钝头体高超声速绕流底部失稳特征数值模拟

朱德华, 沈清, 王强, 袁湘江

朱德华, 沈清, 王强, 袁湘江. 钝头体高超声速绕流底部失稳特征数值模拟[J]. 力学学报, 2012, (3): 465-472. DOI: 10.6052/0459-1879-2012-3-20120301
引用本文: 朱德华, 沈清, 王强, 袁湘江. 钝头体高超声速绕流底部失稳特征数值模拟[J]. 力学学报, 2012, (3): 465-472. DOI: 10.6052/0459-1879-2012-3-20120301
Zhu Dehua, Shen Qing, Wang Qiang, Yuan Xiangjiang. NUMERICAL STUDY OF THE STABILITY OF HYPERSONIC BASE FLOW OVER A BLUNT BODY AND APOLLO COMMAND MODULE[J]. Chinese Journal of Theoretical and Applied Mechanics, 2012, (3): 465-472. DOI: 10.6052/0459-1879-2012-3-20120301
Citation: Zhu Dehua, Shen Qing, Wang Qiang, Yuan Xiangjiang. NUMERICAL STUDY OF THE STABILITY OF HYPERSONIC BASE FLOW OVER A BLUNT BODY AND APOLLO COMMAND MODULE[J]. Chinese Journal of Theoretical and Applied Mechanics, 2012, (3): 465-472. DOI: 10.6052/0459-1879-2012-3-20120301
朱德华, 沈清, 王强, 袁湘江. 钝头体高超声速绕流底部失稳特征数值模拟[J]. 力学学报, 2012, (3): 465-472. CSTR: 32045.14.0459-1879-2012-3-20120301
引用本文: 朱德华, 沈清, 王强, 袁湘江. 钝头体高超声速绕流底部失稳特征数值模拟[J]. 力学学报, 2012, (3): 465-472. CSTR: 32045.14.0459-1879-2012-3-20120301
Zhu Dehua, Shen Qing, Wang Qiang, Yuan Xiangjiang. NUMERICAL STUDY OF THE STABILITY OF HYPERSONIC BASE FLOW OVER A BLUNT BODY AND APOLLO COMMAND MODULE[J]. Chinese Journal of Theoretical and Applied Mechanics, 2012, (3): 465-472. CSTR: 32045.14.0459-1879-2012-3-20120301
Citation: Zhu Dehua, Shen Qing, Wang Qiang, Yuan Xiangjiang. NUMERICAL STUDY OF THE STABILITY OF HYPERSONIC BASE FLOW OVER A BLUNT BODY AND APOLLO COMMAND MODULE[J]. Chinese Journal of Theoretical and Applied Mechanics, 2012, (3): 465-472. CSTR: 32045.14.0459-1879-2012-3-20120301

钝头体高超声速绕流底部失稳特征数值模拟

详细信息
  • 中图分类号: O354.4

NUMERICAL STUDY OF THE STABILITY OF HYPERSONIC BASE FLOW OVER A BLUNT BODY AND APOLLO COMMAND MODULE

  • 摘要: 利用数值模拟方法对高超声速钝锥及Apollo返回舱底部尾迹流场进行了研究, 分析尾迹流动的失稳过程. 对钝锥模型, 在M=6, Re=1.71× 106(Re以球头半径为参考长度)条件下观察到了底部流动的不稳定性. 不添加任何扰动, 数值模拟首先得到的流动是稳定解, 在底部发展出一个主分离区和一个二次分离区, 流动是轴对称状态. 继续进行计算, 发现二次分离线率先变形, 底部流场发展出非定常周期流动. 对Apollo返回舱模型, 在相同条件下 (Re以前面圆弧半径为参考长度), 数值模拟首先得到的流动同样是稳定解, 出现以二次分离线率先变形为起始的结构失稳, 演化出周期性过程, 但持续时间较短, 很快出现了非周期非对称状态. 研究表明, 高超声速钝锥及Apollo返回舱底部流场均存在不稳定性问题, Apollo返回舱的底部流场更加不稳定.
    Abstract: The structural instabilities of base flow are presented by using numerical simulation in this paper in hypersonic base flow over blunt cone with M=6, Re=1.71× 106(based on the nose radius) and Apollo command module with M=6, Re=1.71 × 106(based on the nose radius). Stable solutions are first obtained to show a primary separation and a secondary separation zone in flow over blunt body at M=6. Later, without any arbitrary disturbance imposed, the structural instability still occurs after a certain critical time. The evolving process of the structure of flow over blunt body is a periodic behavior in the forepart, but there is non-periodic behavior observed at M=6 in spite of long calculation time. For Apollo command module, the simulation result is similar to that of the blunt body, while the base flow of Apollo command is more instability than that of blunt cone. This research indicates that the present numerical simulation method can be used for the study of the stability of base flow.
  • Taneda S. Experimental investigation of the wake behind a sphere at low Reynolds numbers. Journal of the Physical Society of Japan, 1956, 11(10): 1104-1108  " target=_blank>
    Magavery RH, Bishop RL. Transition ranges for three-dimensional wakes. Canadian Journal of Physics, 1961, 39: 1418-1422  " target=_blank>
    Sakamoto H, Haniu H. The formation mechanism and shedding frequency of vortices from a sphere in uniform shear flow. Journal of Fluid Mechanics, 1995, 287: 151-171  " target=_blank>
    Moseley Jr WC, Graham RE, Hughes JE. Aerodynamic stability characteristics of the Apollo command module. NASA TN D-4688
    Lyons Jr WC, Brady JJ, Levensteins ZJ. et al. Stability, and wake data for cones and spheres. AIAA Preprint No. 64-44, Sep, 1964
    Nishio M, Nakamura H. Wake stabilization time in a hypersonic pulsed facility. AIAA 2004-2640, 2004
    Danehy PM, Wilkes JA, Alderfer DW, et al. Planar laser-induced fluorescence (PLIF) investigation of hypersonic flowfields in a Mach 10 wind tunnel (invited). AIAA 2006-344, 2006
    沈清, 朱德华.高超声速尾迹流场稳定性数值研究.力学学报, 2009, 41(1): 1-7 (Shen Qing, Zhu Dehua. Numerical study of the stability of hypersonic wake. Chinese Journal of Theoretical and Applied Mechanics, 2009, 41(1): 1-7 (in Chinese))
    Shen Q, Zhuang FG, Guan FM. Numerical simulation on a planar supersonic free shear layer secondary instability. AIAA 2006-3351, 2006
    沈清.三维复杂高超声速黏性流场的数值模拟. [博士论文]. 绵阳: 中国空气动力研究与发展中心, 1991 (Shen Qing. Numerical simulation of three-dimensional complex hypersonic viscous flows. [PhD Thesis]. Mianyang: China Aerodynamics Research and Development Center, 1991 (in Chinese))
