平纹编织陶瓷基复合材料面内剪切细观损伤行为研究

郭洪宝; 王波; 贾普荣; 杨成鹏

doi:10.6052/0459-1879-15-133

平纹编织陶瓷基复合材料面内剪切细观损伤行为研究

西北工业大学力学与土木建筑学院, 西安 710129

详细信息

通讯作者:
王波,副教授,主要研究方向:复合材料的损伤与力学行为.E-mail:b.wang@nwpu.edu.cn

中图分类号: TB332
计量
- 文章访问数: 1192
- HTML全文浏览量: 146
- PDF下载量: 667
出版历程
- 收稿日期: 2015-04-14
- 修回日期: 2015-11-08
- 刊出日期: 2016-03-17

MESOSCOPIC DAMAGE BEHAVIORS OF PLAINWOVEN CERAMIC COMPOSITE UNDER IN-PLANE SHEAR LOADING

School of Mechanics and Civil. & Architecture, Northwestern Polytechnical University, Xi'an 710129, China

摘要

摘要: 采用约西佩斯库(Iosipescu)纯剪切试件,研究了平纹编织SiC/SiC和C/SiC复合材料的面内剪切应力-应变行为和细观损伤特性.通过试验获得了材料不同方向上的单调和迟滞应力-应变行为,对比分析了两种材料的剪切损伤特性,结果表明材料的剪切损伤演化规律受热残余应力水平影响严重.由试件断口电镜扫描结果发现剪切加载状态下桥连纤维承受显著的弯曲载荷和变形,据此提出了纤维弯曲承载机制,并结合裂纹闭合效应分阶段阐释了材料的剪切迟滞环形状.基于材料的剪切细观损伤机制,通过两个损伤变量表征了材料的剪切损伤演化进程,得到了材料的面内剪切细观损伤演化模型.对比发现2D-C/SiC复合材料45°方向基体裂纹的起裂应力明显小于2D-SiC/SiC复合材料,而两者0°/90°方向裂纹的起裂应力基本相同.
- 陶瓷基复合材料 /
- 平纹编织 /
- 面内剪切 /
- 纤维弯曲承载机制 /
- 细观损伤演化
Abstract: The in-plane shear mechanical behaviors and mesoscopic damage behaviors of plain woven SiC/SiC and C/SiC composites were investigated with Iosipescu specimens.The materials' monotonic and hysteresis stress-strain responses in the various directions were obtained by tests, and the shear damage properties of these two materials were analyzed comparatively.It is found that the shear damage evolutions of materials are affected by residual thermal stress significantly.SEM(scanning electron microscope) photos of fracture surfaces indicate that the bridging fibers withstand significant bending load and deflection.Therefore a fiber bending-bearing mechanism was proposed.And combined with the crack closure effect, the shape of hysteresis loops was elucidated well.By considering the characteristic of mesoscopic shear damage modes, two damage variables were defined to character the shear damage evolution of material.And the shear damage evolution models of these two materials were developed.The results show that the initiation stress for matrix cracks in the 45°direction of 2D-C/SiC composite is much lower than that of 2D-SiC/SiC composite, but the initiation stress values for matrix cracks in the 0°/90°direction are the same for these two materials.
- ceramic composites /
- plain woven /
- in-plane shear /
- fiber bending-bearing mechanism /
- mesoscopic damage evolution

HTML全文

参考文献(21)

1 Hallett SR, Green BG, Jiang WG, et al. An experimental and numerical investigation into the damage mechanisms in notched composites. Composites:Part A, 2009, 40:613-624

2 Schmidt S, Beyer S, Knabe H, et al. Advanced ceramic matrix composite materials for current and future propulsion technology applications. Acta Astronaut, 2004, 55(3-9):409-420

3 张鹏, 朱强, 秦鹤勇等. 航空发动机用耐高温材料的研究进展. 材料导报, 2014, 28(11):27-31(Zhang Peng, Zhu Qiang, Qin Heyong, et al. Research progress of high temperature materials for aeroengines. Materials Review, 2014, 28(11):27-31(in Chinese))

4 鲁芹, 胡龙飞, 罗晓光等. 高超声速飞行器陶瓷基复合材料与热结构技术研究进展. 硅酸盐学报, 2013, 41(2):251-260(Lu Qin, Hu Longfei, Luo Xiaoguang, et al. Development of ceramic composite and hot structures for hypersonic vehicles. Journal of the Chinese Ceramics Society, 2013, 41(2):251-260(in Chinese))

5 Vagaggini E, Domergue JM, Evans AG. Relationship between hysteresis measurements and the constituent properties of ceramic matrix composites:I, Theory. J Am Ceram Soc, 1995, 78(10):2709-2720

6 Ahn BK, Curtin WA. Strain and hysteresis by stochastic matrix cracking in ceramic matrix composites. J Mech Phys Solids, 1996, 45(2):177-209

7 Pryce AW, Smith PA. Matrix cracking in ceramic matrix composites under quasi-static tensile loading. Acta Metal Mater, 1993, 41:1269-1281

8 Li LB, Song YD. An approach to estimate interface shear stress of ceramic matrix composites from hysteresis loop. Appl Compos Mater, 2010, 17:309-328

9 Wang YQ, Zhang LT, Cheng LF, et al. Characterization of tensile behavior of a two-dimensional woven carbon/silicon carbide composite fabricated by chemical vapor infiltration. Material Science and Engineering A, 2008, 497:295-300

10 杨成鹏, 矫桂琼, 王波. 2D-C/SiC 复合材料的单轴拉伸力学行为及其强度. 力学学报, 2011, 43(2):330-337(Yang Chengpeng, Jiao Guiqiong, Wang Bo. Uniaxial tensile stress-strain behavior and strength of plain woven C/SiC composite. Chinese Journal of Theoretical and Applied Mechanics, 2011, 43(2):330-337(in Chinese))

11 管国阳, 矫桂琼, 张增光. 平纹编织C/SiC 复合材料剪切性能. 机械科学与技术, 2005, 24(5):515-517(Guan Guoyang, Jiao Guiqiong, Zhang Zengguang. In-plane shear fracture characteristics of plain-woven C/SiC composite. Mechanical Science and Technilogy, 2005, 24(5):515-517(in Chinese))

12 Yan KF, Zhang CY, Qiao SR, et al. Failure and strength of 2D-C/SiC composite under in-plane shear loading at elevated temperature. Materials and Design, 2011, 33:3504-3508

13 Weigel N, Kroplin B, Drinkler D. Micromechanical modeling of damage and failure mechanisms in C/C-SiC. Computational Materials Science, 1999, 16:120-132

14 Weigel N, Dinkler D, Kroplin B. Micromechanically based continuum damage mechanics material laws for fiber-reinforced ceramics. Computers and Structures, 2001, 79:2277-2286

15 Povl B, Heredia FE, Evans AG. In-plane shear properties of 2-D ceramic matrix composites. J. Am. Ceram. Soc., 1994, 77(10):2569-2574

16 Keith WP, Kedward KT. The stress-strain behavior of a porous unidirectional ceramic matrix composite. Composites, 1995, 26(3):163-174

17 Wang YQ, Zhang LT, Cheng LF. Comparison of in-plane shear behaviors of 2D plain woven C/SiC composites. Ceramic-Silikaty, 2012, 54:26-30

18 Keith WP, Kedward KT. Shear damage mechanisms in a woven, nicalon-reinforced ceramic-matrix composite. J Am Ceram Soc, 1997, 80(2):357-364

19 李潘, 王波, 甄文强等. 二维编织SiC/SiC 复合材料的剪切性能. 机械强度, 2014, 36(5):691-693(Li Pan,Wang Bo, ZhenWenqiang, et al. In-plane shear properties of plane-woven SiC/SiC composites. Journal of Mechanical Strength, 2014, 36(5):691-693(in Chinese))

20 郭洪宝, 贾普荣, 王波等. 基于迟滞行为的2D-SiC/SiC 复合材料组份力学性能分析. 力学学报, 2015, 47(2):260-269(Guo Hongbao, Jia Purong, Wang Bo, et al. Study on constituent properties of a 2D-SiC/SiC composite by hysteresis measurments. Chinese Journal of Theoretical and Applied Mechanics, 2015, 47(2):260-269(in Chinese))

21 杨成鹏. 陶瓷基复合材料的力学特性和氧化损伤模拟研究.[博士论文]. 西安:西北工业大学,2011(Yang Chengpeng. Mechanical characterization and oxidation damage modeling of ceramic matrix composites. Xi'an:Northwestern Polytechnical University, 2011(in Chinese))
