EXPERIMENTAL INVESTIGATION OF SYNTHETIC JET CONTROL ON LARGE FLOW SEPARATION OF AIRFOIL DURING STALL
-
摘要: 为研究低速状态合成射流在抑制翼型气流分离和推迟失速方面的控制机理, 开展了NACA0021 翼型失速特性射流控制的风洞试验研究. 通过系统性的模型测力、翼型瞬态流场粒子图像测速和边界层速度测定的对比试验, 深入探索了合成射流各参数对翼型失速特性控制效果的影响规律. 试验结果表明射流偏角在翼型升力和失速迎角控制方面的效果对射流动量系数较为敏感: 当动量系数较大时, 近切向射流的控制效果更好. 射流动量系数为0.033 时, 偏角30°的射流使得翼型升力系数峰值提高23.56%, 失速迎角增大5°; 而动量系数较小时, 偏角较大的射流能够获得最佳控制效果. 射流动量系数为0.0026 时, 法向射流对翼型最大升力系数控制效果最好(提高9.2%).Abstract: In order to investigate the active flow control effect of synthetic jet on preventing flow separation and delaying stall of airfoil at low speed, wind-tunnel tests of jet control on the stall characteristics of NACA0021 airfoil are conducted. By systematic comparison tests including measurements about model aerodynamic forces, flow velocity on the airfoil upper surface based on Particle Image Velocimetry (PIV) technology and velocity profiles in boundary layer, the influences of synthetic jet parameters on control effects of airfoil stall characteristics are further explored. A large number of experimental results indicate that control effects on airfoil lift and stall angle of attack (AoA) due to jet angle are sensitive to the momentum coeffcient of synthetic jet. Overall, the control effects of the almost tangential jet are more effective when the momentum coeffcient of synthetic jet is large enough: increments about 23.6% of maximum lift coeffcient and 5° of stall-incidence of airfoil are obtained when the jet angle is 30° with jet momentum coeffcient being 0.033. On the other hand, a larger jet angle is required to achieve the best control effect when the momentum coeffcient is small: when the momentum coeffcient is about 0.0026, the normal jet is most effective on increasing the maximum lift coeffcient of airfoil by an increment about 9.2%.
-
Key words:
- airfoil /
- airflow separation /
- stall /
- active flow control /
- synthetic jet /
- PIV measurement
-
Smith BL, Glezer A. The formation and evolution of synthetic jets. Physics of Fluids, 1998, 10(9): 2281-2297 Durrani D, Haider BA. Study of stall delay over a generic airfoil using synthetic jet actuator. AIAA-2011-943, 2011 Rumsey TB, Gatski WL. Summary of the 2004 CFD validation workshop on synthetic jets and turbulent separation control. AIAA 2004-2217, 2004 Seifert A, Darabi A, Wygnanski I. Delay of airfoil stall by periodic excitation. AIAA J, 1999, 33 (4): 691-707 Greenblatt D, Wygnanski IJ. The control of flow separation by period excitation. Progress in Aerospace Sciences, 2000, 36(7): 487-545 Gilarranz JL, Train LW, Rediniotis OK. A new class of synthetic jet actuators: Part II: Application to flow separation control. Journal of Fluids Engineering, 2005, 127(2): 377-387 He YY, Cary AW, Peters DA. Parametric and dynamic modeling for synthetic jet control of a post-stall airfoil. AIAA-2001-733; 2001 Hassan AA. A two-point active flow control strategy for improved airfoil stall/post stall aerodynamics. AIAA-2006-99, 2006 韩忠华, 宋文萍, 乔志德. YLSG107高升力翼型主动流动控制的数值模拟. 计算物理, 2009, 26(6): 837-841 (Han Zhonghua, Song Wenping, Qiao Zhide. Numerical simulation of active stall control on high-lift airfoil. Chinese Journal of Computational Physics, 2009, 26(6): 837-841 (in Chinese)) 张攀峰, 王晋军. 孔口倾斜角对合成射流控制翼型流动分离的影响. 兵工学报, 2009, 30(12): 1658-1662 (Zhang Panfeng, Wang Jinjun. Effect of orifice inclined angle on flow control of the stalled airfoil with synthetic jet actuator. Acta Armament Arii, 2009, 30(12): 1658-1662 (in Chinese)) 刘峰, 邹建锋, 郑耀. 合成射流物理参数对控制翼型流动分离的影响. 浙江大学学报(工学版), 2013, 47(1): 147-153 (Liu Feng, Zou Jianfeng, Zheng Yao. Effect of synthetic jets physical parameters on flow separation control over airfoil. Journal of Zhejiang University (Engineering Science), 2013, 47(1): 147-153 (in Chinese)) -
