BURSTING OSCILLATIONS AS WELL AS THE CLASSIFICATION IN THE FIELD WITH CODIMENSION-3 FOLD-FOLD-HOPF BIFURCATION
-
摘要: 不同尺度耦合系统存在着广泛的工程背景, 通常表现为大幅振荡与微幅振荡交替出现的簇发振荡, 其产生机理一直是当前国内外研究的前沿课题之一. 传统的几何奇异摄动分析方法仅对时域上的两尺度耦合有效, 无法揭示频域上不同尺度之间的相互作用, 同时, 当前相关研究仅针对余维一fold或Hopf分岔展开. 本文针对频域两尺度耦合向量场存在余维三fold-fold-Hopf分岔时的复杂动力特性, 基于包含三阶非线性项以内的该分岔向量场的标准型及其普适开折, 给出相应的分岔集, 从而将双开折参数平面划分为对应于不同行为的子区域. 引入慢变周期激励项取代其中一个开折参数, 随慢变激励项的变化, 会存在两类轨迹访问子区域途径, 产生周期Hopf/LPC, Hopf/LPC/Hopf/LPC, fold/LPC/Hopf/Homoclinic和fold/LPC 4种簇发振荡类型. 在分析过程中, 发现系统轨迹上的真实分岔, 往往与理论上的分岔点之间存在着滞后效应, 这种滞后效应的滞后时间也会随着激励幅值的增大而延长, 因为激励幅值的增大, 会导致轨迹沿相应平衡态运动的惯性增大, 特别是, 当激励幅值增大到一定值后, 会导致轨迹沿某平衡态运动并穿越该区域, 也即相关分岔效应来不及出现, 从而导致振荡形式的改变. 本工作表明, 对于局部分岔下的快慢效应, 通过向量场标准型开折参数的周期扰动, 在一定程度可以对该分岔所导致的所有可能的各种簇发进行归类, 并得到其相应的产生机制.
-
关键词:
- 频域两尺度耦合 /
- fold-fold-Hopf分岔 /
- 标准型及普适开折 /
- 簇发振荡 /
- 分岔机制
Abstract: The dynamical systems with the coupling of different scales observed widly in engineering problems often behave in the bursting oscilltions, characterized by the alternations between large-amplitude oscilltations and small-amplitude oscillations, the generation mechanism of which has been one of the hot topics in nonlinear science at home and abroad. The traditional geometric pertubation method can be employed to explore the mechanism of the oscillations only in the systems with two scales in time domain, which can not be directly used to investigate the interaction between different scales in frequency domain. Meanwhile, most of the results are obtained in the vector fields with codimension-1 fold or Hopf bifurcations. Here we focus on the complicated behaviors in the vector field with codimension-3 fold-folfd-Hopf bifurcation when two scales in frequency domain exist. Based on the normal form as well as its universal unfolding with the nonlinear terms up to the third order, all the possible bifurcations are derived, which divide the two unfolding parameter plane into several regions with different dynamics. By introducing a slow-varying periodic excitation instead of one of the unfolding parameters, two types of routes for the tarjectory visiting those regions can be observed, which may result in four classes of bursting oscillations, i.e., periodic Hopf/LPC, Hopf/LPC/Hopf/LPC, fold/LPC/Hopf/Homoclinic and fold/LPC bursting attractors with the variation of the exciting term. It is found that there may exist delay between the locations of the theoretical bifurcation points and the real bifurcation points on the trajectory. The delay may increase with the exciting amplitude, since the inertia of the movement along the equilibrium states may increase. Especiallty, when the exciting amplitude increases to an extent, the trajectory may pass acorss the corresponding regions before the related bifurcation occurs, which leads to the qualitative change of the oscillations. It is shown that, the slow-fast effect with local bifurcations can be investigated by using the periodic perturbation on the unfolding parameters in the normal form of the vector field, which can therefore to present all possible types of bursting patterns as well as the mechanism. -
-
[1] Mease KD. Multiple time-scales in nonlinear flight mechanics: diagnosis and modeling. Applied Mathematics and Computation, 2005,164:627-648 [2] Leimkuhler B. An efficient multiple time-scale reversible integrator for the gravitational N-body problem. Applied Numerical Mathematics, 2002,43:175-190 [3] Davies ML, Schreiber I, Scott SK. Dynamical behaviour of the Belousov- Zhabotinsky reaction in a field-batch reactor. Chemical Engineering Science, 2004,59:139-148 [4] Bashkirtseva I, Nasyrova V, Ryashko L. Stochastic spiking-bursting excitability and transition to chaos in a discrete-time neuron model. International Journal of Bifurcation and Chaos, 2020,30:2050153 [5] Duan LX, Liang TT, Zhao YQ, et al. Multi-time scale dynamics of mixed depolarization block bursting. Nonlinear Dynamics, 2021,103:1043-1053 [6] Bashkirtseva I, Ryashko L, Slepukhina E. Noise-induced spiking-bursting transition in the neural model with the blue sky catastrophe. Physical Review E Statistical Nonlinear & Soft Matter, 2019,99:062408 [7] Bashkirtseva I, Ryashko L, Slepukhina E. Stochastic generation and deformation of toroidal oscillations in neuron model. International Journal of Bifurcation and Chaos, 2018,28:1850070 [8] Gheouali M, Benzekri T, Lozi R, et al. Geometrical model of spiking and bursting neuron on a mug-shaped branched manifold. International Journal of Bifurcation and Chaos, 2020,30:2030044 [9] Chen M, Qi JW, Wu HG, et al. Bifurcation analyses and hardware experiments for bursting dynamics in non-autonomous memristive FitzHugh-Nagumo circuit. Nonlinear Dynamics, 2020,63:1035-1044 [10] Chen M, Qi JW, Xu Q, et al. Quasi-period, periodic bursting and bifurcations in memristor-based FitzHugh-Nagumo circuit. AEU-International Journal of Electronics and Communications, 2019,110:152840 [11] Bao H, Zhu D, Liu WB, et al. Memristor synapse-based Morris-Lecar model: Bifurcation analyses and FPGA-based validations for periodic and chaotic bursting/spiking firings. International Journal of Bifurcation and Chaos, 2020,30:2050045 [12] Bao BC, Yang QF, Zhu L, et al. Chaotic bursting dynamics and coexisting multi-stable firing patterns in 3D autonomous M-L model and microcontroller-based validations. International Journal of Bifurcation and Chaos, 2019,29:1950134 [13] Zhou CY, Li ZJ, Xie F, et al. Bursting oscillations in Sprott B system with multi-frequency slow excitations: Two novel ``Hopf/Hopf'' -hysteresis -induced bursting and complex AMB rhythms. Nonlinear Dynamics, 2020,97:2799-2811 [14] Chen ZY, Chen FQ, Zhou LQ. Slow-fast dynamics in the truss core sandwich plate under excitations with high and low frequencies. Applied Mathematical Modelling, 2020,88:382-395 [15] Chen ZY, Chen FQ. Mixed mode oscillations induced by bi-stability and fractal basins in the FGP plate under slow parametric and resonant external excitations. Chaos, Solitons & Fractals, 2020,137:109814 [16] Zhang SH, Zhang HL, Wang C, et al. Bursting oscillations and bifurcation mechanism in a permanent magnet synchronous motor system with external load perturbation. Chaos, Solitons & Fractals, 2020,141:110355 [17] 马新东, 姜文安, 张晓芳 等. 一类三维非线性系统的复杂簇发振荡行为及其机理. 力学学报, 2020,52(6):1789-1799 (Ma Xindong, Jiang Wenan, Zhang Xiaofang, et al. Complicated bursting behaviors as well as the mechanism of a three dimensional nonlinear system. Chinese Journal of Theoretical and Applied Mechanics, 2020,52(6):1789-1799 (in Chinese))
[18] Zhang H, Chen DY, Xu BB, et al. The slow-fast dynamical behaviors of a hydro-turbine governing system under periodic excitations. Nonlinear Dynamics, 2017,87:2519-2528 [19] Lashina EA, Chumakova NA, Chumakov GA, et al. Chaotic dynamics in the three-variable kinetic model of CO oxidation on platinum group metals. Chemical Engineering Journal, 2009,154:82-87 [20] Theodosiou C, Sikelis K, Natsiavas S. Periodic steady state response of large scale mechanical models with local nonlinearities. International Journal of Solids and Structures, 2009,46:3565-3576 [21] Surana A, Haller G. Ghost manifolds in slow-fast systems, with applications to unsteady fluid separation. Physica D, 2008,237:1507-1529 [22] Rasmussen A, Wyller J, Vik JO. Relaxation oscillations in spruce- budworm interactions. Nonlinear Analysis: Real World Applications, 2011,12:304-319 [23] Hodgkin AL, Huxley AF. A quantitative description of membrane current and its application to conduction and excitation in nerve. Journal Physiol, 1952,117:500-544 [24] Izhikevich EM. Resonate-and-fire neurons. Neural Networks, 2001,14(6-7):883-894 [25] Verhulst F. Singular perturbation methods for slow-fast dynamics. Nonlinear Dynamics, 2007,50:747-753 [26] Surana A, Haller G. Ghost manifolds in slow-fast systems, with applications to unsteady fluid separation. Physica D, 2008,237:1507-1529 [27] Fujimoto K, Kaneko K. How fast elements can affect slow dynamics. Physica D, 2003,180:1-16 [28] Fenichel N. Geometrical singular perturbation theory for ordinary differential equations. Journal of Differential Equations, 1979,31:53-98 [29] Krupa M, Szmolyan P. Extending geometric singular perturbation theory to non-hyperbolic points-fold and canard points in two dimensions. SIAM Journal on Mathematical Analysis, 2001,33:286-314 [30] Rinzel J. Discussion: Electrical excitability of cells, theory and experiment: Review of the Hodgkin-Huxley foundation and an update. Bulletin of Mathematical Biology, 1990,52:5-23 [31] Rasmussen A, Wyller J, Vik J O. Relaxation oscillations in spruce-budworm interactions. Nonlinear Analysis: Real World and Application, 2011,12:304-319 [32] Opala A, Pieczarka M, Matuszewski M. Theory of relaxation oscillations in exciton-polariton condensates. Physical Review B, 2018,98:195312 [33] Bertram R, Rubin JE. Multi-timescale systems and fast-slow analysis. Mathematical Biosciences: An International Journal, 2017,287:105-121 [34] Simo H, Woafo P. Bursting oscillations in electromechanical systems. Mechanics Research Communications, 2011,38:537-541 [35] Razvan MR, Yasaman S. Emergence of bursting in two coupled neurons of different types of excitability. Chaos, Solitons and Fractals, 2020,132:109482 [36] Vo T, Bertram R, Kaper TJ. Multi-mode attractors and spatio-temporal canards. Physica D, 2020,411:132544 [37] Baldemir H, Avitabile D, Tsaneva-Atanasova K. Pseudo-plateau bursting and mixed-mode oscillations in a model of developing inner hair cells. Communications in Nonlinear Science and Numerical Simulation, 2020,80:104979 [38] Izhikevich EM. Neural excitability, spiking and bursting. International Journal of Bifurcation and Chaos, 2000,6:1171-1266 [39] Li XH, Tang JH, Wang YL, et al. Approximate analytical solution in slow-fast system based on modified multi-scale method. Applied Mathematics and Mechanics (English Edition), 2020,41:605-622 [40] Li XH, Hou JY, Chen JF. An analytical method for Mathieu oscillator based on method of variation of parameter. Communications in Nonlinear Science and Numerical Simulation, 2016,37:326-353 [41] Bi QS, Zhang R, Zhang ZD. Bifurcation mechanism of bursting oscillations in parametrically excited dynamical system. Applied Mathematics and Computation, 2014,243:482-491 [42] 张毅, 韩修静, 毕勤胜. 串联式叉型滞后簇发振荡及其动力学行为. 力学学报, 2019,51(1):228-236 (Zhang Yi, Han Xiujing, Bi Qinsheng. Series-mode pitchfork-hysteresis bursting oscillations and their dynamical mechanisms. Chinese Journal of Theoretical and Applied Mechanics, 2019,51(1):228-236 (in Chinese))
[43] 魏梦可, 韩修静, 张晓芳 等. 正负双向脉冲式爆炸及其诱导的簇发振荡. 力学学报, 2019,51(3):904-911 (Wei Mengke, Han Xiujing, Zhang Xiaofang, et al. Positive and negative pulse-shaped explosion as well as bursting oscillations induced by it. Chinese Journal of Theoretical and Applied Mechanics, 2019,51(3):904-911 (in Chinese))
[44] De S, Balakrishnan J. Burst mechanisms and burst synchronization in a system of coupled type-I and type-II neurons. Communications in Nonlinear Science and Numerical Simulation, 2020,90:105391 [45] Njitacke ZT, Kengne J, Fotsin HB. Coexistence of multiple stable states and bursting oscillations in a 4D hopfeld neural network. Circuits, Systems, and Signal Processing, 2020,39:3424-3444 [46] Bi QS, Ma R, Zhang ZD. Bifurcation mechanism of the bursting oscillations in periodically excited dynamical system with two time scales. Nonlinear Dynamics, 2015,79:101-110 [47] Chen XK, Li SL, Zhang ZD, et al. Relaxation oscillations induced by an order gap between exciting frequency and natural frequency. Science China Technological Sciences, 2017,60:289-298 [48] Han XJ, Xia FB, Ji P, et al. Hopf-bifurcation-delay-induced bursting patterns in a modified circuit system. Communications in Nonlinear Science and Numerical, 2016,36:517-527 [49] Han XJ, Yu Y, Zhang C, et al. Turnover of hysteresis determines novel bursting in Duffing system with multiple-frequency external forcings. International Journal of Non-Linear Mechanics, 2017,89:69-74 [50] Yu P, Zhang W, Bi QS. Vibration analysis on a thin plate with the aid of computation of normal forms. International Journal of Non-Linear Mechanics, 2001,36:597-627 [51] Kuznetsov YA. Elements of Applied Bifurcation Theory. Second edition. New York: Springer-Verlag, 1998
