漂浮基柔性空间机器人的鲁棒控制及振动抑制

谢立敏; 陈力

doi:10.6052/0459-1879-12-156

漂浮基柔性空间机器人的鲁棒控制及振动抑制

谢立敏^,,
陈力

福州大学机械工程及自动化学院,福州 350108

基金项目: 国家自然科学基金(11072061, 10672040)和福建省自然科学基金(2010J01003)资助项目.

详细信息

通讯作者:
谢立敏

中图分类号: TP241
计量
- 文章访问数: 1699
- HTML全文浏览量: 128
- PDF下载量: 997
出版历程
- 收稿日期: 2012-05-23
- 修回日期: 2012-07-10
- 刊出日期: 2012-11-17

ROBUST CONTROL AND VIBRATION SUPPRESSION OF FREE-FLOATING FLEXIBLE SPACE ROBOT

Xie Limin^,,
Chen Li

School of Mechanical Engineering and Automation,Fuzhou University,Fuzhou 350108, China

Funds: The project was supported by the National Natural Science Foundation of China (11072061, 10672040) and the Natural Science Foundation of Fujian Province (2010J01003).

摘要

摘要: 讨论了漂浮基柔性空间机器人系统的动力学建模、运动控制算法设计以及关节、臂双重柔性振动的分级主动抑制问题. 利用系统动量、动量矩守恒关系和拉格朗日-假设模态法对系统进行动力学分析,建立系统动力学方程. 基于奇异摄动法,将系统分解为表示系统刚性运动部分的慢变子系统, 表示由柔性臂引起的系统柔性运动部分的快变子系统1和表示由柔性关节引起的系统柔性运动部分的快变子系统2. 针对慢变子系统提出一种鲁棒控制方法来补偿系统参数的不确定性和柔性关节引起的转动误差,实现系统期望运动轨迹的渐近跟踪;针对快变子系统1采用线性二次型最优控制器来抑制由柔性臂引起的系统柔性振动;针对快变子系统2设计了基于机械臂和电机转子的转角速度差值的反馈控制器来抑制由柔性关节引起的系统柔性振动. 因此,系统的总控制律为以上3个子系统控制律的综合. 最后通过仿真实验证明了所提出的混合控制方法的有效性.
- 漂浮基空间机器人 /
- 柔性关节 /
- 柔性臂 /
- 奇异摄动 /
- 鲁棒
Abstract: The dynamics modeling, algorithm design of motion control and step active suppression of joint-link double flexible vibration of free-floating flexible space robot are discussed. The system dynamic equations are established according to system momentum conservation, angular momentum conservation and Lagrange-assumed mode method. Based on singular perturbation method, the system is decomposed into a slow subsystem (represents the system's rigid motion), a fast subsystem 1 (represents the system's flexible motion caused by flexible-link), and a fast subsystem 2 (represents the system's flexible motion caused by flexible-joint). For the slow subsystem, a robust controller is proposed to compensate the uncertain parameters and rotation errors, and to realize the asymptotic tracking of the system's motion trajectory. For the fast subsystem 1, linear quadric regulator (LQR) is used to suppress the flexible vibration caused by flexible-link. For the fast subsystem 2, a feedback controller based on the velocity difference between the link and the motor is used to suppress the flexible vibration caused by flexible-joint. So the system's controller is a synthesize controller by the three controllers. The simulation results prove the controller's efficiency.
- free-floating space robot /
- flexible-joint /
- flexible-link /
- singular perturbation /
- robust

HTML全文

参考文献(12)

Abiko S, Hirzinger G. Adaptive control for a torque controlled free-floating space robot with kinematic and dynamic model uncertainty. In: Proceeding of the 2009 IEEE/RSJ International Conference on Intelligent Robots and Systems. St. Louis, USA: IEEE, 2009: 2359-2364

陈力, 刘延柱. 漂浮基空间机械臂关节轨迹跟踪的增广鲁棒控制方法. 固体力学学报, 2001, 22(3): 225-230 (Chen Li, Liu Yanzhu. The robust control scheme for free-floating space manipulator to track the desired trajectory in jointspace. Acta Mecanica Solida Sinica, 2001, 22(3): 225-230 (in Chinese))

李俊峰, 王照林. 带空间机械臂的充液航天器姿态动力学研究. 宇航学报, 1999, 20(2): 81-86 (Li Junfeng, Wang Zhaolin. Study on attitude dynamics of a liquid-filled spacecraft with manipulators. Journal of a Stronautics, 1999, 20(2): 81-86 (in Chinese))

洪昭斌, 陈力. 柔性空间机械臂基于奇异摄动法的鲁棒跟踪控制和柔性振动主动控制. 工程力学, 2010, 27(8): 191-198 (Hong Zhaobin, Chen Li. Robust control and active vibration control of space flexible manipulator by singular perturbation approach. Engineering Mechanics, 2010, 27(8): 191-198 (in Chinese))

Bahrami M, Jamilnia R, Naghash A. Trajectory optimization of space manipulators with flexible links using a new approach. International Journal of Robotics, 2009, 1(1): 48-55

陈志勇, 陈力. 漂浮基带柔性铰空间机器人的动力学建模及奇异摄动控制研究. 中国机械工程, 2011, 22(18): 2151-2155 (Chen Zhiyong, Chen Li. Study on dynamics modeling and singular perturbation control of free-floating space robot with flexible joints. China Mechanical Engineering, 2011, 22(18): 2151-2155 (in Chinese))

Xie LM, Chen L. Singular perturbation and fuzzy variable structure sliding mode control of space robot system with flexible joint in inertial space. In: Proceeding of the 62nd International Astronautical Congress, Cape Town, SA: IEEE, 2011

章定国, 周胜丰. 柔性杆柔性铰机器人动力学分析. 应用数学和力学, 2006, 27(5): 615-623 (Zhang Dingguo, Zhou Shengfeng. Dynamic analysis of flexible-link and flexible-joint robots. Applied Mathematics and Mechanics, 2006, 27(5): 615-623 (in Chinese))

Gao ZH, Yun C, Bian YS. Coupling effect of flexible joint and flexible link on dynamic singularity of flexible manipulator. Chinese Journal of Mechanical Engineering, 2008, 21(1): 9-12

Vakil M, Fotouhi R, Nikiforuk PN. A new method for dynamic modeling of flexible-link flexible-joint manipulators. Journal of Vibration and Acoustics, 2012, 134(1): 14503-14513

Spong MW. Modeling and control of elastic joint robots. Journal of Dynamics Systems, Measurement, and Control, 1987, 109: 310-319

蔡国平, 洪嘉振. 旋转运动柔性梁的假设模态方法研究. 力学学报, 2005, 37(1): 48-56 (Cai Guoping, Hong Jiazhen. Assumed mode method of a rotating flexible beam. Acta Mechanica Sinica, 2005, 37(1): 48-56 (in Chinese))
