一种用于材料高应变率剪切性能测试的新型加载技术

许泽建; 丁晓燕; 张炜琪; 黄风雷

doi:10.6052/0459-1879-15-445

一种用于材料高应变率剪切性能测试的新型加载技术

北京理工大学爆炸科学与技术国家重点实验室, 北京 100081

基金项目: 国家自然科学基金(11302030)和北京市高校"青年英才计划"资助项目.

详细信息

通讯作者:
许泽建,副教授,主要研究方向:爆炸与冲击动力学.E-mail:xuzejian@bit.edu.cn

中图分类号: O347.4
计量
- 文章访问数: 1553
- HTML全文浏览量: 122
- PDF下载量: 837
出版历程
- 收稿日期: 2015-12-10
- 修回日期: 2016-01-26
- 刊出日期: 2016-05-17

A NEW LOADING TECHNIQUE FOR MEASURING SHEARING PROPERTIES OF MATERIALS UNDER HIGH STRAIN RATES

State Key Laboratory of Explosion Science and Technology, Beijing Institute of Technology, Beijing 100081, China

摘要

摘要: 高应变率下的冲击剪切实验技术是材料动态力学行为及其微观机理研究的重要基础.采用分离式霍普金森压杆(split Hopkinson pressure bar)装置一般可以获得材料在104s-1以内应变率的动态力学性能.在超过10⁴s^-1的应变率下对材料进行冲击剪切测试时,通常需要采用高速压剪飞片技术或由气炮发射子弹对试样进行直接加载.本文提出一种可用于传统霍普金森压杆技术的新型双剪切试样,可以在10³~10⁵s^-1剪应变率范围实现对材料剪切性能的精确测量;同时,可以对材料的变形及失效过程进行直接观测.试样与压杆之间避免了复杂的界面或连接装置,通过转接头可以保证试样与压杆直接接触,提高测试精度,同时可以防止因试样的横向位移而导致的非均匀变形.获得了紫铜在1400~75000s^-1应变率下的剪应力-剪应变曲线,并采用计算软件"ABAQUS/Explicit"对双剪切试样的动态加载过程进行了数值模拟和结果验证.分析表明,剪切区的主要区域内剪切成分占主导地位,其应力应变场沿厚度及宽度方向基本呈均匀分布.实验得到的剪应力-剪应变曲线与模拟结果吻合较好,说明所提出的基于分离式霍普金森压杆系统的双剪切试样可以为材料的高应变率力学性能测试提供一种方便有效的加载技术.
- 双剪切试样 /
- 分离式霍普金森压杆 /
- 动态剪切 /
- 高应变率 /
- 冲击加载
Abstract: Impact shearing loading technique at high strain rates is an important foundation for studying of dynamic behaviors and micromechanism of materials. Using the split Hopkinson pressure bar (SHPB) technique, material behaviours can usually be investigated under strain rates up to 104s^-1. To obtain strain rates that exceed 104s^-1 under dynamic shearing, however, pressure-shear plate impact technique or direct impact method with an air-gun launched projectile has to be used. In this paper, a new double-shear specimen that can be used under the SHPB technique is proposed. With this method, dynamic shear properties of materials can be tested precisely under strain rates ranging from 103 to 105s^-1. Complex interfaces or connectors are not needed between the specimen and the bars. With the aid of a simple fixture, the specimen can contact with the bars directly, with its transverse movements limited. In this work, shear stress-shear strain curves of pure copper were acquired at strain rates between 1 400 and 75 000 s^-1. The dynamic loading processes were modeled by ABAQUS/Explicit to check the validity of this testing method. The results show that the shear component dominates the stress and strain fields, which are distributed uniformly in the central part of the shear zone. The measured shear stress-shear strain curves agree very well with the simulation results. It shows that the new double-shear specimen provides a convenient and e ective way to test dynamic shear properties of materials under high strain rates.
- double-shear specimen /
- split Hopkinson pressure bar (SHPB) /
- dynamic shear /
- high strain rate /
- impact loading

HTML全文

参考文献(26)

1 Hopkinson B. A method of measuring the pressure produced in the detonation of high explosives or by the impact of bullets. Proceedings of the Royal Society of London A Mathematical Physical & Engineering Sciences, 1914, 213(89): 411-413

2 Davies RM. A critical study of the hopkinson pressure bar. Philosophical Transactions of the Royal Society A Mathematical Physical & Engineering Sciences, 1948, 240(821): 375-457

3 Kolsky H. An investigation of the mechanical properties of materials at very high rates of loading. Proceedings of the Physical Society,1949, 62(11): 676-700

4 段祝平, 孙琦清, 杨大光等. 高应变率下金属动力学性能的实验与理论研究- 一维杆的实验方法及其应用. 力学进展, 1980,10(1): 1-16 (Duan Zhuping, Sun Qiqing, Yang Daguang. Experimental and theoretical study on the dynamic properties of metal under high strain rate-Experimental method and application of dimension bar. Advances in Mechanics, 1980, 10(1): 1-16 (in Chinese))

5李玉龙, 郭伟国,徐绯等. Hopkinson 压杆技术的推广应用. 爆炸与冲击, 2006, (26): 385-394 (Li Yulong, Guo Weiguo, Xü Fei. Popularization and application of Hopkinson pressure bar technique. Explosion and Shock Waves, 2006, (26): 385-394 (in Chinese))

6 Murr LE, Staudhammer KP, Meyers MA. Metallurgical Applications of Shock Wave and High Strain Rate Phenomena. New York: Dekker Mechanical Engineering, 1986

7 Meyer LW, Staskewitsch E, Burblies A. Adiabatic shear failure under biaxial dynamic compression/shear loading. Mechanics of Materials,1994, 17(2): 203-214

8 Rittel D, Lee S, Ravichandran G. A shear-compression specimen for large strain testing. Experimental Mechanics, 2002, 42(1): 58-64

9 Dorogoy A, Rittel D, Godinger A. A shear-tension specimen for large strain testing. Experimental Mechanics, DOI 10.1007/s11340-015-0106-1

10 林艺生, 傅学金, 杨月诚. 30CrMnSiA 绝热剪切带显微观察与分析. 兵器材料科学与工程, 2010, 33(6): 59-61 (Lin Yisheng, Fu Xuejin, Yang Yuecheng. Microscopic observation and analysis of adiabatic shear band 30CrMnSiA. Ordnance Material Science and Engineering, 2010, 33 (6): 59-61 (in Chinese))

11 Meyers MA, Chen YJ, Marquis FDS, et al. High-strain, high-strainrate behavior of tantalum. Metallurgical & Materials Transactions A, 1995, 26(10): 2493-2501

12 魏志刚, 李永池. 冲击载荷作用下钨合金材料绝热剪切带形成机理. 金属学报, 2005, 36(12): 1263-1268 (Wei Zhigang, Li Yongchi. The formation mechanism of adiabatic shear band formation mechanism of tungsten alloy materials under impact loading. Journal of Metals, 2005, 36 (12): 1263-1268 (in Chinese))

13 Hartmann KH, Kunze HD, Meyer LW. Shock Waves and Highstrain- rate Phenomena in Metals. Springer US, 1981

14 Ferguson WG, Hauser FE, Dorn JE. Dislocation damping in zinc single crystals. British Journal of Applied Physics, 1967, 18: 411-417

15 Dodd B, Bai Y. Adiabatic Shear Localization. Frontiers and Advances: Elsevier, London, 2012

16 Campbell JD, Ferguson WG. The temperature and strain rate dependence of shear strength of mild steel. Philosophical Magazine,1970, 21(169): 63-82

17 Ruiz DJ, Harding J, Ruiz C. High strain rate testing of materials - a fully validated test calibration by a hybrid numerical/experimental technique. Journal De Physique IV, 1991, C3: 465-470

18 Klepaczko JR. An experimental technique for shear testing at high and very high strain rates. The case of a mild steel. International Journal of Impact Engineering, 1994, 15(1): 25-39

19 Klepaczko JR. Remarks on impact shearing. Journal of the Mechanics & Physics of Solids, 1998, 46(10): 2139-2153

20 Rusinek A, Klepaczko JR. Shear testing of a sheet steel at wide range of strain rates and a constitutive relation with strain-rate and temperature dependence of the flow stress. International Journal of Plasticity,2001, 17(1): 87-115

21 Guo Y, Li Y. A novel approach to testing the dynamic shear response of Ti-6Al-4V. Acta Mechanica Solida Sinica, 2012, 25(3): 299-311

22 Shi FF, Merle R, Hou B, et al. A critical analysis of plane shear tests under quasi-static and impact loading. International Journal of Impact Engineering, 2014, 74: 107-119

23 Clifton RJ, Klopp RW. Pressure-shear plate impact testing. Metals Handbook, 1985, 8(9): 230

24 Nemat-Nasser S. Hopkinson techniques for dynamic recovery experiments. Proceedings of the Royal Society A Mathematical Physical & Engineering Sciences, 1991, 435(1894): 371-391

25 Xu ZJ, Huang FL. Comparison of constitutive models for FCC metals over wide temperature and strain rate ranges with application to pure copper. International Journal of Impact Engineering, 2015, 79:65-74

26 Culver RS. Thermal Instability Strain in Dynamic Plastic Deformation. In: Rohde RW, eds. Metallurgical Effects at High Strain Rates, New York, NY: Plenum Press, 1973. 519-530.
