褶皱与晶界耦合作用对石墨烯断裂行为的影响

任云鹏, 曹国鑫

任云鹏, 曹国鑫. 褶皱与晶界耦合作用对石墨烯断裂行为的影响[J]. 力学学报, 2019, 51(5): 1381-1392. DOI: 10.6052/0459-1879-19-181
引用本文: 任云鹏, 曹国鑫. 褶皱与晶界耦合作用对石墨烯断裂行为的影响[J]. 力学学报, 2019, 51(5): 1381-1392. DOI: 10.6052/0459-1879-19-181
Ren Yunpeng, Cao Guoxin. COUPLING EFFECTS OF WRINKLES AND GRAIN BOUNDARY ON THE FRACTURE OF GRAPHENE[J]. Chinese Journal of Theoretical and Applied Mechanics, 2019, 51(5): 1381-1392. DOI: 10.6052/0459-1879-19-181
Citation: Ren Yunpeng, Cao Guoxin. COUPLING EFFECTS OF WRINKLES AND GRAIN BOUNDARY ON THE FRACTURE OF GRAPHENE[J]. Chinese Journal of Theoretical and Applied Mechanics, 2019, 51(5): 1381-1392. DOI: 10.6052/0459-1879-19-181
任云鹏, 曹国鑫. 褶皱与晶界耦合作用对石墨烯断裂行为的影响[J]. 力学学报, 2019, 51(5): 1381-1392. CSTR: 32045.14.0459-1879-19-181
引用本文: 任云鹏, 曹国鑫. 褶皱与晶界耦合作用对石墨烯断裂行为的影响[J]. 力学学报, 2019, 51(5): 1381-1392. CSTR: 32045.14.0459-1879-19-181
Ren Yunpeng, Cao Guoxin. COUPLING EFFECTS OF WRINKLES AND GRAIN BOUNDARY ON THE FRACTURE OF GRAPHENE[J]. Chinese Journal of Theoretical and Applied Mechanics, 2019, 51(5): 1381-1392. CSTR: 32045.14.0459-1879-19-181
Citation: Ren Yunpeng, Cao Guoxin. COUPLING EFFECTS OF WRINKLES AND GRAIN BOUNDARY ON THE FRACTURE OF GRAPHENE[J]. Chinese Journal of Theoretical and Applied Mechanics, 2019, 51(5): 1381-1392. CSTR: 32045.14.0459-1879-19-181

褶皱与晶界耦合作用对石墨烯断裂行为的影响

基金项目: 1)科学技术部基金(2015GB113000);国家自然科学基金资助项目(11972258)
详细信息
    通讯作者:

    曹国鑫

  • 中图分类号: TB383.1

COUPLING EFFECTS OF WRINKLES AND GRAIN BOUNDARY ON THE FRACTURE OF GRAPHENE

  • 摘要: 由CVD方法制备的石墨烯含有大量的晶界,通常还带有许多褶皱,本文通过分子动力学方法研究了具有褶皱和晶界的石墨烯 平面拉伸断裂行为,结果显示,在垂直晶界方向,褶皱能够显著提高小角度双晶石墨烯的断裂应力,断裂应力增幅最 大约为50%,褶皱对断裂应力的影响随晶界角的增大减弱,导致双晶石墨烯断裂应力对晶界角不敏感,只略低于单晶石墨 烯,和实验结果完全吻合;在沿晶界方向,褶皱对双晶石墨烯断裂应力影响不明显. 另外,褶皱可以显著提高双晶石墨烯的断 裂应变,增幅最大约为100%. 增强机制归纳主要如下:通过面外变形,褶皱可以部分释放晶界5-7环中C---C键的预拉伸变形, 提高双晶石墨烯的断裂应力;褶皱可以降低相邻5-7环之间相互作用,导致断裂应力对晶界角不敏感;在拉伸作用下,褶皱被部分 拉平,这可以显著降低C---C键面内拉伸变形,导致断裂应变显著增大. 本研究为准确理解多晶石墨烯断裂行为提供重要帮助.
    Abstract: Graphene fabricated via chemical vapor deposition (CVD) is typically polycrystalline and also includes many wrinkles. The fracture of the polycrystalline graphene with wrinkles under an uniaxial tensile load is investigated via molecular dynamics simulations. With a tensile load perpendicular to the grain boundary, wrinkles can significantly increase the failure stress of bi-crystalline graphene with a small tilt angle, and the increase in the failure stress is up to around 50%. The wrinkle effect on the failure stress decreases with the increase of the tilt angle, resulting in that the failure stress of bi-crystalline graphene is insensitive to the tilt angle and slightly lower than that of pristine graphene, which agrees with the experimental results very well. With a tensile load along the grain boundary, the failure stress is insensitive to the wrinkle. In addition, wrinkles can significantly increase the failure strain, up to 100%. The influence mechanism can be described as follows: wrinkles will cause the out-of-plane deformation in graphene, resulting a partial release of the tensile pre-stress induced via the 5-7 rings of the grain boundary and consequently an increase in the failure stress of bi-crystalline graphene; the interaction between 5-7 rings of the grain boundary is eliminated, resulting that the failure stress is insensitive to the tilt angle; the flattening of wrinkles can significantly decrease the stretching ratio of C---C bonds, resulting an obvious increase in the failure strain. The present study provides a useful help to understand the fracture of graphene.
  • [1] Li LK, Yu YJ, Ye GJ , et al. Black phosphorus field-effect transistors. Nature Nanotechnology, 2014,9:372-377
    [2] Radisavljevic B, Radenovic A, Brivio J , et al. Single-layer MoS$_{2}$transistors. Nature Nanotechnology, 2011,6:147-150
    [3] Schwierz F . Graphene transistors. Nature Nanotechnology, 2010,5:487-496
    [4] Eda G, Fanchini G, Chhowalla M . Large-area ultrathin films of reduced graphene oxide as a transparent and flexible electronic material. Nature Nanotechnology, 2008,3:270-274
    [5] Georgiou T, Jalil R, Belle BD , et al. Vertical field-effect transistor based on graphene-WS2 heterostructures for flexible and transparent electronics. Nature Nanotechnology, 2013,8:100-103
    [6] Zhang L, Liu WW, Yue CG , et al. A tough graphene nanosheet/ hydroxyapatite composite with improved in vitro biocompatibility. Carbon, 2013,61:105-115
    [7] Rafiee MA, Rafiee J, Wang Z , et al. Enhanced mechanical properties of nanocomposites at low graphene content. ACS Nano, 2009,3:3884-3890
    [8] Vadukumpully S, Paul J, Mahanta N , et al. Flexible conductive graphene/poly(vinyl chloride) composite thin films with high mechanical strength and thermal stability. Carbon, 2011,49:198-205
    [9] Yu QK, Lian J, Siriponglert S , et al. Graphene segregated on Ni surfaces and transferred to insulators. Applied Physics Letters, 2008,93(11):113103
    [10] Reina A, Jia XT, Ho J , et al. Large Area, Few-layer graphene films on arbitrary substrates by chemical vapor deposition. Nano Letters, 2009,9:30-35
    [11] Novoselov KS, Geim AK, Morozov SV , et al. Electric field effect in atomically thin carbon films. Science, 2004,306:666-669
    [12] Lee GH, Cooper RC, An SJ , et al. High-strength chemical-vapor deposited graphene and grain boundaries. Science, 2013,340:1073-1076
    [13] Yazyev OV, Louie SG . Electronic transport in polycrystalline graphene. Nat Mater, 2010,9:806-809
    [14] Song ZG, Artyukhov VI, Yakobson BI , et al. Pseudo hall-petch strength reduction in polycrystalline graphene. Nano Letters, 2013,13:1829-1833
    [15] Rasool HI, Ophus C, Klug WS , et al. Measurement of the intrinsic strength of crystalline and polycrystalline graphene. Nat Communication, 2013,4:2811
    [16] Konakov YV , Ovid'ko IA, Sheinerman AG. Equilibrium dislocation structures at grain boundaries in subsurface areas of polycrystalline graphene and ultrafine-grained metals. Reviews on Advanced Materials Science, 2014,37:83-89
    [17] Huang PY , Ruiz-Vargas CS, van der Zande AM, et al. Grains and grain boundaries in single-layer graphene atomic patchwork quilts. Nature, 2011,469:389
    [18] Ruiz-Vargas CS, Zhuang HLL, Huang PY , et al. Softened elastic response and unzipping in chemical vapor deposition graphene membranes. Nano Letters, 2011,11:2259-2263
    [19] Zhang T, Li X, Gao H . Fracture of graphene: A review. International Journal of Fracture, 2015,196:1-31
    [20] Akinwande D, Brennan CJ, Bunch JS , et al. A review on mechanics and mechanical properties of 2D materials---Graphene and beyond. Extreme Mechanics Letters, 2017,13:42-77
    [21] Cao G, Gao H . Mechanical properties characterization of two-dimensional materials via nanoindentation experiments. Progress in Materials Science, 2019,103:558-595
    [22] Ren Y, Cao G . Adhesive boundary effect on free-standing indentation characterization of chemical vapor deposition graphene. Carbon, 2019,153:438-446
    [23] Lee C, Wei XD, Kysar JW , et al. Measurement of the elastic properties and intrinsic strength of monolayer graphene. Science, 2008,321:385-388
    [24] Cao GX . Atomistic studies of mechanical properties of graphene. Polymers, 2014,6:2404-2432
    [25] Zhou L, Cao G . Nonlinear anisotropic deformation behavior of a graphene monolayer under uniaxial tension. Phys Chem Chem Phys, 2016,18:1657-1664
    [26] Rasool HI, Ophus C, Klug WS , et al. Measurement of the intrinsic strength of crystalline and polycrystalline graphene. Nature Communications, 2013,4:2811
    [27] Han J, Pugno NM, Ryu S . Nanoindentation cannot accurately predict the tensile strength of graphene or other 2D materials. Nanoscale, 2015,7:15672-15679
    [28] Kim K, Lee Z, Regan W , et al. Grain boundary mapping in polycrystalline graphene. ACS Nano, 2011,5:2142-2146
    [29] Grantab R, Shenoy VB, Ruoff RS . Anomalous strength characteristics of tilt grain boundaries in graphene. Science, 2010,330:946-948
    [30] Wei YJ, Wu JT, Yin HQ , et al. The nature of strength enhancement and weakening by pentagon-heptagon defects in graphene. Nat Mater, 2012,11:759-763
    [31] Liu TH, Pao CW, Chang CC . Effects of dislocation densities and distributions on graphene grain boundary failure strengths from atomistic simulations. Carbon, 2012,50:3465-3472
    [32] Han J, Ryu S, Sohn D , et al. Mechanical strength characteristics of asymmetric tilt grain boundaries in graphene. Carbon, 2014,68:250-257
    [33] Wu JT, Wei YJ . Grain misorientation and grain-boundary rotation dependent mechanical properties in polycrystalline graphene. Journal of the Mechanics and Physics of Solids, 2013,61(6):1421-1432
    [34] Jhon YI, Zhu SE, Ahn JH , et al. The mechanical responses of tilted and non-tilted grain boundaries in graphene. Carbon, 2012,50:3708-3716
    [35] Zhang JF, Zhao JJ, Lu JP . Intrinsic strength and failure behaviors of graphene grain boundaries. ACS Nano, 2012,6:2704-2711
    [36] Zhang T, Li XY, Kadkhodaei S , et al. Flaw insensitive fracture in nanocrystalline graphene. Nano Letters, 2012,12:4605-4610
    [37] Lehtinen O, Kurasch S, Krasheninnikov AV , et al. Atomic scale study of the life cycle of a dislocation in graphene from birth to annihilation. Nat Communication, 2013,4:1-7
    [38] Teng Z, Li X, Gao H . Designing graphene structures with controlled distributions of topological defects: A case study of toughness enhancement in graphene ruga. Extreme Mechanics Letters, 2014,1:3-8
    [39] Warner JH, Margine ER, Mukai M , et al. Dislocation-driven deformations in graphene. Science, 2012,337:209-212
    [40] Ren Y, Cao G . Effect of geometrical defects on the tensile properties of graphene. Carbon, 2016,103:125-133
    [41] Plimpton S . Fast parallel algorithms for short-range molecular-dynamics. Journal of Computational Physics, 1995,117:1-19
    [42] Stuart SJ, Tutein AB, Harrison JA . A reactive potential for hydrocarbons with intermolecular interactions. Journal of Chemical Physics, 2000,112:6472-6486
    [43] Zhao H, Min K, Aluru NR . Size and chirality dependent elastic properties of graphene nanoribbons under uniaxial tension. Nano Letters, 2009,9:3012-3015
    [44] Shenderova OA, Brenner DW, Omeltchenko A , et al. Atomistic modeling of the fracture of polycrystalline diamond. Phys Rev B, 2000,61:3877-3888
