六边形蜂窝等效面外剪切模量预测及其尺寸效应

张卫红; 段文东; 许英杰; 朱继宏

doi:10.6052/0459-1879-12-073

六边形蜂窝等效面外剪切模量预测及其尺寸效应

西北工业大学机电学院,西安710072

基金项目: 国家重点基础研究发展计划(2011CB610304)和国家自然科学基金（10925212)资助项目.

详细信息

通讯作者:
张卫红,教授,主要研究方向:结构优化设计.E-mail:zhangwh@nwpu.edu.cn

中图分类号: V214.6
计量
- 文章访问数: 2919
- HTML全文浏览量: 103
- PDF下载量: 1208
出版历程
- 收稿日期: 2013-01-05
- 修回日期: 2013-01-07
- 刊出日期: 2013-03-17

PREDICTIONS OF EFFECTIVE OUT-PLANE SHEAR MODULUS AND SIZE EFFECT OF HEXAGONAL HONEYCOMB

School of Mechanical Engineering, Northwestern Polytechnical University, Xi'an 710072, China

Funds: The project was supported by the National Basic Research Program (2011CB610304) and the National Natural Science Foundation of China (10925212).

摘要

摘要: 给出了预测六边形蜂窝材料等效剪切模量及其尺寸效应的圆筒扭转力学模型和扭转能量法,建立了等效面外剪切模量G₁₃相对于材料体分比ν、周向单胞数n、圆筒半径r和单胞层数参数m变化的解析表达式;同时将扭转能量法、有限元数值模拟计算和G-A经典细观力学方法进行了比较,从理论上揭示并验证了尺寸效应的存在性. 结果表明,当蜂窝体胞尺寸相对结构尺寸无穷小时,预测结果趋近于细观力学方法的结果. 此外,利用周期性蜂窝材料的结构对称特性,使用体胞子结构有限元计算模型进行等效面外剪切模量及其尺寸效应的预测,在不影响计算结果的前提下极大地提高了计算效率.
- 六边形蜂窝材料 /
- 圆筒扭转力学模型 /
- 等效面外剪切模量 /
- 尺寸效应 /
- 扭转能量法 /
- G-A细观力学方法
Abstract: In this paper, a cylinder torsion model and a torsion energy method are proposed to predict equivalent outplane shear modulus of hexagon cellular materials. An analytical expression for its size effect is constructed in terms of volume fraction(ν), number of cells in circumference(n), radius of the hollow cylinder(r) and number parameter of cell layers(m). Comparisons are made among the results of torsion energy method, finite element numerical simulation and G-A microstructure mechanical method. The size effect is revealed and proved theoretically. Numerical results show that when the cell size trends to be infinitely small with regard to the size of the structure, predicted results approach those obtained by mesoscopic mechanics method. Due to the cyclic symmetry of periodic cellular materials, it is shown that the computing efficiency can be greatly increased by means of the substructure model.
- hexagonal honeycomb /
- torsion of cylinder model /
- effective shear modulus /
- size effect /
- torsion energy method /
- G-A microstructure mechanical method

HTML全文

参考文献(10)

Kelsey S, Gellatly R, Clark B. The shear modulus of foil honeycomb cores. Aircraft Engineering, 1964, 30(10): 294-302

Grediae M. A finite element study of the transverse shear in honeycomb Core. International Journal of Solids and Structures, 1993, 30(13): 1777-1788

Meraghni F, Desrumaux F, Benzeggagh ML. Mechanical behaviour of cellular core for structural sandwich panels. Composites Part A: Applied Science and Manufacturing, 1999, 30(6): 767-779

Gibson LJ, Ashby MF. Cellular Solids: Structure and Properties. Cambridge: Cambridge University Press, 1997.

Onck PR,Andrews EW,Gibson LJ. Size effects in ductile cellular solids. Part I: Modeling. International Journal of Mechanical Sciences, 2001, 43: 681-699

Lestari W, Qiao PZ, Song GB, et al. Evaluation of bending and shear moduli of sandwich structures by dynamic response based technique. In: Proceeding of 44th AIAA/ASME/ASCE/AHS Structures, Structural Dynamics and Materials Conference, 2003

Tantikom K., Aizawa T, Mukai T. Symmetric and asymmetric deformation transition in the regularly cell-structured materials Part I: Experimental study. International Journal of Solids and Structures, 2005, 42: 2199-2210

戴高明, 张卫红. 周期性多孔材料等效拉伸模量的尺度效应研究. 中国科学G辑:物理力学天文学, 2009, 39(7): 955-963 (Dai Gaoming, Zhang Weihong. Size effects of effective Young's modulus for periodic cellular materials. Science in China (Series G: Physics,Mechanics & Astronomy), 2009, 39(7): 955-963 (in Chinese))

张卫红, 骆金威, 戴高明等. 周期性多孔材料等效剪切模量的一种简单计算方法与尺寸效应研究. 力学学报, 2011, 43(1): 144-153 (Zhang Weihong, Luo Jinwei, Dai Gaoming, et al. Numerical Predictions of Effective Shear Modulus and Size Effect for Periodic Cellular Materials. Chinese Journal of Theoretical and Applied Mechanics, 2011, 43(1): 144-153 (in Chinese))

Wang AJ, McDowell DJ. Optimization of a metal honeycomb sandwich beam-bar subjected to torsion and bending. International Journal of Solids and Structures, 2003, 40: 2085-2099
