NONLINEAR DYNAMIC ANALYSIS OF A VAN DER POL-MATHIEU EQUATION WITH EXTERNAL EXCITATION
-
摘要: 本文针对含有自激励, 参数激励和外激励等三种激励联合作用下van der Pol-Mathieu方程的周期响应和准周期运动进行分析, 发现其准周期运动的频谱中含有均匀边频带这一新的特性. 首先, 采用传统的增量谐波平衡法(IHB法)分析了van der Pol-Mathieu方程的周期响应, 得到了其非线性频率响应曲线; 再利用Floquet理论对周期解进行稳定性分析, 得到了两种类型的分岔及它们的位置. 然后, 基于van der Pol-Mathieu方程准周期运动的频谱中边频带相邻频率之间是等距的且含有两个不可约的基频的特性(其中一个基频是已知的, 另一个基频事先是未知的), 推导了相应的两时间尺度IHB法, 精确计算出van der Pol-Mathieu方程的准周期运动的另一个未知基频和所有的频率成份及其对应的幅值, 尤其在临界点附近处的准周期运动响应. 得到的准周期运动结果和利用四阶龙格-库塔(RK)数值法得到的结果高度吻合. 最后, 研究发现了含外激励van der Pol-Mathieu方程在不同激励频率时的一些丰富而有趣的非线性动力学现象.
-
关键词:
- van der Pol-Mathieu方程 /
- 两时间尺度增量谐波平衡法 /
- 分岔 /
- 准周期运动 /
- 边频带
Abstract: The periodic responses and quasi-periodic motions of a van der Pol-Mathieu equation subjected to three excitations, i.e., self-excited, parametric excitation, and external excitation, are studied in this paper. A new characteristic is observed that the spectra of the quasi-periodic motions contain uniformly spaced sideband frequencies. Firstly, the traditional incremental harmonic balance (IHB) method is used to obtain periodic responses of the van der Pol-Mathieu equation and to trace their nonlinear frequency response curves automaically. Then the Floquet theory is used to analyze stability of the periodic responses and their bifurcations. Based on the characteristic that the spectra of quasi-periodic motions contain two incommensurate basic frequencies, i.e., the excitation frequency and a priori unknown frequency related to uniformly spaced sideband frequencies. Then the IHB method with two time-scales basing on the two basic frequencies is formulated to accurately calculate all frequency components and their corresponding amplitudes even at critical points. All the results obtained from the IHB method with two time-scales are in excellent agreement with those from numerical integration using the fourth-order Runge-Kutta method. Finally, this investigation reveals rich dynamic characteristics of the van der Pol-Mathieu equation in a range of excitation frequencies. -
-
[1] Iwatsubo T, Saigo M. Transverse vibration of a rotor system driven by a cardan joint. Journal of Sound and Vibration, 1984,95(1):9-18 [2] Doi M, Masuko I, Ito Y. et al. A study on parametric vibration in chuck work. Bulletin of JSME, 1985,28(245):2774-2780 [3] Warminski J, Litak G, Szabelski K. Synchronisation and chaos in a parametrically and self-excited system with two degrees of freedom. Nonlinear Dynamics, 2000,22(2):125-143 [4] Momeni M, Kourakis I, Moslehi-Fard M. et al. A van der Pol-Mathieu equation for the dynamics of dust grain charge in dusty plasmas, Journal of Physics A: Mathematical and Theoreitcal, 2007,40(24):F473-F481 [5] Belhaq M, Kirrou I, Mokni L. Periodic and quasiperiodic galloping of a wind-excited tower under external excitation. Nonlinear Dynamics, 2013,74(3):849-867 [6] Kirrou I, Mokni L, Belhaq M. On the quasiperiodic galloping of a wind-excited tower. Journal of Sound and Vibration, 2013,332(18):4059-4066 [7] Tondl A. On the interaction between self-excited and parametric vibrations. National Research Institute for Machine Design, Monographs and Memoranda No. 25, Prague 1978 [8] Kotera T, Yano S. Periodic solutions and the stability in a non-linear parametric excitation system. Bulletin of JSME, 1985,28(241):1473-1480 [9] 陈予恕, 徐鉴. Van der pol-Duffing-Mathieu型系统主参数共振分岔解的普适分类. 中国科学A辑, 1995,25(12):1287-1297 (Chen Yushu, Xu Jian. Van der Pol type-Duffing-Mathieu system primary parameter resonance bifurcation solution of the general classfication. Science in China A. 1995,25(12):1287-1297 (in Chinese))
[10] Szabelski K, Warminski J. Self-excited system vibrations with parametric and external excitation. Journal of Sound and Vibration, 1995,187(4):595-607 [11] 彭献, 陈自力. 一类强非线性系统共振周期解的渐近分析. 动力学与控制, 2004,2(1):46-50 (Peng Xian, Chen Zili. Asymptotic analysis for resonance cycle solution of a type of strongly nonlinear systems. Journal of Dynamics and Control. 2004,2(1):46-50 (in Chinese))
[12] Belhaq M, Fahsi A. 2:1 and 1:1 frequency-locking in fast excited van der Pol-Mathieu-Duffing oscillator. Nonlinear Dynamics, 2007,53(1-2):139-152 [13] Pandey M, Rand RH, Zehnder AT. Frequency locking in a forced Mathieu-van der Pol-Duffing system. Nonlinear Dynamics, 2007,54(1-2):3-12 [14] 张琪昌, 冯晶晶, 王炜. 类Padé逼近方法在二维非线性振动系统的应用. 力学学报, 2011,43(5):914-921 (Zhang Qichang, Feng Jingjing, Wang Wei. The construction of homoclinic and heteroclinic orbit in two-dimentsional nonlinear systems based on the quasi-Padé approximation, Chinese Journal of Theoretical and Applied Mechanics, 2011,43(5):914-921 (in Chinese))
[15] Warminski J. Nonlinear dynamics of self-, parametric, and externally excited oscillator with time delay: van der Pol versus Rayleigh models. Nonlinear Dynamics, 2019,99(1):35-56 [16] 王延庆, 郭星辉, 梁宏琨 等. 凸肩叶片的非线性振动特性与运动分岔. 力学学报, 2011,43(4):755-764 (Wang Yanqing, Guo Xinghui, Liang Hongkun, et al. Nonlinear vibratory characteristics and bifurcations of shrouded blades. Chinese Journal of Theoretical and Applied Mechanics. 2011,43(4):755-764 (in Chinese))
[17] 张登博, 唐有绮, 陈立群. 非齐次边界条件下轴向运动梁的非线性振动. 力学学报, 2019,51(1):218-227 (Zhang Dengbo, Tang Youqi, Chen Liqun. Nonlinear vibration of axially moving beams with nonhomogeneous boundary conditions. Chinese Journal of Theoretical and Applied Mechanics. 2019,51(1):218-227 (in Chinese))
[18] 顾伟, 张博, 丁虎 等. 2:1 内共振条件下变转速预变形叶片的非线性动力学响应. 力学学报, 2020,52(4):1131-1142 (Gu Wei, Zhang Bo, Ding Hu, et al. Nonlinear dynamic response of pre-deformation blade with variable rotational speed under 2:1 internal resonance. Chinese Journal of, Theoretical and Applied Mechanics, 2020,52(4):1131-1142 (in Chinese))
[19] 陈娅昵, 孟文静, 钱有华 . 一类 Duffing 型系统的不动点混沌和 Fold/Fold 簇发现象及机理分析. 力学学报, 2020,52(5):1475-1484 (Chen Yani, Meng Wenjing, Qian Youhua. Fixed point chaos and Fold/Fold bursting of a class of Duffing systems and the mechanism analysis. Chinese Journal of Theoretical and Applied Mechanics. 2020,52(5):1475-1484 (in Chinese))
[20] Nayfeh AH, Mook DT. Nonlinear Oscillations. Wiley, 1995 [21] Belhaq M, Houssni M. Quasi-periodic oscillations, chaos and suppression of chaos in a nonlinear oscillator driven by parametric and external excitations. Nonlinear Dynamics, 1999,18(1):1-24 [22] Abouhazim N, Belhaq M, Lakrad F. Three-period quasi-periodic solutions in the self-excited quasi-periodic Mathieu oscillator. Nonlinear Dynamics, 2005,39(4):395-409 [23] Fan Q, Leung AYT, Lee YY. Periodic and quasi-periodic responses of van der Pol-Mathieu system subject to various excitation. International Journal of Nonlinear Sciences and Numerical Simulation, 2016,17(1):29-40 [24] Veerman F, Verhulst F. Quasiperiodic phenomena in the van der Pol-Mathieu equation. Journal of Sound and Vibration, 2009,326(1-2):314-320 [25] Huang JL, Zhu WD. An incremental harmonic balance method with two timescales for quasiperiodic motion of nonlinear systems whose spectrum contains uniformly spaced sideband frequencies. Nonlinear Dynamics, 2017,90(2):1015-1033 [26] Huang JL, Zhu WD. A new incremental harmonic balance method with two time scales for quasi-periodic motions of an axially moving beam with internal resonance under single-tone external excitation. Journal of Vibration and Acoustics, 2017,139(2):021010 [27] Huang JL, Zhou WJ, Zhu WD. Quasi-periodic motions of high-dimensional nonlinear models of a translating beam with a stationary load subsystem under harmonic boundary excitation. Journal of Sound and Vibration, 2019,462:114870 [28] Cheung YK, Chen SH, Lau SL. Application of the incremental harmonic balance method to cubic non-linearity systems. Journal of Sound and Vibration, 1990,140(2):273-286 [29] 陈树辉. 强非线性振动系统的定量分析方法. 北京: 科学出版社, 2007 (Chen Shuhui. Quantitative Analysis Methods for Strongly Nonlinear Vibration. Beijing: Science Press, 2007 (in Chinese))
[30] Hsu CS. Impulsive parametric excitation: Theory. Journal of Applied Mechanics, 1972,39(2):551-558 [31] Hsu CS. On approximating a general linear periodic systems. Journal of Mathematical Analysis and Applications, 1974,45(1):234-251 [32] Hsu CS, Cheng WH. Applications of the theory of impulsive parametric excitation and new treatments of general parametric excitation problems. Journal of Applied Mechanics, 1973,40(1):78-86 [33] Friedmann P, Hammond CE, Woo TH. Efficient numerical treatment of periodic systems with application to stability problems. International Journal of Numerical Methods in Engineering, 1977,11(7):1117-1136 [34] Huang JL, Su RKL, Chen SH. Precise Hsu's method for analyzing the stability of periodic solutions of multi-degrees-of-freedom systems with cubic nonlinearity. Computers and Structures, 2009,87(23-24):1624-1630 [35] Zhong WX, Williams FW. A precise time step integration method. Proceedings of the Institution of Mechanical Engineers, Part C: Journal of Mechanical Engineering Science, 1994,208(6):427-430
