互逆规划理论及其用于建立结构拓扑优化的合理模型

隋允康; 彭细荣; 叶红玲; 铁军

doi:10.6052/0459-1879-19-259

互逆规划理论及其用于建立结构拓扑优化的合理模型

doi: 10.6052/0459-1879-19-259

隋允康^*,,
彭细荣^†3),,
叶红玲^*,
铁军^**

^* 北京工业大学机电学院工程力学系,北京 100022
^† 湖南城市学院土木工程学院,湖南益阳 413000
^** 天津财经大学理工学院,天津 300222

基金项目: 1) 国家自然科学基金资助项目(11672103)

详细信息

作者简介:
2) 隋允康,教授,主要研究方向：结构优化. E-mail:ysui@bjut.edu.cn

通讯作者:
彭细荣

中图分类号: O343.1
计量
- 文章访问数: 844
- HTML全文浏览量: 75
- PDF下载量: 84
- 被引次数: 0
出版历程
- 收稿日期: 2019-09-12
- 刊出日期: 2019-11-18

RECIPROCAL PROGRAMMING THEORY AND ITS APPLICATION TO ESTABLISH A REASONABLE MODEL OF STRUCTURAL TOPOLOGY OPTIMIZATION

Sui Yunkang^*
,,
Peng Xirong^{†3)
,},
Ye Hongling^*,
Tie Jun^**

^* Numerical Simulation Center for Engineering, Beijing University of Technology, Beijing 100022, China
^† School of Civil Engineering, Hunan City University, Yiyang 413000, Hunan,China
^** Tianjin University of Finance and Economics, Institute of Technology, Tianjin 300222, China

摘要

摘要: 在数学规划的领域里定义了互逆规划——各自目标函数与约束条件位置相互交换的一对规划. 接着指出,尽管互逆规划与对偶规划在表面上似乎类似,但是二者存在 5 点不同：(1) 是否为同一个问题的不同;(2) 存在``对偶间隙''与否的不同;(3) 设计变量数目的不同;(4) 是否单目标与多目标问题的不同;(5) 问题合理与否的不同. 然后,基于互逆规划的定义,用以审视结构拓扑优化模型,给出如下结果：(1) 从这个角度洞悉,在结构优化中,确实有不合理的模型一直被沿用着;(2) 找到了修正不合理模型使之合理化的方法;(3) 对于给定体积下的柔顺度最小化 (MCVC) 模型,指出了其不合理的原因;(4) MCVC 模型实际是互逆规划的 m 方,由此建立起其对应的 s 方, 即给出了多个柔顺度约束的体积最小化 (MVCC) 模型;(5)给出了MVCC模型中的结构柔顺度约束的物理解释和算法,论证了 ICM (independent continuous and mapping) 方法以往关于全局化应力约束的概念和方法;(6)数值算例表明了 MCVC 与 MVCC 模型作为互逆规划的差异,且印证了 MVCC 模型的合理性.MCVC 模型在不同体积约束及多工况下不同的权系数时,得到最优拓扑不同;但 MVCC 模型在多工况柔顺度约束下可得到唯一的最优拓扑.
- 结构拓扑优化设计 /
- 互逆规划 /
- MCVC 模型 /
- MVCC 模型 /
- ICM 方法
Abstract: Based on mathematical programming theory, the reciprocal programming is defined as a pair of programming which objective and constraint functions are changed each other. After that, it is pointed out that reciprocal programming and dual programming seem similar but there are five differences between them: (1) the difference in whether they are the same problem or not; (2) the difference in whether there exists a dual gap or not; (3) the difference in the number of design variables; (4) the difference between single-objective and multi-objective problems; (5) the difference between reasonable and unreasonable problems. Finally, based on the definition of the reciprocal programming, the structural topology optimization model is examined; and following results are obtained: (1) from this perspective, it is clear that there exists indeed unreasonable models that have been used in structural optimization; (2) a way to correct the unreasonable model and make it reasonable is put forward; (3) the reasons that the minimizing compliance model with volume constraint (MCVC for short) is unreasonable are presented; (4) according to the theory presented in this paper, the MCVC model is actually the m-aspect of reciprocal programming, so its corresponding s-aspect is established, that is, the minimizing volume model with multiple compliance constraints (MVCC for short); (5) the physical interpretation and algorithm of structural compliance constraints in the MVCC model are presented; and the concepts and methods of global stress constraint in the ICM (Independent continuous and mapping ) method are demonstrated; (6) numerical examples show the differences between the MCVC and MVCC model as a pair of reciprocal programming and verify the rationality of the MVCC model. Different optimized topologies are obtained for the MCVC model with different volume constraints and different weighting coefficients for multiple load cases. But a unique optimized topology can be achieved by the MVCC model with compliance constraints under multiple load case.
- structural topology optimization /
- reciprocal programming /
- MCVC model /
- MVCC model /
- ICM method

HTML全文

参考文献(1)

1	隋允康 . 建模$\cdot $变换$\cdot $优化: 结构综合方法新进展. 大连: 大连理工大学出版社, 1996
1	( Sui Yunkang. Modeling, Transformation and Optimization -- New Development of Structural Synthesis Method. Dalian: Dalian University of Technology Press, 1996 (in Chinese))
2	隋允康, 叶红玲 . 连续体结构拓扑优化的ICM方法. 北京: 科学出版社, 2013
2	( Sui Yunkang, Ye Hongling. Continuum Topology Optimization ICM Method. Beijing: Science Press, 2013 (in Chinese))
3	Sui YK, Peng XR . Modeling, Solving and application for topology optimization of continuum structures, ICM Method Based on Step Function. Elsevier, 2018
4	Fleury C. Structural weight optimization by dual methods of convex programming. International Journal for Numerical Methods in Engineering, 1979,14(2):1761-1783
5	Fleury C. Primal and dual methods in structural optimization. Journal of the Structural Division, 1980,106(5):1117-1133
6	Fleury C, Braibant V. Structural optimization: A new dual method using mixed variables. International Journal for Numerical Methods in Engineering, 1986,23(3):409-428
7	钱令希, 钟万勰, 程耿东等. 工程结构优化设计的一个新途径——序列二次规划SQP. 计算结构力学及其应用, 1984,1(1):7-20
7	( Qian Lingxi, Zhong Wanxie, Cheng Gendong, et al. An approach to structural optimization --- sequential quadratic programming, SQP. Computational Structural Mechanics and Applications, 1984,1(1):7-20 (in Chinese))
8	Fleury C. CONLIN: An efficient dual optimizer based on convex approximation concepts. Structural Optimization, 1989,1(2):81-89
9	Svanberg K. The method of moving asymptotes---a new method for structural optimization. International Journal for Numerical Methods in Engineering, 1987,24(2):359-373
10	Beekers M, Fleury C. A primal-dual approach in truss topology optimization. Computers & Structures, 1997,64(1-4):77-88
11	Hoppe RHW, Linsenmann C, Petrova SI. Primal-dual newton methods in structural optimization. Comput Visual Sci, 2006,9(2):71-87
12	Bubeck S. Convex optimization: Algorithms and complexity. Foundations and Trends in Machine Learning, 2015,8(3-4):231-357
13	隋允康, 阳志光 . 应用两点有理逼近改进的牛顿法和对偶法. 大连理工大学学报, 1994,34(1):1-9
13	( Sui Yunkang, Yang Zhiguang, Modified Newton's method and dual method through rational approximation at two expanded points. Journal of Dalian University of Technology, 1994,34(1):1-9 (in Chinese))
14	隋允康, 邢誉峰, 张桂明 . 基于两点累积信息的原/倒变量展开的对偶优化方法. 力学学报, 1994,26(6):699-710
14	( Sui Yunkang, Xing Yifeng, Zhang Guiming, The dual optimization method by original/reciprocal variables' expansion based on cumulative information at two points. Acta Mechanica Sinica, 1994,26(6):699-710 (in Chinese))
15	Bendsoe MP, Kikuchi N. Generating optimal topologies in structural design using a homogenization method. Computer Methods in Applied Mechanics and Engineering, 1988,71(2):197-224
16	Rozvany G. A critical review of established methods of structural topology optimization. Structural and Multidisciplinary Optimization, 2009,37(3):217-237
17	Sigmund O, Maute K. Topology optimization approaches. Structural and Multidisciplinary Optimization, 2013,48(6):1031-1055
18	蔡守宇, 张卫红, 高彤等. 基于固定网格和拓扑导数的结构拓扑优化自适应泡泡法. 力学学报, 2019,51(4):1235-1244
18	( Cai Shouyu, Zhang Weihong, Gao Tong, et al. Adaptive bubble method using fixed mesh and topological derivative for structural topology optimization. Chinese Journal of Theoretical and Applied Mechanics, 2019,51(4):1235-1244 (in Chinese))
19	Mlejnek HP. Some aspects of the genesis of structures. Structural Optimization, 1992,5(1-2):64-69
20	Norato J, Bends?e M, Haber R, et al. A topological derivative method for topology optimization. Structural and Multidisciplinary Optimization, 2007,33(4-5):375-386
21	Xie YM, Steven GP. A simple evolutionary procedure for structural optimization. Comput Struct, 1993,49(5):885-896
22	Osher S, Sethian J. Fronts propagating with curvature dependent speed-algorithms based on hamilton-jacobi formulations. J Comput Phys, 1988,79(1):12-49
23	Bourdin B, Chambolle A. Design-dependent loads in topology optimization. ESAIM: Control, Optimisation and Calculus of Variations, 2003,9(8):19-48
24	Zhang WS, Li D, Yuan J. A new three-dimensional topology optimization method based on moving morphable components (MMCs). Computational Mechanics, 2017,59(4):647-665
25	Yi GL, Sui YK. Different effects of economic and structural performance indicators on model construction of structural topology optimization. Acta Mechanica Sinia, 2015,9:1-12
26	彭细荣, 隋允康 . 对连续体结构拓扑优化合理模型的再探讨. 固体力学学报, 2016,37(1):1-11
26	( Peng Xirong, Sui Yunkang, A further discussion on rational topology optimization models for continuum structures. Chinese Journal of Solid Mechanics, 2016,37(1):1-11 (in Chinese))
27	隋允康, 叶红玲, 彭细荣 . 应力约束全局化策略下的连续体结构拓扑优化. 力学学报, 2006,38(3):364-370
27	( Sui Yunkang, Ye Hongling, Peng Xirong, Topological optimization of continuum structure under the strategy of globalization of stress constraints. Chinese Journal of Theoretical and Applied Mechanics, 2006,38(3):364-370 (in Chinese))
28	隋允康, 彭细荣, 叶红玲 . 应力约束全局化处理的连续体结构ICM拓扑优化方法. 工程力学, 2006,23(7):1-7
28	( Sui Yunkang, Peng Xirong, Ye Hongling, Topology optimization of continuum structure with globalization of stress constraints by ICM method. Engineering Mechanics, 2006,23(7):1-7 (in Chinese))
29	隋允康, 彭细荣 . 求解一类可分离凸规划的对偶显式模型DP-EM方法. 力学学报, 2017,49(5):1135-1144
29	( Sui Yunkang, Peng Xirong, A dual explicit model based DP-EM method for solving a class of separable convex programming. Chinese Journal of Theoretical and Applied Mechanics, 2017,49(5):1135-1144 (in Chinese))
30	Sui YK, Peng XR. Explicit model of dual programming and solving method for a class of separable convex programming problems. Engineering Optimization, 2019,51(7-9):1604-1625
31	Andreassen E, Clausen A, Lazarov BS, et al. Efficient topology optimization in MATLAB using 88 lines of code. Structural Multidisciplinary Optimization, 2011,43(1):1-16
