矩形通道高宽比对单相层流特性的影响

幸奠川; 阎昌琪; 王畅; 孙立成

doi:10.6052/0459-1879-12-246

矩形通道高宽比对单相层流特性的影响

doi: 10.6052/0459-1879-12-246

幸奠川^1, ,,
阎昌琪¹,
王畅^1,2,
孙立成¹

1.
哈尔滨工程大学核安全与仿真技术国防重点学科实验室, 哈尔滨150001
2. 中国舰船研究设计中心, 武汉430064

基金项目: 国家自然科学基金资助项目(11175050,51076034).

详细信息

通讯作者:
幸奠川,博士研究生,主要研究方向:核反应堆热工水力学及气液两相流阻力.E-mail:spiderxdc@126.com

中图分类号: TL334
计量
- 文章访问数: 1996
- HTML全文浏览量: 51
- PDF下载量: 1265
- 被引次数: 0
出版历程
- 收稿日期: 2012-09-10
- 修回日期: 2012-12-17
- 刊出日期: 2013-05-18

EFFECTS OF ASPECT RATIO OF RECTANGULAR CHANNEL ON CHARACTERISTICS OF SINGLE-PHASE LAMINAR FLOW

1.
National Defense Key Subject Laboratory for Nuclear Safety and Simulation Technology, Harbin Engineering University, Harbin 150001, China
2. China Ship Development and Design Center, Wuhan 430064, China

Funds: The project was supported by the National Natural Science Foundation of China (11175050, 51076034).

摘要

摘要: 通过分析壁面切应力,比较了不同高宽比矩形通道宽边和窄边壁面摩擦阻力特性. 结果表明宽边摩擦阻力随高宽比的减小而急剧增加;窄边摩擦阻力变化趋势与宽边相反,但变化幅度比宽边小;总摩擦阻力随高宽比的减小而增大. 宽边摩擦阻力占总摩擦阻力的份额随高宽比的增加而减小,且高宽比越大,变化速率越慢. 高宽比对窄边局部切应力的影响很小,对宽边局部切应力的大小和分布形状均有明显影响. 采用能量梯度法,对不同高宽比矩形通道内单相层流-湍流转捩雷诺数进行求解,并将理论计算结果整理成多项式,其预测值和实验值有很好的一致性.
- 高宽比 /
- 摩擦阻力 /
- 层流 /
- 能量梯度法 /
- 转捩雷诺数
Abstract: The frictional resistances for wide side and narrow side of rectangular channels with different aspect ratios are compared, by analyzing the wall shear stress. The results show that the frictional resistance of the wide side increases sharply as the aspect ratio decrease, of which shows the reversed trend in a smaller range for the narrow side. Therefore the total frictional resistance increases with the decreasing of the aspect ratio. The frictional resistance proportion for wide side out of the total decreases as the aspect ratio increases, more slowly for the larger aspect ratio. The aspect ratio has remarkable influence on both the magnitude and the distribution type of shear stress for wide side, whereas, it has limited influence on shear stress for narrow side. Additionally, the transition Reynolds number of laminar to turbulent flow is calculated by energy gradient method and a polynomial correlation is achieved. The predicted results show good agreement with the experimental data.
- aspect ratio /
- frictional resistance /
- laminar flow /
- energy gradient method /
- transition Reynolds number

HTML全文

参考文献(17)

Shah RK, London AL. Laminar Flow Forced Convection in Ducts: A Source Book for Compact Heat Exchanger Analytical Data. New York: Academic Press, 1978

Ma YG, Ji XY, Wang DJ, et al. Measurement and correlation of pressure drop for gas-liquid two-phase flow in rectangular microchannels. Chin J Chem Eng, 2010, 18(6): 940-947

Mishima K, Hibiki T, Nishihara H. Some characteristics of gas-liquid flow in narrow rectangular ducts. Int J Multiphase Flow, 1993, 19(1): 115-124

Lee HJ, Lee SY. Pressure drop correlations for two-phase flow within horizontal rectangular channels with small heights. Int J Multiphase Flow, 2001, 27(5): 783-796

Agostini B, Watel B, Bontemps A, et al. Friction factor and heat transfer coefficient of R134a liquid flow in mini-ducts. Appl Thermal Eng, 2002, 22(16): 1821-1834

Hrnjak P, Tu X. Single phase pressure drop in microchannels. Int J Heat Fluid Flow, 2007, 28(1): 2-14

Ma J, Li LJ, Huang YP, et al. Experimental studies on single-phase flow and heat transfer in a narrow rectangular channel. Nucl Eng Des, 2011, 241(8): 2865-2873

Soupremanien U, Le Person S, Favre-Marinet M, et al. Influence of the aspect ratio on boiling flows in rectangular mini-channels. Exp Thermal Fluid Sci, 2011, 35(5): 797-809

Chen IY, Chen Y, Liaw J, et al. Two-phase frictional pressure drop in small rectangular channels. Exp Thermal Fluid Sci, 2007, 29(7): 1309-1318

幸奠川,阎昌琪,曹夏昕等.矩形窄缝通道内单相水流动特性研究.原子能科学技术,2011,45(11):1312-1316 (Xing Dianchuan, Yan Changqi, Cao Xiaxin, et al. Research on characteristics of single-phase water flow in narrow rectangular channel. Atomic Energy Sci Techn, 2011, 45(11): 1312-1316 (in Chinese))

王畅,高璞珍,谭思超等. 窄通道内层流!-!紊流转捩区流动与传热特性分析. 哈尔滨工程大学学报,2012,33(4): 0528-0533 (Wang Chang, Gao Puzhen, Tan Sichao, et al. Study of the flow and heat transfer characteristics in the laminar-turbulent transition region of a narrow channel. J Harbin Eng University, 2012,33(4): 0528-0533 (in Chinese))

徐建军,陈炳德,王小军等. 矩形窄缝流到内窄边附近流场的实验研究和数值模拟. 水动力学研究与进展,A辑,2006,21(6): 770-775 (Xu Jianjun, Chen Bingde, Wang Xiaojun, et al. Experimental research and numerical simulation of flow field near the narrow side in a rectangular narrow channel. J Hydrodynamics, Ser, A, 2006,21(6): 770-775 (in Chinese))

徐建军,陈炳德,王小军. 矩形窄缝通道内湍流充分发展区流动边界层探析. 核动力工程,2011,32(1): 95-99 (Xu Jianjun, Chen Bingde, Wang Xiaojun. Analysis and discussion of flow boundary layer in fully turbulent of narrow rectangular channel. Nucl. Power Eng., 2011,32(1): 95-99 (in Chinese))

唐大伟,张春平,曲伟. 矩形微通道内流长的可视化实验研究. 华中科技大学学报(自然科学版),2007,35(11): 24-27 (Tan Dawei, Zhang Chunping, Qu Wei. Visualization experiments of the flow field in rectangular microchannels. J Huazhong Univ Sci Tech (Nature Sci Edition), 2007,35(11): 24-27 (in Chinese))

Dou HS. Mechanism of flow instability and transition to turbulence. Int J Non-Linear Mech, 2006, 41(4): 512-517

Dou HS, Khoo BC. Energy gradient method for turbulent transition with consideration of effect of disturbance frequency. J Hydrodynamics, Ser, B, 2010, 22(5): 23-28

Dou HS, Khoo BC, Tsai HM. Determining the critical condition for turbulent transition in a full-developed annulus flow. J Petrol Sci Eng, 2010, 73 (1-2): 41-47
