VIBRATION ANALYSIS OF ELECTRIC VEHICLE-ROAD COUPLING SYSTEM CONSIDERING TIRE-ROAD MULTI-POINT CONTACT
-
摘要: 轮毂电机驱动电动汽车的簧下质量大, 使得轮胎动载荷增加, 且电机激励进一步加剧车轮振动. 同时, 轮胎与路面单点接触的简化模型, 其动力学计算结果与实际存在差别. 鉴于此, 考虑电机的电磁激励、胎路多点接触和非线性地基, 建立了电动汽车−路面系统机电耦合动力学模型, 通过Galerkin法推导了非线性地基梁的垂向振动, 利用积化和公式推导了非线性地基梁中非线性项积分的精确表达式, 提出了路面截断阶数选取的简易方法, 并通过路面位移响应的收敛性进行了验证. 在此基础上, 研究了胎路多点接触、非线性地基、电机激励、车速、路面不平顺幅值等对路面及车辆响应的影响. 结果表明, 非线性地基及多点接触对车辆响应的影响中, 轮胎动载荷的影响最大, 车身加速度和悬架动挠度的影响较小, 且考虑电机激励时, 二者对车辆响应的影响显著增大. 从对路面响应的影响看, 电机激励的影响最大, 非线性地基的影响次之, 多点接触的影响较小. 所建模型及研究方法可为电动汽车的垂向动力学分析提供一种新思路.Abstract: The unsprung mass of the electric vehicle driven by the hub motor is large, which makes the tire dynamic load increase, and the motor excitation further aggravates the wheel vibration. Meanwhile, the dynamic calculation results of the simplified model of single point contact between tire and road are different from the actual. Thus, considering the electromagnetic excitation of the motor, nonlinear foundation and multi-point contact between tire and road, the electromechanical coupling dynamic model of the electric vehicle-road system is established. The vertical vibration of the nonlinear foundation beam is derived by the Galerkin method, and the accurate expression of the nonlinear integral term in the nonlinear foundation beam is derived by using the integral sum formula. A simple method to select the truncation order of the road is proposed, which is verified with the convergence of road response. Accordingly, the effects of multi-point contact between tire and road, nonlinear foundation, motor excitation, vehicle speed and road roughness amplitude on vehicle response are studied. The results show that among the effects of nonlinear foundation and multi-point contact on the vehicle response, the tire dynamic load has the largest influence, and the vehicle body acceleration and suspension dynamic displacement have a small effect. Moreover, when the motor excitation is considered, the influence of the two on the vehicle response increases. From the perspective of the influence on the road response, the motor excitation has the greatest, the nonlinear foundation has the second influence, and the multi-point contact has the less. The established model and research method provide a new idea for vertical dynamics analysis of electric vehicles.
-
引言
近年来, 轮毂电机驱动电动汽车, 因传动效率高、便于实现智能控制等优点, 得到了广泛关注[1-3], 是未来电动汽车的发展方向. 但独立驱动电动汽车的动力学与控制也面临诸多新问题, 其一是簧下质量大, 导致轮胎动载荷增加, 轮胎与路面动力学相互作用更加突出. 其二是电机激励进一步加剧车轮振动, 影响轮胎的接地安全性、车辆行驶的平顺性和稳定性.
目前, 关于独立驱动电动汽车的机电耦合振动方面的研究较为丰富, 金智林等[4]针对轮毂电机驱动电动汽车的侧倾稳定性, 分析了不同路面激励下非簧载质量的影响. 张利鹏等[5]建立了分布式驱动动力学模型, 实现了极限工况下整车高速稳定性控制. 平先尧等[6]构造了强跟踪无迹卡尔曼滤波观测器, 提高了四轮独立驱动电动汽车附着系数的识别精度. 张志达等[7]提出了基于故障检测机制的鲁棒自适应UKF算法, 对分布式驱动电动汽车的纵、侧向车速和质心侧偏角进行估计. Qin等[8]针对路面激励引起的不平衡电磁力, 提出了基于动态吸振结构的轮式开关磁阻电机电动汽车的减振方法. Shao等[9]通过对1/4汽车主动悬架和开关磁阻电机模型进行数值模拟, 发现路面不平度与电机气隙偏心率和不平衡残余力高度耦合. Li等[10]针对轮毂电机存在的振动问题, 建立了车辆瞬态动力学机电耦合综合模型, 提出了主动悬架系统多目标优化控制方法. 上述文献多针对电机激励对车辆响应的影响进行研究, 且多将路面作为对车辆的激励, 未涉及电机激励对路面响应的影响, 也未对路面系统进行建模计算.
关于车路相互作用方面, 主要包括路面系统和车路耦合的研究. 路面系统多采用连续体梁[11], 通过Galerkin、有限差分、Newmark、有限元等方法, 研究集中载荷作用下路面动态响应, Froio等[12]研究了无限大Pasternak弹性梁在集中载荷作用下的稳态响应, 通过傅里叶变换得到了一个通用的闭式解析解. Esen[13]采用改进的有限元法, 对功能梯度材料在双参数地基上对Timoshenko梁的横向振动分析. 车路耦合方面, 通过轮胎力将车辆与路面耦合计算[14], 且轮胎多采用单点接触模型, 如Hien等[15]采用有限元法构造运动方程, 弹簧的质量、刚度和车辆阻尼系数假定为高斯随机变量, 研究了具有不确定参数的车辆−弹性支承梁的动力响应. Krishnanunni和Rao[16]提出了车−路系统响应的迭代解耦方法. Li和Yang[17]建立了车路耦合动力学模型, 认为路面振动会给汽车带来二次激励, 影响轮胎动载和附着特性.
针对轮胎与路面接触情况, 多采用单点接触模型, 对实际的胎路接触模型大大简化, 方便计算, 但精度也会降低. 随着数字计算能力的提升, 胎路点接触模型的计算精度, 逐渐受到研究者们的质疑, 车路耦合方面, Yang等[18]提出了改进轮胎滚子接触力学模型, 提高了精度, 但计算量大, 运算速度较慢. 黄晓明和郑彬双[19]针对胎路附着特性研究不足, 提出从时变性、统一性及车辆抗滑需求感应参数等方面深入研究. 孙加亮等[20]针对多柔体系统动力学问题, 提出柔性部件的动力建模与优化. 刘志浩等[21]建立了轮胎欧拉梁模型, 研究轮胎包容性对振动特性的影响. 王立安等[22]建立了1/4汽车与半空间地基耦合振动模型, 采用弹性滚子接触模型反映轮胎包容性, 推导了地表振动位移的解析解. 车桥耦合方面, Zhang等[23]提出了多弹簧接触轮胎模型, 可考虑路面不平顺和车轮跳离路面, 便于车桥耦合动力学分析. Deng等[24]提出了轮胎与桥面的多点接触模型, 通过实验证明多点接触模型精度更高. 车桥耦合中, 桥梁通常取5阶模态即可满足计算要求. 而路面系统, 通常取100阶以上, 计算更为复杂, 且多点接触的车路耦合方面的研究尚不多见. 在非线性路基方面. Ding等[25]等研究考虑几何非线性、水平放置弹性梁的主共振, 表明由非对称弹性支承和几何非线性所引起的软化特性到硬化特性的转变仅存在于第一阶模态响应. Singh和Harsha[26]利用应力函数Galerkin方法研究了夹层板在Pasternak弹性地基上的动力特性. 但以上研究仅采用移动集中力描述车辆载荷, 未考虑胎路多点接触.
独立驱动电动汽车的车轮振动剧烈, 与路面的动力学相互作用更加突出. 但现有研究主要针对传统汽车, 关于电动车轮与路面动力学相互作用的研究尚不多见. 而考虑轮胎与路面的多点接触, 基于非线性地基, 研究独立驱动电动汽车在路面不平顺、电机激励及车路耦合激励的综合作用下的动力学问题, 尚未见文献报道. 鉴于此, 论文建立了基于非线性地基及多点接触的轮毂电机电动汽车−路面系统机电耦合动力学模型, 研究汽车与路面的相互作用机理, 分析非线性地基及多点接触在不同激励形式下对路面和电动汽车响应的影响.
1. 电动汽车−路面系统建模
1.1 车−路系统运动微分方程
车−路系统动力学模型, 如图1所示. 采用二自由度1/4汽车悬架模型描述电动汽车垂向振动; 利用非线性黏弹性地基上有限长Euler−Bernoulli梁模拟道路系统. 路面由各向同性、矩形截面Euler−Bernoulli梁模拟, 地基由三次立方非线性Winkler地基模型[27]模拟. 单位长度梁受到基础的作用力为
$$ P = {k_{{\text{r1}}}}{y_{\text{r}}} + {k_{{\text{r3}}}}{y_{\text{r}}}^3 + {c_{\rm{r}}}\frac{{\partial {y_{\text{r}}}}}{{\partial t}} $$ (1) 式中, kr1, kr3分别为地基的线性和非线性弹性系数; cr为地基阻尼系数; yr为路面垂向位移.
假定t = 0时刻汽车位于道路中点, 以速度v沿直线匀速行驶. 利用达朗贝尔原理及Bernoulli−Euler理论, 建立车辆及路面垂向振动微分方程[27]
$$ \begin{split} & {m_2}{{\ddot y}_2} + {c_2}({{\dot y}_2} - {{\dot y}_1}) + {k_2}({y_2} - {y_1}) = 0 \\ & ({m_1} + {m_3}){{\ddot y}_1} - {c_2}({{\dot y}_2} - {{\dot y}_1}) - {k_2}({y_2} - {y_1}) + \\ &\qquad {\text{ }}\sum\limits_{i = 1}^n {{c_{{\text{t}}i}}({{\dot y}_1} - {{\dot y}_{0i}} - {{\dot y}_{{\text{t}}i}})} + \sum\limits_{i = 1}^n {{k_{{\text{t}}i}}({y_1} - {y_{0i}} - {y_{{\text{t}}i}})} = {F_{\text{e}}} \end{split} $$ (2) $$ \begin{split} & EJ\frac{{\partial {}^4{y_{\rm{r}}}}}{{\partial {x^4}}} + \rho A\frac{{\partial {}^2{y_{\rm{r}}}}}{{\partial {t^2}}} + {k_{{\rm{r}}1}}{y_{\rm{r}}} + {k_{{\rm{r}}3}}{y_{\rm{r}}}^3 + \\ &\qquad {\rm{ }}{c_{\rm{r}}}\frac{{\partial {y_{\rm{r}}}}}{{\partial t}} = F(t){\rm{\delta }}(x - vt) \end{split}$$ (3) 式中, m1, m2分别为非簧载质量和簧载质量, m3为轮毂电机及减速机构质量, y1, y2分别为非簧载质量和簧载质量位移, k2, c2分别为悬架刚度和阻尼系数, Fe为电机垂向激励合力. E为路面材料弹性模量, J为路面截面对中性轴的惯性矩, ρ, A分别为路面密度和横截面积, δ为狄拉克函数, x为汽车行驶方向的位移, v为行驶速度.
F(t)为电动汽车与路面相互作用力, 即轮胎力
$$ \begin{split} F = &\sum\limits_{i = 1}^n {{c_{{\text{t}}i}}({{\dot y}_1} - {{\dot y}_{0i}} - {{\dot y}_{{\text{t}}i}})} + {\text{ }}\sum\limits_{i = 1}^n {{k_{{\text{t}}i}}({y_1} - {y_{0i}} - {y_{{\text{t}}i}})} - \\ & ({m_1} + {m_2} + {m_3})g \end{split} $$ (4) 式中, 轮胎与路面为多点接触, n为多点接触数量; yti为轮胎下方各接触点处的路面振动位移, 称之为路面二次激励[27], kti, cti分别为各点接触处轮胎的刚度和阻尼系数. 假定每个接触点的刚度和阻尼系数相同, 即
$$ {k_{{\text{t}}i}} = {k_{\text{t}}}/n , \;\; {c_{{\text{t}}i}} = {c_{\text{t}}}/n $$ (5) 式中, kt, ct为轮胎总的刚度系数和阻尼系数.
y0i为各接触点处的路面不平顺激励, 采用正弦函数描述
$$ {y_{0i}} = {B_0}\sin \left[\frac{{2{\text{π}} }}{{{L_0}}}\left(vt{\text{ + }}\frac{{i{L_{\text{t}}}}}{{n - 1}}\right)\right],\;\;i = 0,1,\cdots $$ (6) 式中, B0, L0分别为路面不平顺幅值及波长, Lt为轮胎接触印迹长度.
汽车参数取为[28]: m1 = 40 kg, m2 = 337.5 kg, m3 = 30 kg, kt = 250 kN/m, k2 = 19.6 kN/m, ct = 375 N·s/m, c2 = 1450 N·s/m, 轮胎印迹Lt = 25.4 mm[24], 车轮滚动半径0.304 4 m[29], 车速v = 20 m/s.
路面系统参数取为[27, 30-31]: 路面宽度、厚度分别为6 m, 0.01 m, 长度L = 160 m; 路面材质为沥青混合料, 密度ρ = 2.5 t/m3, 弹性模型E = 1.6 GN/m2, 路面不平顺参数: L0 = 10 m, B0 = 0.02 m; 地基的线性和非线性弹性系数、地基阻尼系数分别取为kr1 = 8 MN/m2, kr3 = 8 MN/m2, cr = 300
${\rm{k}}{\text{N}} \cdot {\text{s/}}{{\text{m}}^2}$ .1.2 胎路接触点数的选取
为了合理选取胎路接触点数, 计算得到不同胎路接触点数下的路面响应最大幅值, 根据其收敛性确定接触点数. 模态截断阶数取NM = 200, 轮胎与路面接触点数取1 ~ 8, 行驶速度分别为30, 50, 60和130 km/h, 考虑电机激励与不考虑电机激励时, 接触点数对非线性与线性地基的路面响应最大幅值的影响如图2所示.
![]()
图 2 接触点数对路面响应最大幅值的影响Figure 2. Effects of the number of contact point on the maximum amplitude of road response由图2可见, 多点接触较单点接触, 路面响应最大幅值都有所降低:
(1)不考虑电机激励时, 随着接触点数的增大, 路面最大幅值呈现下降趋势. 且当n > 3时, 路面响应最大幅值的相对增量小于0.02%;
(2)考虑单机激励时, 电机激励使得路面响应波动都增大, 且随着车速增加, 路面响应相对降幅增大, 其中车速为130 km/h时, 最大降幅为5.72%, 而车速为30 km/h时, 最大降幅都小于0.8%. 当n > 5时, 路面响应变化较小, 小于1.5%.
综上, 在后续计算中, 胎路接触点数n取为6.
1.3 电机垂向激励
采用四相8/6极开关磁阻电机[29, 32], 每转24个步距, 步进角15°. 电机垂向激励合力由定、转子间的切向力和径向力组成, 其中电磁转矩波动产生切向力, 其表达式为
$$ {F_\tau } = {T_{\text{e}}}/R $$ (7) 式中, R为电机定子半径, Te为电磁转矩.
假设电机相电流I为常数, 且磁路为线性, 则磁极上的径向力为
$$ {F_{\text{r}}} = \frac{{\partial [L(\theta ,{l_{\rm{g}}}){I^2}/2]}}{{\partial {l_{\rm{g}}}}} \approx - \frac{1}{2}{I^2}\frac{{L(\theta ,{l_{\rm{g}}})}}{{{l_{\rm{g}}}}} $$ (8) 式中, 电感
$ L(\theta ,{l_{\rm{g}}}) $ 为转子转角θ及气隙长度lg的函数, 根据线性磁路假设, 有$$ L(\theta ,{l_{\rm{g}}}) = {L_{\min }} + {K_\theta }\theta $$ (9) 式中, Lmin为最小电感, Kθ为L与θ关系曲线斜率.
定、转子间的气隙长度为
$$ {l_{\text{g}}} = \sqrt {{b^2} + {{(r{\theta _1})}^2}} $$ (10) 式中, b为定转子极间最短距离; rθ1转子凸极转过的弧长, r为转子半径, θ1为转子凸极转角.
将式(9)和式(10)代入式(8), 且考虑切向力与径向力的作用周期相同, 得到径向力
$$ {F_{\text{r}}} = - \dfrac{{{I^2}}}{2}\dfrac{{{L_{\min }} + {K_\theta }\dfrac{{a{\text{π}} }}{{30}}\left({t - nT} \right)}}{{\sqrt {{b^2} + {{\left(\dfrac{{{\text{π}} ar}}{{30}}\right)}^2}{{\left[t - \left(n{\text{ + }}\dfrac{7}{{20}}\right)T\right]}^2}} }} $$ (11) 电机垂向激励合力的解析表达式为
$$ {F_{\text{e}}} = \left\{ \begin{array}{l} {F_\tau }\cos \left(\dfrac{{a{\text{π}} }}{{30}}t\right) + {F_{\text{r}}}\sin \left(\dfrac{{a{\text{π}} }}{{30}}t\right){\text{, }}\;\;nT \leqslant t \leqslant \left(n + \dfrac{7}{{20}}\right)T \\ 0 {\text{ ,}}\;\;\left(n + \dfrac{7}{{20}}\right)T < t \leqslant \left(n + 1\right)T \end{array} \right. $$ (12) 式中, T = 60/(aNr)为电磁激励基波周期, a为电机转速, Nr为转子级数.
电机各参数取值为[29, 32]: R = 0.05 m, Te = 165 N·m; b = 1 mm, I = 1 A, Kθ = 82.5, Lmin = 4.95 H, r = 0.047 m, Nr = 6.
2. 路面响应及收敛性判定指标
2.1 路面响应求解
假设路面垂向位移为
$$ {y_{\text{r}}}(x,t) = \sum\limits_{i = 1}^{NM} {{\phi _i}(x){\eta _i}(t)} $$ (13) 式中,
$ {\phi _i}(x) $ 为地基梁的模态函数,$ {\eta _i}(t) $ 为时间函数, NM为截断阶数.将式(13)代入式(3), 且两端乘以
$ {\phi _j}(x) $ , 并对x在[0, L]区间积分, 得到$$ \begin{split} & \sum\limits_{i = 1}^{NM} {\left[\rho A\frac{{{{\rm{d}}^2}{\eta _i}(t)}}{{{\rm{d}}{t^2}}} + c\frac{{{\rm{d}}{\eta _i}(t)}}{{{\rm{d}}t}} + {k_{{\rm{r1}}}}{\eta _i}(t)\right] \cdot } \int_0^L {{\phi _i}(x){\phi _j}(x){\rm{d}}x{\rm{ + }}} \\ & \qquad EJ\sum\limits_{i = 1}^{NM} {{\eta _i}(t)} \int_0^L {\frac{{{{\rm{d}}^4}{\phi _i}(x)}}{{{\rm{d}}{x^4}}}{\phi _j}(x){\rm{d}}x} + \\ & \qquad{k_{{\rm{r}}3}}\int_0^L {{{\left[\sum\limits_{i = 1}^{NM} {{\eta _i}(t){\phi _i}(x)} \right]}^3}{\phi _j}(x){\rm{d}}x} = {\rm{ }}\\ & \qquad\int_0^L {F(t){\rm{\delta }}(x - vt){\phi _j}(x){\rm{d}}x} \\[-15pt] \end{split}$$ (14) 两端简支边界条件下, 地基梁的模态振型为
$$ {\phi _i}(x) = {C_i}\sin (i{\text{π}} x/L),\;\;i = 1,2,\cdots $$ (15) 根据模态振型的正交性, 以及
$ \dfrac{{{{\text{d}}^4}{\phi _i}(x)}}{{{\text{d}}x}} = {(i{\text{π}} /L)^4}{\phi _i}(x) $ , 整理式(14)得到$$ \begin{split} & {{\ddot \eta }_i}(t) + \frac{c}{{\rho A}}{{\dot \eta }_i}(t) + \frac{{EJ{{\left( {i{\text{π}} } \right)}^4} + {L^4}{k_{{\rm{r}}1}}}}{{\rho A{L^4}}}{\eta _i}(t) + \\ &\qquad {\rm{ }}\frac{{{k_{{\rm{r}}3}}}}{{\rho A}}\int_0^L {\sum\limits_{i = 1}^{NM} {{{\left[ {{\phi _i}(x){\eta _i}(t)} \right]}^3}{\phi _j}(x){\rm{d}}x} } = \frac{{F(t)}}{{\rho A}}{\phi _i}(vt) \end{split} $$ (16) 对于式(16)中的非线性项积分
$\displaystyle\int_0^L \displaystyle\sum\limits_{i = 0}^{NM} {{\left[ {{\phi _i}(x){\eta _i}(t)} \right]}^3}\cdot $ $ {\phi _j}(x){\rm{d}}x$ , 文献[27]采用无量纲化处理后再进行数值积分, 相应的动力学方程需进行变量代换, 推导过程比较繁琐, 且数值积分的计算精度与积分步长密切相关. 为此, 论文采用三角函数的积化和公式推导立方非线性项积分的解析表达式, 避免了数值积分计算, 精度高, 且运算速度快. 具体方法如下:先将立方非线性项改写
$$ \begin{split} & \int_0^L {\sum\limits_{i = 0}^{NM} {{{\left[ {{\phi _i}(x){\eta _i}(t)} \right]}^3}{\phi _j}(x){\rm{d}}x} }= \sum\limits_{i = 1}^{NM} {\sum\limits_{k = 1}^{NM} {\sum\limits_{m = 1}^{NM} {{\eta _i}(t){\eta _k}(t){\eta _m}(t) \cdot } } } \\ &\qquad {\rm{ }}\int_0^L {{\phi _i}(x){\phi _k}(x){\phi _m}(x){\phi _j}(x){\rm{d}}x} =\\ &\qquad \sum\limits_{i = 1}^{NM} {\sum\limits_{k = 1}^{NM} {\sum\limits_{m = 1}^{NM} {{\eta _i}(t){\eta _k}(t){\eta _m}(t) \cdot } } } \\ &\qquad \int_0^L {\sin \left(\frac{{i{\text{π}} x}}{L}\right)} \sin \left(\frac{{k{\text{π}} x}}{L}\right)\sin \left(\frac{{m{\text{π}} x}}{L}\right)\sin (\frac{{j{\text{π}} x}}{L}){\rm{d}}x\\ &\qquad j = 1,2,\cdots,NM\\[-13pt] \end{split}$$ (17) 利用三角函数的积化和公式, 可得式(17)中的积分项为
$$\begin{split} & \int_0^L {\sin \left( {\frac{{i{\text{π}} x}}{L}} \right)} \sin \left( {\frac{{k{\text{π}} x}}{L}} \right)\sin \left( {\frac{{m{\text{π}} x}}{L}} \right)\sin \left( {\frac{{j{\text{π}} x}}{L}} \right){\rm{d}}x = \\ &\qquad \frac{1}{8}\int_0^L {\left\{ {\cos [{\text{π}} x(i - k + m - j)/L] + } \right.} \\ &\qquad \cos [{\text{π}} x(i - k - m + j)/L] + \cos [{\text{π}} x(i - k + m + j)/L] + \\ &\qquad \cos [{\text{π}} x(i - k - m - j)/L] + \cos [{\text{π}} x(i + k + m - j)/L] + \\ &\qquad \cos [{\text{π}} x\left( {i + k - m + j} \right)/L] + \cos [{\text{π}} x\left( {i + k + m + j} \right)/L] + \\ &\qquad \left. {\cos [{\text{π}} x\left( {i + k - m - j} \right)/L]} \right\}{\rm{d}}x\\[-10pt] \end{split}$$ (18) 由于
$$ \begin{split} &\int_0^L {\cos \left({{\text{π}}\varDelta x/L} \right)} {\rm{d}}x = \\ &\qquad {\text{ }}\left\{ \begin{array}{l} \dfrac{{L\sin ({\text{π}}\varDelta )}}{{{\text{π}}\varDelta }},\;\;\varDelta {\text{ = }}i \mp k \pm m \mp j \ne 0 \\ L {\text{ }},\;\;\varDelta {\text{ = }}i \mp k \pm m \mp j = 0{\text{ }} \end{array} \right. \end{split} $$ (19) 式(18)进一步整理为
$$ \begin{split} & \int_0^L {\sin \left(\frac{{i{\text{π}} x}}{L}\right)} \sin \left(\frac{{k{\text{π}} x}}{L}\right)\sin \left(\frac{{m{\text{π}} x}}{L}\right)\sin \left(\frac{{j{\text{π}} x}}{L}\right){\text{d}}x {\text{ }} =\\ & \qquad \frac{1}{8}\sum\limits_{kk = 1}^8 {{f_{kk}}(i,j,k,m)} \end{split} $$ (20) 式中,
${f_{kk}}(i,j,k,m) = \left\{ \begin{array}{l} \dfrac{L}{{ {\text{π}}\varDelta }}\sin ( {\text{π}}\varDelta),\;\;\varDelta \ne 0 \\ L {\text{ ,}}\;\;\;\varDelta = 0 \end{array} \right.$ 将式(20)代入式(17), 得到
$$ \begin{split} & \int_0^L {\sum\limits_{i = 0}^{NM} {{{\left[ {{\phi _i}(x){\eta _i}(t)} \right]}^3}{\phi _j}(x){\rm{d}}x} } = \\ & \qquad\frac{L}{8}\sum\limits_{i = 1}^{NM} {\sum\limits_{k = 1}^{NM} {\sum\limits_{m = 1}^{NM} {{\eta _i}(t){\eta _k}(t){\eta _m}(t)\sum\limits_{kk = 1}^8 {{f_{kk}}(i,j,k,m)} } } } \\& \qquad j = 1,2,\cdots,NM \end{split}$$ (21) 将式(21)代入式(16), 得到非线性地基梁第i阶模态的振动微分方程
$$ \begin{split} & {{\ddot \eta }_i}(t) + \frac{c}{{\rho A}}{{\dot \eta }_i}(t) + \frac{{EJ{{\left( {i{\text{π}} } \right)}^4} + {L^4}{k_{{\rm{r}}1}}}}{{\rho A{L^4}}}{\eta _i}(t) + \\ &\qquad \frac{{L{k_{{\rm{r}}3}}}}{{8\rho A}}\sum\limits_{i = 1}^{NM} {\sum\limits_{k = 1}^{NM} {\sum\limits_{m = 1}^{NM} {{\eta _i}(t){\eta _k}(t){\eta _m}(t)} } } \sum\limits_{kk = 1}^8 {{f_{kk}}(i,j,k,m)} =\\ &\qquad \frac{{F(t)}}{{\rho A}}{\phi _i}(vt)\\[-10pt] \end{split}$$ (22) 式中, 地基梁模态振型
$ {\phi _i}(x) $ 的系数$ {C_i} $ , 通过正交性进行归一化求解$$ \int_0^L {{\phi _i^2}\left(x \right)} {\text{d}}x{\text{ = }}\int_0^L {C_i^2{{\left[ {\sin \left({\frac{{i{\text{π}} x}}{L}} \right)} \right]}^2}} {\text{d}}x{\text{ = 1}} $$ (23) 求得
$ {C_i} = \sqrt {\dfrac{2}{L}} $ , 模态振型为$$ {\phi _i}(x) = \sqrt {\frac{2}{L}} \sin \left({\frac{{i{\text{π}} x}}{L}} \right),\;\;i = 1,2,\cdots $$ (24) 将式(24)代入式(22), 通过4阶龙格库塔数值方法求解
$ {\eta _i}(t) $ . 再将$ {\eta _i}(t) $ 和$ {\phi _i}(x) $ 代入式(13)得到路面垂向位移$ {y_{\text{r}}}(x,t) $ .图3所示为本文提出的非线性项积分处理方法与文献[27]的数值积分方法对比, 图中截断阶数分别为50和150, 路面位移最大幅值的相对差别分别为0.16%和0.13%. 证明论文所提出的方法的正确性, 也说明截断阶数越高, 数值积分精度越高, 二者差别越小.
2.2 截断阶数的选取及收敛性判定指标
截断阶数NM越大, 路面响应的精度越高, 但运算耗时也越长. 合理选择截断阶数, 在保证计算精度的同时, 加快运算速度, 具有重要意义. Chen等[33]等研究了集中载荷作用下非线性地基多层梁的Galerkin截断阶数的收敛性. 受此启发, 论文基于非线性地基及胎路多点接触, 分析电动汽车−路面机电耦合系统的Galerkin截断阶数的收敛性.
由式(14)可知, 线弹性地基梁无阻尼、不考虑非线性刚度及路面激励时的固有频率为
$$ {\omega _i} = \sqrt {\frac{{EJ{{\left({i{\text{π}} } \right)}^4} + {L^4}{k_{{\rm{r}}1}}}}{{\rho A{L^4}}}} $$ (25) 以相邻频率之间的相对增量为路面响应收敛性的判定指标, 其表达式为
$$ {\lambda _i}{\text{ = }}\frac{{\omega _{i{\text{ + }}1}^{} - \omega _i^{}}}{{\omega _i^{}}} \times 100{{\% }},\;\;i = 1,2,\cdots $$ (26) 图4所示为线弹性地基梁的固有频率随截断阶数NM的变化曲线, 表1为前300阶固有频率及相邻频率之间的相对差别, 相邻频率之间的相对增量随截断阶数NM的变化曲线如图5示.
表 1 线弹性地基梁的固有频率及相邻频率差别Table 1. Natural frequency and relative differences of adjacent frequencies of linear elastic foundation beamNM Frequency/Hz Difference/% 1 11.623 0 0 10 11.623 9 0.002 6 20 11.636 8 0.022 0 30 11.692 8 0.075 5 40 11.842 1 0.177 0 50 12.150 9 0.331 6 60 12.693 2 0.529 3 70 13.539 1 0.743 7 80 14.742 5 0.941 6 90 16.335 2 1.096 8 100 18.327 4 1.199 0 110 20.714 3 1.252 0 120 23.483 4 1.266 4 130 26.619 4 1.254 1 140 30.107 8 1.224 8 150 33.935 7 1.186 0 160 38.092 5 1.142 3 170 42.569 7 1.097 180 47.360 2 1.051 9 190 52.458 6 1.008 1 200 57.860 7 0.966 3 210 63.562 8 0.926 7 220 69.562 2 0.889 4 230 75.856 7 0.854 5 240 82.444 4 0.821 7 250 89.323 9 0.791 0 260 96.493 9 0.762 3 270 103.953 4 0.735 5 280 111.701 6 0.710 3 290 119.737 7 0.686 6 300 128.061 3 0.664 4 (1)地基梁的固有频率随着截断阶数NM的增大而增大, 且前60阶具有密频特性, NM大于60时, 固有频率显著增大;
(2)相邻频率之间的相对增量呈现先增后减趋势, NM = 120时, 相对增量达到最大值1.266 4%. NM > 120时, 相对增量逐渐减小, 且NM > 200时, 相对增量都小于1%, 说明截断阶数越高, 相邻频率之间的差别越小, 表明路面响应具有收敛性.
图6所示为路面位移最大幅值随截断阶数NM的变化曲线. 当NM > 120时, 路面垂向位移最大幅值变化较小, 相对差别在3%以内, 且线性地基(linear foundation, LF)与非线性地基(nonlinear foundation, NF)、单点接触(single point, SP)与多点接触(multi-point, MP)的变化趋势一致, 表明NM > 120时, Galerkin截断对于路面位移响应的计算结果相对精确, 也验证了通过式(26)选取截断阶数NM的有效性.
![]()
图 6 截断阶数对路面响应最大幅值的影响Figure 6. Effects of truncation order on maximum amplitude of road response3. 系统参数对车辆和路面响应的影响
与以往研究不同[28], 本文在电动汽车−路面系统建模中考虑了非线性地基、胎路多点接触和电机激励, 因此主要分析不同车速和路面不平顺幅值下, 以上3个因素对车辆及路面响应的影响规律.
3.1 非线性地基、多点接触及电机激励对路面响应的影响
汽车以20 m/s驶过路面某一位置(x = 120 m), 非线性地基与线性地基, 多点接触与单点接触, 以及电机激励对路面垂向位移的影响如图7和图8所示, 路面响应的最大幅值及相对差别见表2.
![]()
图 7 B0 = 0.02 m时非线性地基、多点接触及电机激励对路面响应的影响Figure 7. Effects of nonlinear foundation and multi-point contact and motor excitation on road response when B0 = 0.02 m![]()
图 8 B0 = 0.002 m时非线性地基、多点接触及电机激励对路面响应的影响Figure 8. Effects of nonlinear foundation and multi-point contact and motor excitation on road response when B0 = 0.002 m表 2 路面响应的最大幅值及相对增量Table 2. Maximum amplitude of road response and relative differenceB0/m Motor excitation NF LF Difference between NF and LF yr(SP)/m yr(MP)/m difference yr(SP)/m yr(MP)/m difference SP MP 0.02 √ 2.468 6 × 10−4 2.302 2 × 10−4 −6.74% 2.593 3 × 10−4 2.580 6 × 10−4 −0.49% −4.81% −10.79% × 4.205 0 × 10−4 4.199 6 × 10−4 −0.13% 4.426 7 × 10−4 4.430 9 × 10−4 0.09% −5.01% −5.22% difference 41.29% 45.18% − 41.42% 41.76% − − − 0.002 √ 1.976 6 × 10−4 1.957 3 × 10−4 −0.98% 2.069 5 × 10−4 2.066 9 × 10−4 −0.13% −4.49% −5.30% × 3.819 7 × 10−4 3.819 1 × 10−4 −0.02% 3.846 2 × 10−4 3.846 6 × 10−4 0.01% −0.69% −0.71% difference 48.25% 48.75% − 46.19% 46.27% − − − (1)胎路多点接触相比于单点接触, 路面响应的最大幅值都有所降低, 且非线性地基与线性地基的变化规律一致. 其中, B0 = 0.02 m时, 考虑电机激励与不考虑电机激励时, 非线性地基的多点接触相比于单点接触, 路面响应最大降幅分别为6.74%和0.13%, B0 = 0.002 m时, 最大降幅分别为0.98%和0.02%. 线性地基的最大降幅都小于0.49%;
(2)非线性地基相比于线性地基, 路面响应的最大幅值都减小, 且多点接触与单点接触的影响规律相似. 但非线性与线性地基的多点接触对路面响应的影响大于单点接触, 其中, B0 = 0.02 m和0.002 m时, 多点接触的最大降幅分别为10.79%和5.30%, 相应的单点接触分别为5.01%和4.49%. 说明路面越粗糙, 非线性地基及线性地基对路面响应的影响增大, 尤其是多点接触的影响更为显著;
(3)考虑电机激励相比于不考虑电机激励, 路面响应的最大幅值明显增大, 其中, B0 = 0.02 m和0.002 m时, 考虑电机激励相比于不考虑电机激励, 非线性地基、多点接触的最大增幅分别为45.18%和48.75%. 非线性地基的单点接触及线性地基都具有相似影响规律. 说明路面较为平滑时, 电机激励的影响更为显著.
3.2 非线性地基、多点接触及电机激励对车辆响应的影响
限于篇幅, 论文仅列出路面不平顺幅值B0 = 0.02 m且考虑电机激励时, 非线性地基及多点接触对车辆响应指标的影响, 如图9 ~ 图11示. 图12为B0 = 0.02 m和0.002 m时, 车辆响应指标的相对增量.
![]()
图 9 非线性地基及多点接触对车身加速度的影响Figure 9. Effects of nonlinear foundation and multi-point contact on acceleration of vehicle body![]()
图 11 非线性地基及多点接触对轮胎动载荷的影响Figure 11. Effects of nonlinear foundation and multi-point contact on tire dynamic load![]()
图 12 非线性地基及多点接触对车辆响应的相对差别Figure 12. Relative differences of nonlinear foundation and multi-point contact on vehicle response(1)从多点接触对车辆响应的影响看, 多点接触相比于单点接触, 车辆响应指标都有所增加, 其中, 轮胎动载荷的影响最大, 考虑电机激励、B0 = 0.02 m和0.002 m时, 非线性地基的最大增幅分别为18.27%和22.31%, 不考虑电机激励时, 最大增幅分别为5.39%和4.76%, 车身加速度和悬架动挠度的影响较小, 最大增幅都小于2.1%. 线性地基与非线性地基的变化趋势相似, 但都低于非线性地基, 最大增量都小于1.5%;
(2)从非线性地基对车辆响应的影响看, 非线性地基的多点接触相比于线性地基, 车辆响应指标都有所增加, 其中, 轮胎动载荷的影响最大, 考虑电机激励、B0 = 0.02 m和0.002 m时, 最大增幅分别为10.19%和24.19%, 车身加速度的影响较小, 最大增幅都小于1.6%;
(3)从频域分析可见, 车辆响应呈现两个明显峰值. 可见, 车身加速度和轮胎动载荷的最大峰值受电机激励的中频(43 Hz)部分的影响较大, 而悬架动挠度受低频(9 Hz)部分的影响较大.
综上可见, 电机激励使得非线性地基及胎路多点接触相比于线性地基及单点接触, 对车辆响应的影响增大, 实际计算时应予以重视.
![]()
图 10 非线性地基及多点接触对悬架动挠度的影响Figure 10. Effects of nonlinear foundation and multi-point contact on suspension dynamic displacement3.3 车速对路面和车辆响应的影响
在上述分析的基础上, 本节仅考虑电机激励, 分析不同车速时, 胎路多点接触及非线性地基对车辆及路面响应的影响.
3.3.1 对路面响应的影响
电动汽车在40 ~ 120 km/h行驶速度下, 非线性地基及胎路多点接触对路面响应最大幅值的影响, 如图13示. 为了图示清晰, 图14仅展示车速分别为40, 50和70 km/h时, 路面响应的频域曲线.
![]()
图 13 不同车速时非线性地基及胎路多点接触对路面响应最大幅值的影响Figure 13. Effects of nonlinear foundation and multi-point contact between tire and road on the maximum amplitude of road response at different speeds![]()
图 14 不同车速时非线性地基及胎路多点接触对路面响应的频域曲线Figure 14. Frequency domain curves of the effects of non-linear foundation and multi-point contact between tire and road on the road response at different speeds(1)不同车速下, 非线性地基相比于线性地基, 路面响应的相对增量随着车速增加而减小, 且多点接触与单点接触变化趋势一致, 其中车速为50 km/h时, 非线性与线性地基的相对增量最大, 为15.8%. 说明中低速行驶时, 非线性地基及多点接触对路面响应的影响应予以关注. 此外, 车速为70 km/h时, 路面不平顺激励频率为1.94 Hz, 接近车身的固有频率, 使得车身加速度增大, 而路面最大位移降低;
(2)从频域响应分析看, 非线性地基与线性地基对路面响应的影响, 随着车速增加而降低, 与图14的影响规律一致; 且路面响应受电机垂向激励的低频部分的影响较大.
综上可见, 电机激励对路面响应的影响最大, 非线性地基的影响次之, 多点接触的影响较小. 尤其是电动汽车中低速行驶在较为粗糙路面时, 电机激励、多点接触及非线性地基对路面响应的综合影响不容忽视.
路面二次位移激励受非线性地基、胎路多点接触及电机激励的影响, 如图15所示. 图16为不同速度时, 路面二次位移最大幅值的变化曲线.
(1)多点接触相比于单点接触, 对路面二次位移的影响较小, 不同车速下非线性地基的多点接触与单点接触的相对增量都小于2%, 线性地基的变化趋势与之一致;
(2)非线性地基与线性地基对路面二次位移的影响随车速增加而降低, 且多点接触时, 非线性地基相比于线性地基, 路面二次位移最大幅值都有所减小, 其中40 km/h时最大减幅为9.4%, 而60 ~ 120 km/h时都小于5%. 说明中低速行驶时, 非线性地基对路面二次位移的影响较大;
(3)考虑电机激励时, 路面二次位移的最大幅值显著增加, 最大增幅超过60%.
![]()
图 16 不同行驶速度下路面二次位移的最大幅值Figure 16. Maximum amplitude of road secondary displacement at different speeds3.3.2 对车辆响应的影响
车速分别为40 ~ 120 km/h, 考虑电机激励时, 车身加速度、悬架动挠度和轮胎动载荷受非线性地基及多点接触的影响, 如图17. 不同速度下非线性地基及多点接触对车辆响应的最大增幅如图18.
![]()
图 17 不同车速下非线性地基及多点接触对车辆响应最大幅值的影响Figure 17. Effects of NF and MP on maximum amplitude of vehicle response at different speeds![]()
图 18 不同车速下非线性地基及多点接触对车辆响应的最大增幅Figure 18. Maximum differences of NF and MP on vehicle response at different speeds(1)不同车速下, 多点接触的车辆响应指标的相对增量均大于单点接触. 其中, 轮胎动载荷的相对增量都大于13%, 最大增幅为54.19%, 车身加速度和悬架动挠度的相对增量都小于4%. 而且车速越高, 相对差别越大, 进一步说明限速的必要性;
(2)不同车速下, 非线性地基的车辆响应的相对增幅均大于线性地基. 其中, 轮胎动载荷的影响最大, 高速行驶时最大增幅为43.74%. 悬架动挠度的影响次之, 中低速时最大增幅9.13%, 随着车速的增加, 相对增量减小. 车身加速度的影响较小, 相对增幅都小于5%;
(3)车身加速度、悬架动挠度和轮胎动载荷都在50 ~ 70 km/h区间出现峰值, 主要原因是车辆在该速度区间行驶时, 路面激励与车身固有频率接近, 发生共振所致.
3.4 地基弹性系数对路面和车辆响应的影响
考虑电机激励, 对比分析非线性地基、胎路多点接触(NF, MP)与线性地基、胎路多点接触(LF, MP)下, 地基弹性系数对路面和车辆响应的影响. 分别令kr3和kr1中的一个参数取值不变, 另一个参数分别取8 × 106, 2.4 × 107和4.8 × 107 N·m−2, 地基弹性系数对路面某一位置(x = 120 m处)最大位移的影响如图19所示.
由图19可知, 随着地基线性弹性系数的增大, 路面响应的最大幅值显著降低, 且线性与非线性地基的变化趋势一致, 线性与非线性地基的最大降幅分别为39.8%和38.5%. 地基非线性弹性系数增大时, 线性地基的路面响应不受影响, 非线性地基的路面最大位移略有增加, 最大增幅为1.23%. 可见, 地基线性弹性系数对路面响应的影响大于地基非线性弹性系数. 提升地基弹性系数, 可减小路面最大位移, 对路面使用寿命有利.
![]()
图 19 地基弹性系数对路面响应最大幅值的影响Figure 19. Effects of foundation elastic coefficient on maximum amplitude of road response地基弹性系数对车辆响应的最大幅值的影响, 如图20 ~ 图21所示.
![]()
图 20 地基线性弹性系数对车辆响应最大幅值的影响Figure 20. Effects of foundation linear elastic coefficient on maximum amplitude of vehicle response![]()
图 21 地基非线性弹性系数对车辆响应最大幅值影响Figure 21. Effects of foundation nonlinear elastic coefficient on maximum amplitude of vehicle response![]()
图 21 地基非线性弹性系数对车辆响应最大幅值影响(续)Figure 21. Effects of foundation nonlinear elastic coefficient on maximum amplitude of vehicle response (continued)(1)从线性弹性系数对车辆响应的影响看, 非线性地基的车辆响应指标的相对增量均大于线性地基, 其中轮胎动载荷的影响最大, 最大增幅为−9.88%, 而车身加速度和悬架动挠度的最大增幅分别为2.63%和2.04%;
(2)从非线性弹性系数的影响看, 非线性地基的车辆响应指标均高于线性地基, 其中, 轮胎动载荷的影响较大, 最大增幅为2.75%, 车身加速度和悬架动挠度的最大增幅分别为−0.68%和1.11%;
(3)地基弹性系数对轮胎动载荷的影响最大, 对悬架动挠度和车身加速度的影响较小. 同时, 增加地基线性弹性系数, 可降低非线性地基的轮胎动载荷, 有利于提升车辆的行驶安全和道路使用寿命.
4. 结论
建立了基于非线性地基及胎路多点接触的电动汽车−路面系统机电耦合动力学模型, 利用Galerkin法推导了非线性地基梁的垂向振动微分方程, 提出了路面截断阶数选取判定指标, 分析了车辆与路面响应受非线性地基、胎路多点接触、电机激励、行驶速度、地基弹性系数的影响规律. 所建模型及研究结果具有较好的理论参考价值, 可为电动汽车垂向动力学分析提供新思路.
(1)推导得到的非线性地基梁非线性项积分的精确表达式, 计算速度快、精度高, 克服了数值积分因积分步长选取影响求解精度的问题以及无量纲变换的繁琐性.
(2)通过判断线弹性地基梁相邻频率间相对增量的最大值, 选取非线性地基−车辆−电机激励耦合系统的路面截断阶数, 简单快捷, 具有可行性.
(3)电机激励对路面响应的影响最大, 非线性地基次之, 多点接触较小. 其中, 电动汽车以中低速行驶在较为粗糙路面时, 电机激励、多点接触及非线性地基对路面响应的综合影响不容忽视.
(4)非线性地基及多点接触对轮胎动载荷的影响最大, 对车身加速度和悬架动挠度的影响较小; 考虑电机激励时, 非线性地基及多点接触对车辆响应的影响增大; 不同车速下, 非线性地基及多点接触对轮胎动载荷的影响最大, 车身加速度和悬架动挠度的影响较小.
(5)地基弹性系数对轮胎动载荷的影响最大, 对悬架动挠度和车身加速度的影响较小. 地基弹性系数对路面响应的影响大于车辆响应. 因此, 增加地基线性弹性系数, 可降低轮胎动载荷及路面响应, 有利于提升车辆的行驶安全和道路使用寿命.
-
![]()
图 2 接触点数对路面响应最大幅值的影响
Figure 2. Effects of the number of contact point on the maximum amplitude of road response
![]()
图 6 截断阶数对路面响应最大幅值的影响
Figure 6. Effects of truncation order on maximum amplitude of road response
![]()
图 7 B0 = 0.02 m时非线性地基、多点接触及电机激励对路面响应的影响
Figure 7. Effects of nonlinear foundation and multi-point contact and motor excitation on road response when B0 = 0.02 m
![]()
图 8 B0 = 0.002 m时非线性地基、多点接触及电机激励对路面响应的影响
Figure 8. Effects of nonlinear foundation and multi-point contact and motor excitation on road response when B0 = 0.002 m
![]()
图 9 非线性地基及多点接触对车身加速度的影响
Figure 9. Effects of nonlinear foundation and multi-point contact on acceleration of vehicle body
![]()
图 11 非线性地基及多点接触对轮胎动载荷的影响
Figure 11. Effects of nonlinear foundation and multi-point contact on tire dynamic load
![]()
图 12 非线性地基及多点接触对车辆响应的相对差别
Figure 12. Relative differences of nonlinear foundation and multi-point contact on vehicle response
![]()
图 10 非线性地基及多点接触对悬架动挠度的影响
Figure 10. Effects of nonlinear foundation and multi-point contact on suspension dynamic displacement
![]()
图 13 不同车速时非线性地基及胎路多点接触对路面响应最大幅值的影响
Figure 13. Effects of nonlinear foundation and multi-point contact between tire and road on the maximum amplitude of road response at different speeds
![]()
图 14 不同车速时非线性地基及胎路多点接触对路面响应的频域曲线
Figure 14. Frequency domain curves of the effects of non-linear foundation and multi-point contact between tire and road on the road response at different speeds
![]()
图 16 不同行驶速度下路面二次位移的最大幅值
Figure 16. Maximum amplitude of road secondary displacement at different speeds
![]()
图 17 不同车速下非线性地基及多点接触对车辆响应最大幅值的影响
Figure 17. Effects of NF and MP on maximum amplitude of vehicle response at different speeds
![]()
图 18 不同车速下非线性地基及多点接触对车辆响应的最大增幅
Figure 18. Maximum differences of NF and MP on vehicle response at different speeds
![]()
图 19 地基弹性系数对路面响应最大幅值的影响
Figure 19. Effects of foundation elastic coefficient on maximum amplitude of road response
![]()
图 20 地基线性弹性系数对车辆响应最大幅值的影响
Figure 20. Effects of foundation linear elastic coefficient on maximum amplitude of vehicle response
![]()
图 21 地基非线性弹性系数对车辆响应最大幅值影响
Figure 21. Effects of foundation nonlinear elastic coefficient on maximum amplitude of vehicle response
![]()
图 21 地基非线性弹性系数对车辆响应最大幅值影响(续)
Figure 21. Effects of foundation nonlinear elastic coefficient on maximum amplitude of vehicle response (continued)
表 1 线弹性地基梁的固有频率及相邻频率差别
Table 1 Natural frequency and relative differences of adjacent frequencies of linear elastic foundation beam
NM Frequency/Hz Difference/% 1 11.623 0 0 10 11.623 9 0.002 6 20 11.636 8 0.022 0 30 11.692 8 0.075 5 40 11.842 1 0.177 0 50 12.150 9 0.331 6 60 12.693 2 0.529 3 70 13.539 1 0.743 7 80 14.742 5 0.941 6 90 16.335 2 1.096 8 100 18.327 4 1.199 0 110 20.714 3 1.252 0 120 23.483 4 1.266 4 130 26.619 4 1.254 1 140 30.107 8 1.224 8 150 33.935 7 1.186 0 160 38.092 5 1.142 3 170 42.569 7 1.097 180 47.360 2 1.051 9 190 52.458 6 1.008 1 200 57.860 7 0.966 3 210 63.562 8 0.926 7 220 69.562 2 0.889 4 230 75.856 7 0.854 5 240 82.444 4 0.821 7 250 89.323 9 0.791 0 260 96.493 9 0.762 3 270 103.953 4 0.735 5 280 111.701 6 0.710 3 290 119.737 7 0.686 6 300 128.061 3 0.664 4
下载: 导出CSV
表 2 路面响应的最大幅值及相对增量
Table 2 Maximum amplitude of road response and relative difference
B0/m Motor excitation NF LF Difference between NF and LF yr(SP)/m yr(MP)/m difference yr(SP)/m yr(MP)/m difference SP MP 0.02 √ 2.468 6 × 10−4 2.302 2 × 10−4 −6.74% 2.593 3 × 10−4 2.580 6 × 10−4 −0.49% −4.81% −10.79% × 4.205 0 × 10−4 4.199 6 × 10−4 −0.13% 4.426 7 × 10−4 4.430 9 × 10−4 0.09% −5.01% −5.22% difference 41.29% 45.18% − 41.42% 41.76% − − − 0.002 √ 1.976 6 × 10−4 1.957 3 × 10−4 −0.98% 2.069 5 × 10−4 2.066 9 × 10−4 −0.13% −4.49% −5.30% × 3.819 7 × 10−4 3.819 1 × 10−4 −0.02% 3.846 2 × 10−4 3.846 6 × 10−4 0.01% −0.69% −0.71% difference 48.25% 48.75% − 46.19% 46.27% − − −
下载: 导出CSV
-
[1] 《中国公路学报》编辑部. 中国汽车工程学术研究综述﹒2017. 中国公路学报, 2017, 30(6): 1-197 (Editorial Department of China Journal of Highway and Transport. Review on China’s automotive engineering research progress﹒2017. China Journal of Highway and Transport, 2017, 30(6): 1-197 (in Chinese) doi: 10.3969/j.issn.1001-7372.2017.06.001 [2] Zhang XP, Liang YN, Yu EH, et al. Review of electric vehicle policies in China: Content summary and effect analysis. Renewable and Sustainable Energy Reviews, 2016, 70: 698-714
[3] 李勇, 徐兴, 孙晓东等. 轮毂电机驱动技术研究概况及发展综述. 电机与控制应用, 2017, 44(6): 1-7 (Li Yong, Xu Xing, Sun Xiaodong, et al. Review and future development of in-wheel motor drive technology. Electric Machines & Control Application, 2017, 44(6): 1-7 (in Chinese) doi: 10.3969/j.issn.1673-6540.2017.06.001 [4] 金智林, 陈国钰, 赵万忠. 轮毂电机驱动电动汽车的侧翻稳定性分析与控制. 中国机械工程, 2018, 29(15): 1772-1779 (Jin Zhilin, Chen Guoyu, Zhao Wanzhong. Rollover stability and control of in-wheel motor drive electric vehicles. China Mechanical Engineeering, 2018, 29(15): 1772-1779 (in Chinese) doi: 10.3969/j.issn.1004-132X.2018.15.002 [5] 张利鹏, 李亮, 祁炳楠等. 双电机分布式驱动汽车高速稳定性机电耦合控制. 机械工程学报, 2015, 51(16): 29-40 (Zhang Lipeng, Li Liang, Qi Bingnan, et al. High speed stability electromechanical coupling control for dual-motor distributed drive electric vehicle. Journal of Mechanical Engineering, 2015, 51(16): 29-40 (in Chinese) doi: 10.3901/JME.2015.16.029 [6] 平先尧, 李亮, 程硕等. 四轮独立驱动汽车多工况路面附着系数识别研究. 机械工程学报, 2019, 55(22): 80-92 (Ping Xianyao, Li Liang, Cheng Shuo, et al. Tire-road friction coefficient estimators for 4WID electric vehicles on diverse road conditions. Journal of Mechanical Engineering, 2019, 55(22): 80-92 (in Chinese) [7] 张志达, 郑玲, 吴行等. 基于鲁棒自适应UKF的分布式电动汽车状态估计. 中国科学: 技术科学, 2020, 50(11): 1461-1473 (Zhang Zhida, Zheng Ling, Wu Hang, et al. State estimation of distributed electric vehicle based on robust adaptive UKF. Scientia Sinica Technologica, 2020, 50(11): 1461-1473 (in Chinese) doi: 10.1360/SST-2019-0326 [8] Qin YC, He CC, Shao XX, et al. Vibration mitigation for in-wheel switched reluctance motor driven electric vehicle with dynamic vibration absorbing structures. Journal of Sound and Vibration, 2018, 419: 249-267 doi: 10.1016/j.jsv.2018.01.010
[9] Shao XX, Naghdy F, Du HP, et al. Coupling effect between road excitation and an in-wheel switched reluctance motor on vehicle ride comfort and active suspension control. Journal of Sound and Vibration, 2019, 443: 683-702 doi: 10.1016/j.jsv.2018.12.012
[10] Li Z, Zheng L, Ren Y, et al. Multi-objective optimization of active suspension system in electric vehicle with In-Wheel-Motor against the negative electromechanical coupling effects. Mechanical Systems and Signal Processing, 2019, 116: 545-565 doi: 10.1016/j.ymssp.2018.07.001
[11] Younesian D, Hosseinkhani A, Askari H, et al. Elastic and viscoelastic foundations: A review on linear and nonlinear vibration modeling and applications. Nonlinear Dynamics, 2019, 97(1): 853-895 doi: 10.1007/s11071-019-04977-9
[12] Froio D, Rizzi E, Simoes F, et al. Universal analytical solution of the steady-state response of an infinite beam on a Pasternak elastic foundation under moving load. International Journal of Solids and Structures, 2018, 132: 245-263
[13] Esen I. Dynamic response of a functionally graded Timoshenko beam on two-parameter elastic foundations due to a variable velocity moving mass. International Journal of Mechanical Sciences, 2019, 153-154: 21-35 doi: 10.1016/j.ijmecsci.2019.01.033
[14] 李韶华, 路永婕, 任剑莹. 重型汽车-道路三维相互作用动力学研究. 北京: 科学出版社, 2020: 1-10 (Li Shaohua, Lu Yongjie, Ren Jianying. Study on Dynamics of Three Dimensional Interaction Between Heavy Vehicle and Road. Beijing: Science Press, 2020: 1-10 (in Chinese))
[15] Hien TD, Hung ND, Kien NT, et al. The variability of dynamic responses of beams resting on elastic foundation subjected to vehicle with random system parameters. Applied Mathematical Modelling, 2019, 67: 676-687 doi: 10.1016/j.apm.2018.11.018
[16] Krishnanunni CG, Rao BN. Decoupled technique for dynamic response of vehicle-pavement systems. Engineering Structures, 2019, 191: 264-279 doi: 10.1016/j.engstruct.2019.04.042
[17] Li SH, Yang SP. Investigation of the interaction between a vehicle and the road using the second road excitation on the vehicle. Proceedings of the Institution of Mechanical Engineers, Part D: Journal of Automobile Engineering, 2009, 223(7): 855-863 doi: 10.1243/09544070JAUTO1046
[18] Yang SP, Li SH, Lu YJ. Investigation on dynamical interaction between a heavy vehicle and road pavement. Vehicle System Dynamics, 2010, 48(8): 923-944 doi: 10.1080/00423110903243166
[19] 黄晓明, 郑彬双. 沥青路面抗滑性能研究现状与展望. 中国公路学报, 2019, 32(4): 32-49 (Huang Xiaoming, Zheng Binshuang. Research status and progress for skid resistance performance of asphalt pavements. China Journal of Highway and Transport, 2019, 32(4): 32-49 (in Chinese) [20] 孙加亮, 田强, 胡海岩. 多柔体系统动力学建模与优化研究进展. 力学学报, 2019, 51(6): 1565-1586 (Sun Jialiang, Tian Qiang, Hu Haiyan. Advances in dynamic modeling and optimization of flexible multibody systems. Chinese Journal of Theoretical and Applied Mechanics, 2019, 51(6): 1565-1586 (in Chinese) doi: 10.6052/0459-1879-19-212 [21] 刘志浩, 高钦和, 于传强等. 重载轮胎面内欧拉梁模型及耦合振动特性研究. 振动工程学报, 2019, 32(1): 107-119 (Liu Zhihao, Gao Qin, Yu Chuanqiang, et al. Study on the model of euler beam and coupling vibration characteristics of heavy duty tire. Journal of Vibration Engineering, 2019, 32(1): 107-119 (in Chinese) [22] 王立安, 赵建昌, 王作伟. 汽车行驶诱发地表振动的解析研究. 力学学报, 2020, 52(5): 1509-1518 (Wang Li’an, Zhao Jianchang, Wang Zuowei. Analytical study on ground vibration induced by moving vehicle. Chinese Journal of Theoretical and Applied Mechanics, 2020, 52(5): 1509-1518 (in Chinese) doi: 10.6052/0459-1879-20-033 [23] Zhang Y, Zhao HS, Lie ST. A nonlinear multi-spring tire model for dynamic analysis of vehicle-bridge interaction system considering separation and road roughness. Journal of Sound and Vibration, 2018, 4(36): 112-137
[24] Deng L, Cao R, Wang W, et al. A multi-point tire model for studying bridge-vehicle coupled vibration. International Journal of Structural Stability and Dynamics, 2016, 16(8): 1550047 doi: 10.1142/S0219455415500479
[25] Ding H, Li Y, Chen LQ. Nonlinear Vibration of a Beam with Asymmetric Elastic Supports. Nonlinear Dynamics, 2019, 95(2): 2543-2554
[26] Singh SJ, Harsha SP. Nonlinear dynamic analysis of sandwich S-FGM plate resting on Pasternak foundation under thermal environment. European Journal of Mechanics A Solids, 2019, 76: 155-179 doi: 10.1016/j.euromechsol.2019.04.005
[27] Yang SP, Chen LQ, Li SH. Dynamics of Vehicle-road Coupled System. Beijing: Springer jointly published with Science Press, 2015: 80-90.
[28] 冯桂珍, 李韶华, 路永婕. 考虑弹性支撑边界条件的电动汽车-路面系统机电耦合振动特性分析. 中国公路学报, 2020, 33(8): 81-91 (Feng Guizhen, Li Shaohua, Lu Yongjie. Analysis of electromechanical coupling vibration characteristics of electric vehicle-road system considering elastically supported boundary conditions. China Journal of Highway and Transport, 2020, 33(8): 81-91 (in Chinese) [29] 钟银辉, 李以农, 杨超等. 基于主动悬架控制轮边驱动电动车垂向振动研究. 振动与冲击, 2017, 36(11): 242-247 (Zhong Yinhui, Li Yinong, Yang Chao, et al. Vertical vibration of in-wheel motor electric vehicles based on active suspension control. Journal of vibration of shock, 2017, 36(11): 242-247 (in Chinese) [30] 邓学钧, 黄晓明. 路面设计原理与方法. 北京: 人民交通出版社, 2001: 107-142 (Deng Xuejun, Huang Xiaoming. Theory and Method of Road Design. Beijing: China Communications Press, 2001: 107-142 (in Chinese))
[31] Senalp AD, Arikoglu A, Ozkol I. Dynamic response of a finite length Euler-Bernoulli beam on linear and nonlinear viscoelastic foundations to a concentrated moving force. Journal of Mechanical Science and Technology, 2010, 24(10): 1957-1961 doi: 10.1007/s12206-010-0704-x
[32] 张义民, 薛玉春, 贺向东. 基于开关磁阻电机驱动系统的电动汽车振动研究. 汽车工程, 2007, 29(1): 46-49 (Zhang Yimin, Xue Yuchun, He Xiangdong. A research on the vibration of an electric vehicle using switched reluctance motor as drive system. Automotive Engineering, 2007, 29(1): 46-49 (in Chinese) doi: 10.3321/j.issn:1000-680X.2007.01.010 [33] Chen HY, Ding H, Li SH, et al. Convergent term of the galerkin truncation for dynamic response of sandwich beams on nonlinear foundations. Journal of Sound and Vibration, 2020, 483: 115514 doi: 10.1016/j.jsv.2020.115514
