结构振动对大型激波风洞气动力测量的干扰

孟宝清; 韩桂来; 姜宗林

doi:10.6052/0459-1879-15-152

结构振动对大型激波风洞气动力测量的干扰

中国科学院力学研究所高温气体动力学国家重点实验室, 北京 100190

基金项目: 国家自然科学基金资助项目(11472281).

详细信息

通讯作者:
韩桂来,助研,主要研究方向:高超声速飞行器气动力/热特性、激波风洞气动力测量、爆轰波传播与演化机理.E-mail:hanguilai@imech.ac.cn

中图分类号: O326
计量
- 文章访问数: 1136
- HTML全文浏览量: 129
- PDF下载量: 858
出版历程
- 收稿日期: 2015-05-07
- 修回日期: 2015-08-25
- 刊出日期: 2016-01-17

THEORETICAL INVESTIGATION ON AERODYNAMIC FORCE MEASUREMENT INTERFERED BY STRUCTURAL VIBRATIONS IN LARGE SHOCK TUNNEL

State Key Laboratory of High Temperature Gas Dynamics, Institute of Mechanics, Chinese Academy of Sciences, Beijing 100190, China

摘要

摘要: 激波风洞起动过程形成冲击载荷激励测力系统的结构振动,气动力测量过程中振动尚未衰减,测力过程可以看作是一个动态的过程,激波风洞中天平输出信号包含了振动干扰的输出信号,现有的解决方法缺乏理论支撑,精度受限. 本文应用振动理论方法,得到了自由振动、强迫振动特性的基本解析结果. 自由振动特性研究中考查了单个振型对测力的干扰及其影响规律以及干扰量幅值随测力截面相对位置的变化规律. 强迫振动特性研究了不同载荷强迫振动下各阶振型对测力的干扰. 研究表明,由于干扰量幅值与加速度幅值的“零点位置” 不重合,传统加速度惯性补偿存在理论上的缺陷. 实验中确定干扰量主要来源需要综合考虑截面位置、载荷作用位置、载荷类型的影响.
- 激波风洞 /
- 气动力测量 /
- 振动干扰 /
- 理论求解
Abstract: Structural vibration of aerodynamic measurement system is caused by the impulse forces generated by startup process of the shock tunnel, and the test time is too short to allow the vibration to decay. Therefore, the aerodynamic force measurement can be considered as a dynamic process, during which the signals outputted by balance are consist of aerodynamic force signals and vibration signals. Existing methods are lack of support of theory and the accuracies of them are limited. Theoretical analysis is used in this paper and we obtain the analytical solutions of fundamental characteristics of free vibrations and forced vibrations. Study of free vibrations focuses on the disciplines of aerodynamic force measurement interfered by a single vibration shape and amplitude of interference changed with section of force measurement. The inferences of di erent vibration shapes during forced vibration motivated by varied forces are investigated in research of forced vibration. Results show that there are theoretical defects for traditional acceleration compensation techniques because the zero points of amplitude of interference and acceleration are inconsistent. What's more, the influences of section for force measurement, acting position of force and type of force should be considered to determine the main source of interference in experiments.
- shock tunnel /
- aerodynamic force measurement /
- vibration interference /
- theoretical investigation

HTML全文

参考文献(16)

1 姜宗林, 李进平, 赵伟等. 长试验时间爆轰驱动激波风洞技术研究. 力学学报, 2012, 44(5): 824-831 (Jiang Zonglin, Li Jinping, Zhao Wei, et al. Investigating into techniques for extending the testduring of detonation-driven shock tunnels. Chinese Journal of Theoretical and Applied Mechanics, 2012, 44(5): 824-831 (in Chinese))

2 Lynn KC, Commo SA, Parker PA. Wind-tunnel balance characterization for hypersonic research applications. Journal of Aircraft,2012, 49(2): 556-565

3 唐志共, 许晓斌, 杨彦广等. 高超声速风洞气动力试验技术进展. 航空学报, 2015, 36(1): 86-97 (Tang Zhigong, Xu Xiaobin, Yang Yanguang, et al. Research progress on hypersonic wind tunnel aerodynamic testing techniques. Acta Aeronautica et Astronautica Sinica, 2015, 36(1): 86-97 (in Chinese))

4 Robinson MJ, Mee DJ, Tsai CY, et al. Three-component force measurements on a large scramjet in a shock tunnel. Journal of Spacecraft and Rockets, 2004, 41(3): 416-425

5 Smith AL, Mee DJ, Daniel WJT, et al. Design, modelling and analysis of six component force balance for hypervelocity wind tunnel testing. Computers & Structures, 2001, 79(11): 1077-1088

6 谢海斌, 谢红卫, 龙志强. 磁悬挂天平校准关系的非线性拟合. 国防科技大学学报,2001, 23(6): 90-94 (Xie Haibin, Xie Hongwei, Long Zhiqiang. Nonlinear fitness of calibration model of magnetic suspension and balance system. Journal of National University of Defense Technology, 2001, 23(6): 90-94 (in Chinese))

7 刘慧敏, 尹力明. 磁悬挂天平俯仰电磁场的二维有限元分析. 计算机仿真, 2005, 22(8): 37-49 (Liu Huimin, Yin Liming. The 2D finite element analysis of msbs lifting electro magnetic field. Computer Simulation, 2005, 22(8): 37-49(in Chinese))

8 罗也凡, 毕志献. 脉冲型风洞用加速度计测力天平. 气动实验与测量控制, 1996, 10(1): 59-64 (Luo Yefan, Bi Zhixian. The accelerometer force balance used in the impulse wind tunnel. Aerodynamic Experiment and Measurement & Control, 1996, 10(1): 59-64 (in Chinese))

9 程忠宇, 陈宏, 张琦. 多加速度计振动分离惯性补偿测力技术. 实验流体力学, 1999, 13(4): 57-61 (Cheng Zhongyu, Chen Hong, Zhang Qi. Inertia compensation technology based on multiaccelerometer vibration separating. Journal of Experiments in Fluid Mechanics, 1999, 13(4): 57-61 (in Chinese))

10 Smolinski G. Proof of concept for testing acceleration compensation force balance techniques in short duration flows with a CEV capsule. AIAA Paper, 2007-1010, 2007

11 Marineau E, MacLean M, Mundy E, et al. Force measurements in hypervelocity flows with an acceleration compensated strain gage balance. Journal of Spacecraft and Rockets, 2012, 49(3): 474-482

12 贾区耀, 杨益农, 蒋增辉. 风洞自由飞实验结果的精度、准度. 宇航学报, 2009, 30(6): 2082-2085 (Jia Quyao, Yang Yinong, Jiang Zenghui. The precision and accuracy of wind tunnel free-flight experiment result. Journal of Astronautics, 2009, 30(6): 2082-2085 (in Chinese))

13 Laurence SJ, Hornung HG. Image-based force and moment measurement in hypersonic facilities. Experiments in Fluids, 2009,46(2): 343-353

14 郭大华, 高冰, 林贞彬. 脉冲风洞中新型自由天平探索. 流体力学实验与测量, 2003, 17(1): 68-72 (Guo Dahua, Gao Bing, Lin Zhenbin. The exploration of a new kind of free-released balance in impulsive wind tunnels. Experiments and Measurement in Fluid Mechnics, 2003, 17(1): 68-72 (in Chinese))

15 刘洪山, 徐翔, 姜华等. 应力波天平在国内激波风洞上的应用. 实验流体力学, 2006, 20(1): 36-39 (Liu Hongshan, Xu Xiang, Jiang Hua, et al. The application of the stress wave force balance in shock tunnel in China. Journal of Experiments in Fluid Mechanics, 2006,20(1): 36-39 (in Chinese))

16 倪振华. 振动力学. 西安:西安交通大学出版社,1989 (Ni Zhenhua. Vibration Mechanics. Xi'an: Xi'an JiaoTong University Press,1989 (in Chinese))
