基于信号分子双向输运的运动细胞极性反转模拟

冯世亮; 朱卫平

doi:10.6052/0459-1879-14-242

基于信号分子双向输运的运动细胞极性反转模拟

冯世亮,
朱卫平^,

上海大学, 上海市应用数学和力学研究所, 上海200072

基金项目: 国家自然科学基金资助项目(31370940).

详细信息

通讯作者:
朱卫平,教授,主要研究方向:固体力学,细胞生物力学.E-mail:wpzhu@shu.edu.cn

中图分类号: Q615
计量
- 文章访问数: 1009
- HTML全文浏览量: 83
- PDF下载量: 540
出版历程
- 收稿日期: 2014-08-17
- 修回日期: 2014-10-30
- 刊出日期: 2015-03-17

SIMULATION FOR REVERSAL OF CELL POLARITY BASED ON BIDIRECTIONAL TRANSPORT OF SIGNALING MOLECULES

Feng Shiliang,
Zhu Weiping^,

Shanghai University, Shanghai Institute of Applied Mathematics and Mechanics, Shanghai 200072, China

Funds: The project was supported by the National Natural Science Foundation of China (31370940).

摘要

摘要: 为解释运动细胞极性反转实验所发生的现象, 依据调控细胞极化的信号级联转导关系, 构建了包含一对非稳态二维反应—扩散方程的数学模型, 并采用格子Boltzmann 方法数值求解. 数值实验显示, 当反向信号使胞内Rac 的活化梯度值达到和超过初始正向极化梯度的1.5 倍时, 负责细胞极化的Rac-PIs 反馈回路产生时空调控效应, 可驱动伪足标识信号分子(如磷酸激酶(PI3K) 和磷脂酰肌醇-3, 4, 5- 三磷酸(PIP₃)) 和尾部标识信号分子(如磷酸酶(PTEN) 和磷脂酰肌醇-4, 5- 双磷酸(PIP₂)) 发生双向输运, 并最终重新积聚于对极. 模拟得到的极性反转时程曲线与已有实验吻合. 此外, 针对实验观测到的新伪足开始形成与原先伪足完全消失之间存在着延滞时间(~30 s), 该文证实这是由于细胞两极对游离态激活酶(例如, PI3K) 展开竞争所致, 无需引入前人所设想的全局性抑制因子的作用.
- 运动细胞 /
- 极性反转 /
- 细胞骨架 /
- 信号转导 /
- 数学模型
Abstract: To investigate the mechanisms underlying the reversal of cell polarity, a mathematical model consisting of a pair of reaction-di usion equations was presented and solved numerically with the Lattice—Boltzmann method. It was found that, by applying a reversal gradient of Rac signal in a cell, labels for lamellipod (i.e., PI3K, and PIP₃) would disappear from the front of cell, and redistribute to the rear, while labels for tail (i.e., PTEN, PIP₂) would act oppositely. The spatiotemporal patterns of lamellipod and tail interconversion derived from our numerical simulation agreed well with that of the experimental observations. Besides, the time delay taking place between actin assembly at the new front and disassembly at the previous front was medicated by the completion of an activator (i.e., PI3K), without the help of a supposed "global inhibitor".
- motile cells /
- repolarization /
- cytoskeleton /
- signaling transduction /
- mathematical model

HTML全文

参考文献(30)

Wolf K, te Lindert M, Krause M, et al. Physical limits of cell migration: Control by ECM space and nuclear deformation and tuning by proteolysis and traction force. Journal of Cell Biology, 2013, 201(7): 1069-1084

Wrighton KH. Wound healing: ESCRTs help repair membranes. Nature Reviews Molecular Cell Biology, 2014, 15(3): 151-151

Muller WA. How endothelial cells regulate transmigration of leukocytes in the inflammatory response. American Journal of Pathology, 2014, 184(4): 886-896

Polacheck WJ, Zervantonakis IK, Kamm RD. Tumor cell migration in complex microenvironments. Cellular and Molecular Life Sciences, 2013, 70(8): 1335-1356

Tojima T, Itofusa R, Kamiguchi H. Steering neuronal growth cones by shifting the imbalance between exocytosis and endocytosis. Journal of Neuroscience, 2014, 34(21): 7165-7178

Jilkine A, Edelstein-Keshet L. A comparison of mathematical models for polarization of single eukaryotic cells in response to guided cues. PLoS Computational Biology, 2011, 7(4): e1001121

Dalous J, Burghardt E, Müller-Taubenberger A, et al. Reversal of cell polarity and actin-myosin cytoskeleton reorganization under mechanical and chemical stimulation. Biophysical Journal, 2008, 94(3): 1063-1074

Chung CY, Funamoto S, Firtel RA. Signaling pathways controlling cell polarity and chemotaxis. Trends in Biochemical Sciences, 2001, 26(9): 557-566

Yumura S, Mori H, Fukui Y. Localization of actin and myosin for the study of ameboid movement in Dictyostelium using improved immunofluorescence. Journal of Cell Biology, 1984, 99(3): 894-899

Gerisch G, Keller HU. Chemotactic reorientation of granulocytes stimulated with micropipettes containing fMet-Leu-Phe. Journal of Cell Science, 1981, 52(1): 1-10

Iglesias PA, Devreotes PN. Navigating through models of chemotaxis. Current Opinion in Cell Biology, 2008, 20(1): 35-40

Simon CM, Vaughan EM, Bement WM, et al. Pattern formation of Rho GTPases in single cell wound healing. Molecular Biology of the Cell, 2013, 24(3): 421-432

Meinhardt H. Orientation of chemotactic cells and growth cones: Models and mechanisms. Journal of Cell Science, 1999, 112(17): 2867-2874

Janetopoulos C, Ma L, Devreotes PN, et al. Chemoattractant-induced phosphatidylinositol 3, 4, 5-trisphosphate accumulation is spatially amplified and adapts, independent of the actin cytoskeleton. Proceedings of the National Academy of Sciences, 2004, 101(24): 8951-8956

Levine H, Kessler DA, Rappel WJ. Directional sensing in eukaryotic chemotaxis: A balanced inactivation model. Proceedings of the National Academy of Sciences, 2006, 103(26): 9761-9766

Mori Y, Jilkine A, Edelstein-Keshet L. Wave-pinning and cell polarity from a bistable reaction-diffusion system. Biophysical Journal, 2008, 94(9): 3684-3697

Feng S, Zhu W. Bidirectional molecular transport shapes cell polarization in a two-dimensional model of eukaryotic chemotaxis. Journal of Theoretical Biology. 2014, 363(21): 235-246

Lin B, Holmes WR, Wang CC, et al. Synthetic spatially graded rac activation drives directed cell polarization and locomotion. arXiv preprint arXiv: 1204.5517, 2012

Weiner OD, Neilsen PO, Prestwich GD, et al. A PtdInsP3-and Rho GTPase-mediated positive feedback loop regulates neutrophil polarity. Nature Cell Biology, 2002, 4(7): 509-513

Bos JL, Rehmann H, Wittinghofer A. GEFs and GAPs: critical elements in the control of small G proteins. Cell, 2007, 129(5): 865-877

Infante E, Ridley AJ. Roles of Rho GTPases in leucocyte and leukaemia cell transendothelial migration. Philosophical Transactions of the Royal Society B: Biological Sciences, 2013, 368(1629): 20130013

Huang YE, Iijima M, Parent CA, et al. Receptor-mediated regulation of PI3Ks confines PI (3, 4, 5) P₃to the leading edge of chemotaxing cells. Molecular Biology of the Cell, 2003, 14(5): 1913-1922

Charest PG, Firtel RA. Feedback signaling controls leading-edge formation during chemotaxis. Current Opinion in Genetics & Development, 2006, 16(4): 339-347

Goldbeter A. Oscillatory enzyme reactions and Michaelis-Menten kinetics. FEBS Letters, 2013, 587(17): 2778-2784

Postma M, Van Haastert PJM. A diffusion-translocation model for gradient sensing by chemotactic cells. Biophysical Journal, 2001, 81(3): 1314-1323

Gamba A, de Candia A, Di Talia S, et al. Diffusion-limited phase separation in eukaryotic chemotaxis. Proceedings of the National Academy of Sciences, 2005, 102(47): 16927-16932

Ueda M, Shibata T. Stochastic signal processing and transduction in chemotactic response of eukaryotic cells. Biophysical Journal, 2007, 93(1): 11-20

Ma L, Janetopoulos C, Yang L, et al. Two complementary, local excitation, global inhibition mechanisms acting in parallel can explain the chemoattractant-induced regulation of PI(3,4,5)P₃. Biophysical Journal, 2004, 87(6): 3764-3774

Marée AFM, Grieneisen VA, Edelstein-Keshet L. How cells integrate complex stimuli: The effect of feedback from phosphoinositides and cell shape on cell polarization and motility. PLoS Computational Biology, 2012, 8(3): e1002402

Neilson MP, Veltman DM, van Haastert PJM, et al. Chemotaxis: a feedback-based computational model robustly predicts multiple aspects of real cell behaviour. PLoS Biology, 2011, 9(5): e1000618
