南海水合物黏土沉积物力学特性试验模拟研究

石要红, 张旭辉, 鲁晓兵, 王淑云, 王爱兰

石要红, 张旭辉, 鲁晓兵, 王淑云, 王爱兰. 南海水合物黏土沉积物力学特性试验模拟研究[J]. 力学学报, 2015, 47(3): 521-528. DOI: 10.6052/0459-1879-14-424
引用本文: 石要红, 张旭辉, 鲁晓兵, 王淑云, 王爱兰. 南海水合物黏土沉积物力学特性试验模拟研究[J]. 力学学报, 2015, 47(3): 521-528. DOI: 10.6052/0459-1879-14-424
Shi Yaohong, Zhang Xuhui, Lu Xiaobing, Wang Shuyun, Wang Ailan. EXPERIMENTAL STUDY ON THE STATIC MECHANICAL PROPERTIES OF HYDRATE-BEARING SILTY-CLAY IN THE SOUTH CHINA SEA[J]. Chinese Journal of Theoretical and Applied Mechanics, 2015, 47(3): 521-528. DOI: 10.6052/0459-1879-14-424
Citation: Shi Yaohong, Zhang Xuhui, Lu Xiaobing, Wang Shuyun, Wang Ailan. EXPERIMENTAL STUDY ON THE STATIC MECHANICAL PROPERTIES OF HYDRATE-BEARING SILTY-CLAY IN THE SOUTH CHINA SEA[J]. Chinese Journal of Theoretical and Applied Mechanics, 2015, 47(3): 521-528. DOI: 10.6052/0459-1879-14-424
石要红, 张旭辉, 鲁晓兵, 王淑云, 王爱兰. 南海水合物黏土沉积物力学特性试验模拟研究[J]. 力学学报, 2015, 47(3): 521-528. CSTR: 32045.14.0459-1879-14-424
引用本文: 石要红, 张旭辉, 鲁晓兵, 王淑云, 王爱兰. 南海水合物黏土沉积物力学特性试验模拟研究[J]. 力学学报, 2015, 47(3): 521-528. CSTR: 32045.14.0459-1879-14-424
Shi Yaohong, Zhang Xuhui, Lu Xiaobing, Wang Shuyun, Wang Ailan. EXPERIMENTAL STUDY ON THE STATIC MECHANICAL PROPERTIES OF HYDRATE-BEARING SILTY-CLAY IN THE SOUTH CHINA SEA[J]. Chinese Journal of Theoretical and Applied Mechanics, 2015, 47(3): 521-528. CSTR: 32045.14.0459-1879-14-424
Citation: Shi Yaohong, Zhang Xuhui, Lu Xiaobing, Wang Shuyun, Wang Ailan. EXPERIMENTAL STUDY ON THE STATIC MECHANICAL PROPERTIES OF HYDRATE-BEARING SILTY-CLAY IN THE SOUTH CHINA SEA[J]. Chinese Journal of Theoretical and Applied Mechanics, 2015, 47(3): 521-528. CSTR: 32045.14.0459-1879-14-424

南海水合物黏土沉积物力学特性试验模拟研究

基金项目: 国家自然科学基金(51239010,41376078,11102209)和中国地质调查局(GZH201100311)资助项目.
详细信息
    通讯作者:

    张旭辉,副研究员,主要研究方向:天然气水合物开采中的岩土力学问题研究.E-mail:zhangxuhui@imech.ac.cn

  • 中图分类号: TU411

EXPERIMENTAL STUDY ON THE STATIC MECHANICAL PROPERTIES OF HYDRATE-BEARING SILTY-CLAY IN THE SOUTH CHINA SEA

Funds: The project was supported by the National Natural Science Foundation of China (51239010, 41376078, 11102209) and China Geology Survey (GZH201100311).
  • 摘要: 利用自行研制的含水合物沉积物合成、分解与力学性质测量一体化试验设备,以南海水合物区域的海底粉质黏土作为骨架,制备含水合物沉积物样品,并对其进行了三轴压缩试验研究,获得了水合物分解前后的应力应变曲线和抗剪强度特性. 结果表明:在水合物饱和度0%~45% 的范围内,水合物沉积物的应力应变曲线均表现为弹塑性变形,存在明显的应变硬化现象;抗剪强度、内摩擦角和黏聚力随水合物饱和度的增加而增加. 相对而言,内摩擦角随饱和度增加幅度较小,其他参数在水合物饱和度超过25% 时,呈陡然增高趋势;水合物分解后导致抗剪强度最大可降低为初始的1/4,不同初始饱和度条件下水合物完全分解后沉积物的抗剪强度基本相等,并大于同等围压条件下初始不含水合物的沉积物抗剪强度.
    Abstract: By using an integrated experimental apparatus for syntheses of hydrate-bearing sediment (HBS) and tri-axial mechanical tests, a series of static tests were conducted on the silty-clay containing tetra-hydro-furan (THF) hydrate. The samples were prepared with the silty-clay obtained from the South China Sea where gas hydrate has been found. The stress-strain curves before and after hydrate dissociation and the strength parameters were obtained. It is shown that the hydrate-bearing silty-clay behaves as elastic-plastic failure and obvious strain hardening. The failure stress (the stress difference of the maximum and minimum stresses), internal friction angle and cohesion increase with the rise of hydrate saturation. The internal friction angle increases a little bit with the rise of hydrate saturation, while the other parameters increase rapidly once the hydrate saturation is over 25%, which is agreed well with the change of hydrate occurrence form in the pore of HBS. The dissociation of hydrate can cause the sediment's strength decrease to be 1/4 of the initial value. The strengths of the sediments after hydrate dissociation at different initial hydrate saturations are almost the same and larger than that of the sediment initially without hydrate.
  • Koh CA. Towards a fundamental understanding of natural gas hydrates. Chemical Society Reviews, 2002, 31: 157
    Kvenvolden KA, Lorenson TD. The global occurrence of natural gas hydrate. Geophysical Monograph, 2001, 124: 3-18
    张洪涛,张海启,祝有海.中国天然气水合物调查研究现状及其进展. 中国地质, 2007,34(6): 953-961 (Zhang Hongtao, Zhang Haiqi, Zhu Youhai. Gas hydrate investigation and research in China: Present status and progress. Geology in China, 2007,34(6): 953-961 (in Chinese))
    王淑云, 鲁晓兵. 水合物沉积物力学性质的研究现状. 力学进展, 2009, 39(2): 176-188 (Wang Shuyun, Lu Xiaobing. Advances of research on mechanical properties of gas hydrate deposits. Advances in Mechanics, 2009, 39(2): 176-188 (in Chinese))
    Winters WJ, Pecher IA, Waite WF, et al. Physical properties and rock physics models of sediment containing natural and laboratory-formed methane gas hydrate. American Mineralogist, 2004, 89: 1221-1227
    Winters WJ, Waite WF, Mason DH, et al. Methane gas hydrate effect on sediment acoustic and strength properties. Journal of Petroleum Science and Engineering, 2007, 56: 127-135
    Hyodo M, Nakata Y, Yoshimoto N, et al. Shear behaviour of methane hydrate-bearing sand. In: Proceedings of 17th International Offshore and Polar Engineering Conference, 2007, Lisbon, Portugal, 1326-1333
    Masui A, Haneda H, Ogata Y, et al. Mechanical properties of sandy sediment cotaining marine gas hydrates in deep sea offshore Japan. In: Proceedings of 17th International Offshore and Polar Engineering Conference, Ocean Mining Symposium, 2007, Lisben, Portugal, 53-56
    Miyazaki K, Masui A, Sakamoto Y, et al. Triaxial compressive properties of artificial methane-hydrate-bearing-sediment. Journal of Geophysical Research, 2011, 116, B06102
    Clayton CRI, Priest JA, Best AI. The effects of disseminated methane hydrate on the dynamic stiffness and damping of a sand. Geotechnique, 2005, 55(6): 423-434
    Zhang XH, Lu XB, Zhang LM, et al. Experimental study on mechanical properties of methane-hydrate-bearing sediments. Acta Mechanica Sinica, 2012, 28(5): 1356-1366
    张旭辉, 王淑云, 李清平 等. 天然气水合物沉积物力学性质的试验研究. 岩土力学, 2010, 31(10): 3069-3074 (Zhang Xuhui, Wang Shuyun, Li Qingping, et al. Experimental study of mechanical properties of gas hydrate deposits. Rock and Soil Mechanics, 2010, 31(10): 3069-3074 (in Chinese))
    Lu XB, Wang L, Wang SY, et al. Study on the Mechanical Properties of the tetrahydrofuran hydrate deposit. In: Proceedings of 18th International Offshore and Polar Engineering Conference, Vancouver, Canada, 2008, 57-60
    魏厚振, 颜荣涛, 陈盼 等. 不同水合物含量含二氧化碳水合物砂三轴试验研究. 岩土力学, 2011, 32(Supp.2): 198-203 (Wei Houzhen, Yan Rongtao, Chen Pan, et al. Deformation and failure behavior of carbon dioxide hydrate-bearing sands with different hydrate contents under triaxial shear tests. Rock and Soil Mechanics, 2011, 32(Supp.2): 198-203 (in Chinese))
    李洋辉,宋永臣,刘卫国. 天然气水合物三轴压缩试验研究进展. 天然气勘探与开发, 2010, 33(2): 51-55 (Li Yanghui, Song Yongchen, Liu Weiguo. Triaxial compression test of natural gas hydrate. Natural Gas Exploration & Development, 2010, 33(2): 51-55 (in Chinese))
    李令东, 程远方, 孙晓杰 等. 水合物沉积物试验岩样制备及力学性质研究. 中国石油大学(自然科学版), 2012, 36(4): 97-101 (Li Lingdong, Cheng Yuanfang, Sun Xiaojie, et al. Experimental sample preparation and mechanical properties study of hydrate bearing sediments. Journal of China University of Petroleum, 2012, 36(4): 97-101 (in Chinese))
    Yun TS, Santamarina JC, Rupple C. Mechanical properties of sand, silt and clay containing tetrahydrofuran hydrate. Journal of Geophysical Research, 112, B04106
    Waite WF, Santamarina JC, Cortes DD, et al. Physical properties of hydrate-bearing sediments. Reviews of Geophysics, RG4003/2009, 47: 1-38
    吴青柏, 蒲毅彬, 蒋观利, 等. 冻结粗砂土中甲烷水合物形成CT试验研究. 天然气地球科学, 2006, 17(2): 239-248 (Wu Qingbai, Pu Yibin, Jiang Guanli, et al. Experimental research of formation process of methane hydrate in freezing coarse grain size sand by computerized tomography. Natural Gas GeoScience, 2006, 17(2): 239-248 (in Chinese))
    Nagashima K, Orihashi S, Yamamoto Y, et al. Encapsulation of saline solution by tetrahydrofuran clathrate hydrates and inclusion migration by recrystallization. Journal of Physical Chemistry B, 2005, 109: 10147-10153
    Lu XB, Zhang XH, Wang SY. Advances in study of mechanical properties of gas hydrate bearing sediments. The Open Ocean Engineering Journal, 2013, 6: 26-40
