撞击载荷下数字电子散斑离面位移的测试研究1）
A STUDY OF MEASURING OUT OFF PLANE DISPLACEMENT USING DSPI UNDER IMPACT LOADING
-
摘要: 采用瞬态光学图像采集技术，实现了动态数字散斑干涉（ＤＳＰＩ）．以周边固支圆板受法向撞击集中载荷为例，对其离面位移场进行了测试．实验值与动有限元计算结果比较，两者是比较接近的
-
关键词:
- 红宝石脉冲激光器 /
- 瞬态光学图像采集技术 /
- 动态数字散斑干涉 /
- 动有限元
Abstract: The dynamic digital speckle pattern interferometry(DSPI) has been achieved by using the instantaneous image capturing technique. The measurement of out of plane displacement field of circular restrained plate with a cross point impact loading is completed. The results of dynamic finite element method show good agreement with those of experiments. -
