绕振荡水翼流动及其转捩特性的数值计算研究

吴钦; 王国玉; 黄彪

doi:10.6052/0459-1879-13-080

绕振荡水翼流动及其转捩特性的数值计算研究

doi: 10.6052/0459-1879-13-080

北京理工大学机械与车辆学院, 北京100081

基金项目: 国家自然科学基金资助项目（11172040,51239005）.

详细信息

作者简介:
王国玉，教授，主要研究方向：流体机械及空化理论研究.

中图分类号: O357.5
计量
- 文章访问数: 769
- HTML全文浏览量: 21
- PDF下载量: 1202
- 被引次数: 0
出版历程
- 收稿日期: 2013-03-09
- 修回日期: 2013-04-19
- 刊出日期: 2014-01-18

NUMERICAL METHODS AND TRANSITION INVESTIGATION OF TRANSIENT FLOWS AROUND A PITCHING HYDROFOIL

School of Mechanical and Vehicular Engineering, Beijing Institute of Technology, Beijing 100081, China

Funds: The project was supported by the National Natural Science Foundation of China (11172040, 51239005).

摘要

摘要: 通过对比标准k-ω SST 湍流模型和基于标准k-ω SST 湍流模型修正的γ-Re_θ 转捩湍流模型对绕振荡NACA66 水翼流动的数值计算结果与实验结果，对水翼振荡过程的水动力特性和流场结构变化进行了分析研究. 结果表明：与标准k-ω SST 湍流模型的数值计算结果相比，基于标准k-ω SST 湍流模型修正的γ-Re_θ 转捩湍流模型能有效预测绕振荡翼型流场结构和水动力特性，捕捉流场边界层发生的流动分离和转捩现象；绕振荡水翼的流动过程可分为5 个特征阶段，当来流攻角较小时，在水翼前缘发生层流向湍流的转捩现象，水翼动力特征曲线出现变化拐点；随着来流攻角的增大，顺时针尾缘涡逐渐形成并向水翼前缘发展；当攻角较大时，前缘涡分离导致动力失速，水翼的动力特征曲线出现大幅波动；水翼处于顺时针向下旋转阶段，绕水翼的流动状态逐渐由湍流过渡为层流.
- 振荡水翼 /
- 数值计算 /
- 转捩特性
Abstract: In order to investigate the numerical method for transient flows around a pitching hydrofoil, the numerical simulations for a NACA66 hydrofoil are performed by using the standard k-ω SST turbulence model and revised γ-Re_θ transition model respectively. The simulation results are compared with the experimental results, and the hydrodynamic property and the fluid structure during the pitching process are studied. It is revealed that, compared with the standard k-ω SST turbulence model, the revised -Re transition model is able to present the hydrodynamic property and the fluid structure of the transient flow around a pitching hydrofoil more accurately, and better predict the separation and transition process in the boundary layer. The transient flow process around a pitching hydrofoil can be divided into 5 parts. At small angle of attack, transition is observed at the leading edge of the foil, resulting in the inflection of dynamic property curves. As the angle of attack increases, a clockwise trailing edge vortex expands toward the leading edge of the foil. At high angles of attack, large-scale load fluctuations are observed due to the stall caused by separation of the leading edge vortex. The transition from turbulent flow to laminar flow occurs during the downward pitching process.
- pitching hydrofoil /
- numerical simulation /
- transition property

HTML全文

参考文献(17)

McCroskey WJ. Unsteady airfoils. Annual Review of Fluid Mechanics, 1982, 14: 285-311

Lee T, Gerontakos P. Investigate of flow over an oscillating airfoil. Journal of Fluid Mechanics, 2004, 512: 313-341

Akcabay DT, Young YL. Hydroelastic response and energy harvesting potential of flexible piezoelectric beams in viscous flow. Physics of Fluids, 2012, 24: 054106

Ducoin A, Young YL. Hydroelastic response and stability of a hydrofoil in viscous flow. Journal of Fluids Structure, 2013, 38: 40-57

Liu Z, Young YL. Performance-based design and analysis of flexible composite propulsors. Journal of Fluids Structure, 2011, 27: 1310-1325

Huang Biao, Ducoin A, Young YL. Evaluation of cavitation models for prediction of transient cavitating flows around a pitching hydrofoil. The 8th International Symposium on Cavitation, Singapor, 13-16, August, 2012

Ducoin A, Astolfi JA, Deniset F, et al. Computational and experimental investigation of flow over a transient pitching hydrofoil. European Journal of Mechanics/B Fluids , 2009, 28(6): 728-743

Langtry RB, Menter FR. A correlation-based transition model using local variables-Part I: Model Formulation. Journal of Turbomachinery , 2006, 128: 413-422

Smith AMO, Gamberoni N. Transition, pressure gradient and stability theory. Douglas Aircraft Company, Long Beach, California Rep. ES26388, 1956

Abu-ghannam BJ, Shaw R. Natural transition of boundary layers-the effects of turbulence, pressure gradient, and flow history. Journal of Mechanical Engineering Science, 1980, 22(5): 213-228

Suzen YB, Xiong G, Huang PG. Predictions of transitional flows in low-pressure turbines using an intermittency transport equation. AIAA Journal, 2000, 40(2): 254-266

Steelant J, Dick E. Modeling of laminar-turbulent transitional for high freestream turbulence. Journal of Fluids Engineering, 2001, 123: 22-30

Langtry RB, Menter FR. Transition Modeling for General CFD Applications in Aeronautics, AIAA Paper 2005-522, Reno, Nevada, 2005

Menter F R, Langtry R, Völker, S. Transition modeling for general purpose CFD codes. Flow, Turbulence and Combustion, 2006, 77(1): 277-303.

董平,黄洪雁,冯国泰. 带有压力梯度的平板边界层转捩数值模拟. 航空动力学报, 2007, 22(11): 1909-1914 (Dong Ping, Huang Hongyan, Feng Guotai. Numerical simulation of boundary layer transition under pressure gradient. JoumaI of Aerospace Power, 2007, 22(11): 1909-1914 (in Chinese))

罗华玲, 乔渭阳, 许开富. 基于转捩模型的涡轮流场及性能数值模拟. 西北工业大学学报,2007,25(6): 778-783 (Luo Hualing, Qiao Weiyang, Xu Kaifu. Calculating Reynolds number effects on the dynamic performance of turbine based on transition model. Journal of Northwestern Polytechnical University , 2007,25(6): 778-783 (in Chinese))

Ducoin A. Etude experimentale et numerique du chargement hydrodynamique des corps portants en regime transitoire avec prise en compte du couplage fluide structure. [PhD Thesis]. Institut de Recherche de l'École Navale, Lanvéoc Poulmic, Ecole Centrale de Nantes, France, 2008
