页岩气藏压裂水平井试井分析

朱光普; 姚军; 樊冬艳; 曾慧

doi:10.6052/0459-1879-15-229

页岩气藏压裂水平井试井分析

中国石油大学(华东)石油工程学院, 山东青岛 266580

基金项目: 国家自然科学基金(51504277,51504276),山东省自然科学基金(ZR2014EEP018)和中国石油大学(华东)研究生创新工程(YCX2015018)资助项目.

详细信息

作者简介:
姚军,教授,主要研究方向:油气渗流理论.E-mail:RCOGFR_UPC@126.com

中图分类号: TE312
计量
- 文章访问数: 1485
- HTML全文浏览量: 128
- PDF下载量: 1605
出版历程
- 收稿日期: 2015-06-18
- 修回日期: 2015-10-13
- 刊出日期: 2015-11-17

PRESSURE TRANSIENT ANALYSIS OF FRACTURED HORIZONTAL WELL IN SHALE GAS RESERVOIR

School of Petroleum Engineering in China University of Petroleum, Shandong Qingdao 266580, China

Funds: The project was supported by the National Natural Science Foundation Key program of China (51504227,51504276), Natural Science Foundation of Shandong Province, China（ZR2014EEP018) and Master Innovative Project of China University of Petroleum (East China) (YCX2015018).

摘要

摘要: 页岩气藏资源丰富,开发潜力巨大,已成为目前研究的热点.与常规气藏相比,页岩气藏运移机制复杂,流动模式呈非线性,有必要考虑页岩气的吸附解吸,天然微裂缝的应力敏感性,人工裂缝内的非达西流等非线性因素对压裂水平井压力响应的影响. 基于双重介质和离散裂缝混合模型,分别采用Langmuir等温吸附方程描述吸附解吸,渗透率指数模型描述应力敏感,Forchheimer方程描述非达西效应,建立页岩气藏压裂水平井数值试井模型. 运用伽辽金有限元法对模型进行求解.根据试井特征曲线,划分流动阶段,着重分析非线性因素对压力响应的影响.结果表明:页岩气藏压裂水平井存在压裂裂缝线性流、压裂裂缝径向流、地层线性流、系统径向流及封闭边界影响5 种流动阶段.吸附解吸的影响发生窜流之后,Langmuir吸附体积增大,拟压力导数曲线凹槽更加明显,系统径向流出现时间与压力波传播到边界时间均延迟;天然裂缝系统的应力敏感性主要影响试井曲线的晚期段,拟压力和拟压力导数曲线均表现为上翘,应力敏感效应越强,上翘幅度越大;高速非达西效应对早期段影响较大,非达西效应越强,拟压力降幅度越大,试井曲线上翘.与解析解的对比以及矿场实例验证了模型的正确性与适用性.
- 页岩气藏 /
- 吸附解吸 /
- 应力敏感 /
- 非达西流 /
- 数值试井
Abstract: Shale gas reservoirs have received much attention for their potential in satisfying future energy demands. Compared to conventional gas reservoir, Shale gas reservoir is characterized by complicated nonlinear processes, including adsorption and desorption, pressure-dependent permeability and non-Darcy flow. To investigate the e ect of those nonlinear mechanisms, a combined dual-continuum and discrete fracture numerical well test model was developed to analyze the transient pressure. Desorption, pressure-dependent permeability of natural fractures and non-Darcy flow was respectively described by Langmuir isotherm equation, exponential model of permeability and Forchheimer equation. Galerkin finite element method was applied to solve the model. Flow regimes were divided and the e ect of nonlinear factors on pressure response was analyzed according to the well test curve. The results indicate that there are five flow regimes, including fracture linear flow, fracture radial flow, formation linear flow, formation radial flow, pseudo steady state of closed boundary. The shale gas desorption's e ect arising after interporosity flow happened, the bigger Langmuir adsorption volume is, the deeper groove shows on the derivative curve and the later pressure propagate to the border; Bigger pseudo-pressure drop and pseudo-pressure derivative were observed with greater pressure-dependent e ect in the later stage of well test curve; Non-Darcy flow in hydraulic fractures mainly a ecting the early time, the pseudo-pressure drop increased with increasing flow rate. The comparison with analytical solution and field engineering application prove the feasibility of the model.
- shale gas reservoir /
- adsorption and desorption /
- pressure-dependent permeability /
- non-Darcy flow /
- numerical well test

HTML全文

参考文献(32)

姚同玉,黄延章,李继山. 页岩气在超低渗介质中的渗流行为. 力学学报,2012,44(6):990-995(Yao Tongyu, Huang Yanzhang, Li Jishan. Flow regim for shale gas in extra low permeability porous media. Chinese Journal of Theoretical and Applied Mechanics, 2012, 44(6): 990-995(in Chinese))

Nobakht M, Clarkson CR, Kaviani D. New type curves for analyzing horizontal well with multiple fractures in shale gas reservoirs. In: Proceedings of the SPE Unconventional Resources Conference, Calgary, Alberta, Canada, 15-17 November 2011. Society of Petroleum Engineers, 2011

Lewis AM, Hughes RG. Production data analysis of shale gas reservoirs. In: Proceedings of the SPE Annual Technical Conference and Exhibition, Denver, Colorado, USA, 21-24 September 2008. Society of Petroleum Engineers, 2008

姚军,孙海,樊冬艳等. 页岩气藏运移机制及数值模拟. 中国石油大学学报(自然科学版),2013, 37(1):91-98 (Yao Jun, Sun Hai, Fan Dongyan, et al. Transport mechanisms and numerical simulation of shale gas reservoir. Journal of China University of Petrolem, 2013, 37(1):91-98 (in Chinese))

Zhang M, Yao J, Sun H, et al. Triple-continuum modeling of shale gas reservoirs considering the effect of kerogen. Journal of Natural Gas Science and Engineering, 2015, 24: 252-263

Wu YS, Li N, Wang C, et al. A multiple-continuum model for simulation of gas production from shale gas reservoirs. In: Proceedings of the SPE Reservoir Characterisation and Simulation Conference and Exhibition, Abu Dhabi, UAE, 16-18 September 2013. Society of Petroleum Engineers, 2013

Ding D, Wang C, Wu YS. Characterizing hydraulic fractures in shale gas reservoirs using transient pressure tests. In: Proceedings of the SPE Hydraulic Fracturing Technology Conference, Woodlands,Texas, USA, 46 February 2013. Society of Petroleum Engineers, 2013

Fan DY, Yao J, Sun H, et al. A composite model of hydraulic fractured horizontal well with stimulated reservoir volume in tight oil & gas reservoir. Journal of Natural Gas Science and Engineering, 2015, 24: 115-123

Ozkan E, Brown ML, Raghavan R, et al. Comparison of fractured-horizontal-well performance in tight sand and shale reservoirs. In: Proceedings of the SPE Western North American Regional Meeting, Anaheim, California, USA, 26-30 January 2009. Society of Petroleum Engineers, 2009

Cheng YM. Pressure transient characteristics of hydraulically fractured horizontal shale gas wells. In: Proceedings of the SPE Western Regional Meeting, San Jose, California,USA, 24-26 March, 2009. Society of Petroleum Engineers, 2009

Lee SJ, Kim TH, Lee KS. Type curves for pressure transient analysis of horizontal wells in shale gas reservoirs. In: Proceedings of the SPE Middle East Oil and Gas Show and Conference, Manama, Bahrain, 10-13 March, 2013. Society of Petroleum Engineers, 2013

Eshkalak MO, Aybar U, Sepehrnoori K. An integrated reservoir model for unconventional resources, coupling pressure dependent phenomena. In: Proceedings of the SPE Eastern Region Meeting, Charleston, WV, USA, 21-23 October, 2014. Society of Petroleum Engineers, 2014

Wu YS, Li JF, Ding DY, et al. A generalized framework model for simulation of gas production in unconventional gas reservoirs. In: Proceedings of the SPE Reservoir Simulation Symposium, Woodlands, Texas, USA, 18-20 February, 2012. Society of Petroleum Engineers, 2012

张帆. 页岩气藏压裂水平井试井分析方法研究. [硕士论文]. 成都:西南石油大学,2014 (Zhang Fan. The research of well test analytical method of fractured horizontal well in shale gas well. [Master Thesis]. Chendu: South West Petroleum University, 2014 (in Chinese))

樊冬艳,姚军,孙海等. 页岩气藏分段压裂水平井不稳定渗流模型. 中国石油大学学报(自然科学版),2014,38(5):116-123 (Fan Dongyan, Yao Jun, Sun Hai, et al. Transient flow model of stage-fractured horizontal wells in shale gas reservoirs. Journal of China University of Petrolem, 2014,38(5):116-123 (in Chinese))

Kuchuk F, Biryukov D. Pressure-transient behavior of continuously and discretely fractured reservoirs. In: Proceedings of the SPE Annual Technical Conference and Exhibition, San Antonio, Texas, USA, 8-10 October, 2012. Society of Petroleum Engineers, 2012

Morton KL, Nogueira PB, Booth R, et al. Integrated interpretation for pressure transient tests in discretely fractured reservoirs. In: Proceedings of the SPE Annual Conference & Exhibition incorporating SPE Europec, Copenhagen, Denmark, 4-7 June 2012. Society of Petroleum Engineers, 2012

Ramey HJ Jr. Non-Darcy flow and wellbore storage effects in pressure build-up and drawdown of gas wells. SPE Journal, 1058, 1965

Li D, Engler TW. Literature review on correlations of the non-darcy coefficient. In: Proceedings of the SPE Permian Basin Oil and Gas Recovery Conference, Midland, Texas, USA, 15-16 May 2001. Society of Petroleum Engineers, 2001

Zhang F, Yang DY. Determination of fracture conductivity in tight formations with non-Darcy flow behavior. In: Proceedings of the SPE Unconventional Resources Conference, Calgary, Alberta, Canada, 30 October-1 November 2012. Society of Petroleum Engineers, 2012

张烈辉,朱水桥,王坤等. 高速气体非达西渗流数学模型. 新疆石油地质,2004,25(2):165-167, 176 (Zhang Leihui, Zhu Shuiqiao, Wang Kun, et al. A mathematical model for non-darcy flow at high flow rate. Xing Jiang Petroleum Geology, 2004,25(2):165-167,176 (in Chinese))

Hagoort J. 气藏工程原理. 周勇等译. 北京:石油工业出版社,1992 (Hagoort J. The Principle of Gas Reservoir. Zhou Yong et al. transl. Beijin:Petroleum Industry Press,1992 (in Chinese))

Evans RD, Civan F. Characterization of non-Darcy multiphase flow in petroleum bearing formations. Oklahoma University., Norman, OK, USA, 1990

庄惠农. 气藏动态描述和试井. 北京:石油工业出版社,2009 (Zhuang Huinong. Gas Reservoir Dynamic Description and Well Testing. Beijing: Petroleum Industry Press, 2009 (in Chinese))

Lee J. Well Testing. New York: Society of Petroleum Engineers, 1982

Soeder DJ. Porosity and permeability of eastern Devonian gas shale. SPE Formation Evaluation, 1988, 3(1): 116-124

Ross DJ, Bustin RM. Characterizing the shale gas resource potential of Devonian-Mississippian strata in the western Canada sedimentary basin: Application of an integrated formation evaluation. AAPG Bulletin, 2008, 92(1): 87-125

Dong JJ, Hsu JY, Wu WJ, et al. Stress-dependence of the permeability and porosity of sandstone and shale from TCDP Hole-A. International Journal of Rock Mechanics and Mining Sciences, 2010, 47(7): 1141-1157

Chen D, Pan ZJ, Ye ZH. Dependence of gas shale fracture permeability on effective stress and reservoir pressure: Model match and insights. Fuel, 2015, 139: 383-392

Yu W, Sepehrnoori K, Patzek TW. Evaluation of gas adsorption in marcellus shale. In: Proceedings of the SPE Annual Technical Conference and Exhibition, Amsterdam, The Netherlands, 27-29 October 2014. Society of Petroleum Engineers, 2014

Zerzar A, Bettam Y. Interpretation of multiple hydraulically fractured horizontal wells in closed systems. In: Proceedings of the SPE International Improved Oil Recovery Conference in Asia Pacific, Kuala Lumpur, Malaysia, 20-21 October 2003. Society of Petroleum Engineers, 2003

姚军,刘丕养,吴明录. 裂缝性油气藏压裂水平井试井分析. 中国石油大学学报(自然科学版),2013,37(5):107-113, 119 (Yao Jun, Liu Piyang, Wu Minglu. Well test analysis of fractured horizontal well in fractured reservoir. Journal of China University of Petroleum, 2013,37(5):107-113, 119 (in Chinese))
