations of a charged ballistic missile.AIAA 277-287,1982

Streetman B,Peck MA.New synchronous orbits using the geomagnetic Lorentz force.Journal of Guidance,Control,and Dynamics,2007,30(6):1677-1690

Streetman B,Peck MA.General bang-bang control method for Lorentz augmented orbits.Journal of Spacecraft and Rockets,2010,47(3):484-492

Streetman B,Peck MA.Gravity-assist maneuvers augmented by the Lorentz force.AIAA 2007-6846,2007

Atchison JA,Streetman B,Peck MA.Prospects for Lorentz augmentation in Jovian captures.AIAA 2006-6596,2006

Pollock GE,Gangestad JW,Longuski JM.Responsive coverage using propellantless satellites.AIAA-RS6-2008-2002,2008

Pollock GE,Gangestad JW,Longuski JM.Inclination change in low-Earth orbit via the geomagnetic Lorentz force.Journal of Guidance,Control,and Dynamics,2010,33(5):1387-1395

Gangestad JW,Pollock GE,Longuski JM.Lagrange's planetary equations for the motion of electrostatically charged spacecraft.Celestial Mechanics and Dynamical Astronomy,2010,108(2):125-145

高扬.洛仑兹力推进的带电卫星:轨道运动与推进概念.见:中国空间科学学会空间探测专业委员会第22届学术会议文集,辽宁大连,2009 (Gao Yang.Charged spacecraft propelled by Lorentz force:orbital dynamics and propulsion concept.In:Proceeding of 22nd conference of space exploration committee,Chinese society of space research,Da Lian,Liao Ning,2009 (in Chinese))

Kong E,Elias L,Kwon D,et al.Electromagnetic formation flight for multi-satellite arrays.Journal of Spacecraft and Rockets,2004,41(4):659-666

Miller DW.Ahsun U,Ramirez-Riberos JL.Control of electromagnetic satellite formations in near-Earth orbit.Journal of Guidance,Control and Dynamics,2010,33(6):1883-1891

King LB,Chong JH,Deshmukh S,et al.Study of interspacecraft Coulomb forces and implications for formation flying.Journal of Propulsion and Power,2003,19(3):497-505

Schaub,H.,Stabilization of satellite motion relative to a Coulomb spacecraft formation.Journal of Guidance,Control and Dynamics,2005,28(6):1231-1239

Peck MA,Streetman B,Saaj CM,et al.Spacecraft formation flying using Lorentz forces.Journal of British Interplanetary Society,2007,60:263-267

Pollock GE,Gangestad JW,Longuski JM.Analysis of Lorentz spacecraft motion about Earth using the Hill-Clohessy-Wiltshire equations.AIAA 2008-6762,2008

Lai ST.An overview of electron and ion beam effects in charging and discharging of spacecraft.IEEE Transaction on Nuclear Sciences,1989,36 (6):2027-2032

Torkar K,Riedler W,Escoubet CP,et al.Active spacecraft potential control for Cluster-implementation and first results.Annales Geophysicae,2001,19:1289-1302

Jackson JD.Classical Electrodynamics.3rd edn.America:John Wiley & Sons,Inc,1999.186

Goldstein H,Poole C,Safko J.Classical Mechanics.American:Pearson Education,2002.22

罗远.洛仑兹力推进的带电卫星轨道动力学分析.[硕士论文].北京:中国科学院光电研究院/中国科学院研究生院,2009 (Luo Yuan.Analysis of the orbital dynamics about charged satellites propelled by Lorentz force.[Master Thesis].Beijing:Academy of Opto-Electronics,Chinese Academy of Sciences,2009 (in Chinese))

Peng C,Gao Y.Lorentz-force-perturbed orbits with Application to J₂-invariant formation.Acta Astronautica,2012,77:12-28

Schaub H.Spacecraft relative orbit geometry description through orbit element differences.In:Proceeding of 14th U.S.National Congress of Theoretical and Applied Mechanics Blacksburg,VA,June 23-28,2002

Hanspeter S,John LJ.Analytical mechanics of space systems.American Institute of Aeronautics and Astromautics,2003
