基于有限变形理论的数值流形方法研究

位伟; 姜清辉; 周创兵

doi:10.6052/0459-1879-13-081

基于有限变形理论的数值流形方法研究

doi: 10.6052/0459-1879-13-081

位伟^1,2,
姜清辉^1,2,
周创兵^1,2

1.
武汉大学土木建筑工程学院, 武汉430072
2. 水资源与水电工程科学国家重点实验室, 武汉430072

基金项目: 国家重点基础研究发展计划（2011CB013506）和国家自然科学基金（51179137, 51309181）资助项目.

详细信息

作者简介:
姜清辉，教授，主要研究方向：岩土力学数值方法与边坡稳定分析.

中图分类号: O343.5
计量
- 文章访问数: 817
- HTML全文浏览量: 24
- PDF下载量: 1017
- 被引次数: 0
出版历程
- 收稿日期: 2013-03-21
- 修回日期: 2013-06-16
- 刊出日期: 2014-01-18

STUDY ON NUMERICAL MANIFOLD METHOD BASED ON FINITE DEFORMATION THEORY

1.
School of Civil Engineering, Wuhan University, Wuhan 430072, China
2. State Key Laboratory of Water Resources and Hydropower Engineering, Wuhan 430072, China

Funds: The project was supported by the National Natural Science Foundation (51179137) and the National Basic Research Program of China (2010CB732005, 51309181).

摘要

摘要: 原有数值流形方法通过积累每一时步的小变形而得到结构最终的大变形，然而，当结构发生大变形、大转动时往往产生较大计算误差. 针对该问题，从动量守恒方程以及应力边界条件的积分弱形式出发，引入流形方法的插值函数，建立了基于有限变形理论的数值流形方法. 通过对比改进前后流形方法的计算迭代格式，指出了原有流形方法计算大变形问题时的误差来源. 最后，通过大变形悬臂梁和旋转块体算例对有限变形流形方法进行了验证. 数值结果表明，改进后的流形方法能够很好地处理大变形大转动问题，消除了转动所带来的计算误差，其计算结果与解析解及ABAQUS 软件求得的数值解相吻合.
- 数值流形方法 /
- 有限变形 /
- 大转动
Abstract: The large deformation of structure calculated by original numerical manifold method (NMM) is cumulated by small deformation calculated in each time step. However, when the structure undergoes large deformation and large rotation, the calculation strategy used in original NMM will lead to calculation error. In order to solve this problem, in this study, combining the interpolation function of NMM, the Numerical Manifold Method based on finite deformation theory is deduced from integral weak form of the momentum conservation equation and the stress boundary conditions. The comparison between the iteration schemes of original NMM and improved NMM points out the sources of error calculated by original NMM for the large deformation problem. Finally, examples of large deformation cantilever and rotation block are employed to exam the improved NMM. The numerical result shows that the improved NMM handles the problem involving in large deformation and large rotation very well. The result calculated by the improved NMM eliminates the errors caused by rotation of structure and is coincide with the analytical solution and Abaqus numerical solution very well.
- numerical manifold method /
- finite deformation /
- large rotation

HTML全文

参考文献(17)

Shi GH. Manifold method of material analysis. In: Transactions of the Ninth Army Conference on Applied Mathematics and Computing, Minnesoda, USA, 1991. 51-76

Shi GH. Modeling of rock joints and blocks by manifold method. In: Proc. of the 32rd U.S. Symp. On Rock Mechanics. Sanata Fe. New Mexico, 1992. 639-648

Shi GH. Manifold method. In: Proc. of the 1st Int. Forum on DDA Simulation of Discontinuous Media. Bekerley, california, USA. 1996. 52-204

Chiou YJ,Tsay RJ,Chuang WL. Crack propagation using manifold method. In: Proceedings of the 2nd International Conference on Analysis of Discontinuous Deformation,Kyoto,Japan,1997. 298-308

Tsay RJ,Chiou YJ,Chuang WL. Crack growth prediction by manifold method. Journal of Engineering Mechanics,1999,125(8):884-890

Chiou YJ,Lee YM,Tsay RJ. Mixed mode fracture propagation by manifold method. International Journal of Fracture,2002,114:327-347

Wu ZJ,Louis N, Yuen W. Frictional crack initiation and propagation analysis using the numerical manifold method. Computers and Geotechnics,2012,39:38-53

Zhang HH,Li LX, An XM, et al. Numerical analysis of 2-D crack propagation problems using the numerical manifold method. Engineering Analysis with Boundary Element,2010,34:41-50

姜清辉,王书法. 锚固岩体的三维数值流形方法. 岩石力学与工程学报,2006,25(3):528-532 (Jiang Qinghui, Wang Shufa. Three-dimensional numerical manifold method simulation of anchor bolt-supported rock mass.it Chinese Journal of Rock Mechanics and Engineering,2006, 25(3): 528-532 (in Chinese))

焦健,乔春生,徐干成. 开挖模拟在数值流形方法中的实现. 岩土力学,2010,31(9): 2951-2957. (Jiao Jian, Qiao Chunsheng, Xu Gancheng. Simulation of excavation in numerical manifold method. Rock and Soil Mechanics,2010, 31(9): 2951-2957 (in Chinese))

Ohnishi Y,Tanaka M,Koyama T. Manifold method in saturated-unsaturated groundwater flow analysis. In: Proceedings of the 3rd International Conference on Analysis of Discontinuous Deformation,Vail,USA,1999

Jiang QH,Deng SS,Zhou CB. Modeling unconfined seepage flow using three-dimensional numerical manifold method. Journal of Hydrodynamics,2010,22(4):554-561

王芝银,王思敬,杨志法. 岩石大变形分析的流形方法. 岩石力学与工程学报. 1997, 16(5):399-404 (Wang Zhiyin, Wang Sijing, Yang Zhifa. Manifold method in analysis of large deformation for rock. Chinese Journal of Rock Mechanics and Engineering, 1997, 16(5):399-404 (in Chinese))

朱以文,曾又林. 岩石大变形分析的增量流形方法. 岩石力学与工程学报,1999,18(1):1-5 (Zhu Yiwen, Zeng Youlin, Chen Mingxiang. Incremental manifold method in analysis of large deformation for rock. Chinese Journal of Rock Mechanics and Engineering, 1999,18(1):1-5 (in Chinese))

林兴超, 汪小刚, 王玉杰. 数值流形法中“质量守恒”的探讨. 岩土力学,2011, 32(10): 3065-3070 (Lin Xingchao, Wang Xiaogang, Wang Yujie. Discussion on “mass conservation” in numerical manifold method. Rock and Soil Mechanics,2011, 32(10): 3065-3070 (in Chinese))

Holden JT. On the finite deflections of thin beams. Int J Solids Structures,1972,8:1051-1055

高亚楠,高峰, Yeung MR等, 基于有限变形理论的非连续变形分析方法改进. 岩石力学与工程学报.2011, 30(11): 2360-2365 (Gao Yanan,Gao Feng, Yeung MR, et al. Modification of discontinuous deformation analysis method based on finite deformation theory. Chinese Journal of Rock Mechanics and Engineering, 2011, 30(11): 2360-2365 (in Chinese))
