鼻腔加温功能特征及其与气流场关系的研究

苏英锋; 孙秀珍; 刘迎曦; 于申; 王吉喆; 高飞

doi:10.6052/0459-1879-2012-3-20120318

鼻腔加温功能特征及其与气流场关系的研究

苏英锋^1,2,
孙秀珍^1,2,
刘迎曦^1,2,
于申¹,
王吉喆²,
高飞¹

1.
大连理工大学工业装备结构分析国家重点实验室, 工程力学系, 大连 116024
2. 大连医科大学附属第二医院耳鼻咽喉科, 大连 116027

基金项目: 国家自然科学基金(10902022, 10872043, 11072055)和辽宁省自然科学基金(20082157)资助项目.

详细信息

中图分类号: R318. 01
计量
- 文章访问数: 1580
- HTML全文浏览量: 67
- PDF下载量: 658
出版历程
- 收稿日期: 2011-07-17
- 修回日期: 2011-09-07
- 刊出日期: 2012-05-17

NUMERICAL SIMULATION OF INTRANASAL TEMPERATURE FIELD AND ITS RELATIONSHIP WITH THE AIRFLOW DURING INSPIRATION

1.
State Key Laboratory of Structural Analysis for Industrial Equipment, Department of Engineering Mechanicals, Dalian University of Technology, Dalian 116024, China
2. Department of Otorhinalaryngology, The Second Affiliated Hospital of Dalian Medical University, Dalian 116027, China

Funds: The project was supported by the National Natural Science Foundation of China (10902022, 10872043, 11072055) and the Natural Science Foundation of Liaoning Province (20082157)

摘要

摘要: 为研究鼻腔加温功能特征及其与气流场之间的关系, 选用1例健康国人的鼻腔进行CT扫描. 据CT数据对鼻腔气道进行表面三维重建, 运用计算流体动力学方法分析通气量为12L/min时吸气相0.15s, 0.45s, 0.75s的鼻腔气流场与温度场. 结果显示吸气相0.15s, 0.45s, 0.75s鼻腔气流场主要表现为双侧气流量分布不对称, 其中气流主要流经左侧; 双侧均为总鼻道中、下部气流量较多, 嗅裂、中鼻道和下鼻道气流量少. 吸气相0.15s, 0.45s, 0.75s温度场均表现为温度自鼻腔前端至鼻咽部逐渐增高, 其中温度主要上升区域为鼻内孔-下鼻甲前端-中鼻甲前端对应气道, 且在吸气速度和流量增大后, 这一主要加温区域无明显向后延长征象; 双侧鼻腔及单侧鼻腔不同部位气道气流分布差别较大, 但双侧温度场基本对称, 单侧鼻腔不同气道部位温度差值亦较小, 幅度均小于1℃.
- 鼻腔 /
- 计算流体动力学 /
- 温度场 /
- 气流场
Abstract: To explore the characteristic of warming function of nasal cavity and its relationship with the airflow, a three dimensional model throughout human nasal cavity is established based on CT scan data. Then the airflow fields and temperature fields at time points of 0.15s, 0.45s and 0.75s during inspiration at the ventilation volume of 12L/min are simulated using computational fluid dynamics (CFD) method. The detailed results of airflow field and temperature field at the above three time points during inspiration show that the airflow in both sides is asymmetry, and the air passes mainly through the left side. The volumes of the airflow in the middle and ventral medial regions are larger than those in olfactory split, middle and inferior meatuses in both sides. As to the temperature field, the temperature increases gradually from anterior part of nasal cavity till nasopharynx. The main temperature-increase happens characteristically within the anterior nasal segment including the airway among ostium internum and heads of inferior and middle turbinates at the above three time points, while temperature increases slightly after the head of middle turbinate. The length of the main temperature-increase segment of airway does not lengthen obviously as to the increase of the volume of airflow at the above three time points. Not the same as the airflow distribution difference between both nasal cavity or different parts in either side, the temperature fields in both sides are almost symmetry, and the temperature difference between both sides or different parts in either side is less than 1℃.
- nasal cavity /
- computational fluid dynamics (CFD) /
- temperature field /
- airflow field

HTML全文

参考文献(17)

Hornung DE, Leopold DA, Youngentob SL, et al. Airtlow pattern in a human nasal model. Arch Otolaryngol Head Neck Surg, 1987, 113(2): 169-172

Kelly JT, Prasad AK, Wexler AS. Detailed flow patterns in the nasal cavity. Appl Physiol, 2000, 89 (1): 323-337

Subramanian RP, Richardson RB, Morgan KT, et al. Computational fluid dynamics simulations of inspiratory airflow in the human nose and nasopharynx. Inhal Toxicol, 1998, 10(2): 91-120

Martonen TB, Zhang Z, Yue G, et al. 3-D particle transport within the human upper respiratory tract. Aerosol Sci, 2002, 33(8): 1095-1110

Keyhani K, Scherer PW, Mozell MM. A numerical model of nasal odorant transport for the analysis of human olfaction. J Theor Biol, 1997, 186(3): 279-301

孙秀珍, 刘迎曦, 苏英锋等. 鼻腔气道三维重建和气流流场的数值模拟与分析. 临床耳鼻咽喉头颈外科杂志, 2007, 21(23): 1057-1059 (Sun Xiuzhen, Liu Yingxi, Su Yingfeng, et al. The 3-D reconstruction of the nasal airway to model and analyze the airflow. J Clin Otorhinolaryngol Head Neck Surg, 2007, 21(23): 1057-1059 (in Chinese))

孙秀珍, 于申, 刘迎曦等. 鼻腔结构的三维重建与气体流场数值模拟. 生物医学工程学杂志, 2006, 23(6): 1162-1165 (Sun Xiuzhen, Yu Shen, Liu Yingxi, et al. Three dimensional reconstruction of the nasal cavity structure and numerical simulation of airflow. J Biomed Eng, 2006, 23(6): 1162-1165 (in Chinese))

于申, 刘迎曦, 孙秀珍. 湍流尺寸下鼻腔的几何尺寸与鼻腔阻塞系数的关系. 计算力学学报, 2008, 25(4): 459-463 (Yu Shen, Liu Yingxi, Sun Xiuzhen. Correlation of nasal cavity geometry dimensions and nasal obstruction coefficients in turbulence airflow. Chinese Journal of Computational Mechanics, 2008, 25(4): 459-463 (in Chinese))

苏英锋, 孙秀珍, 刘迎曦等. 鼻中隔矫正术或联合下鼻甲骨折外移术对鼻腔模拟气流场及气道结构的影响分析. 中华耳鼻咽喉头颈外科学杂志, 2011, 46(2): 96-100 (Su Yingfeng, Sun Xiuzhen, Liu Yinxi, et al. Effect of nasal septal reconstruction or in combination with fracture of inferior turbinate operation on the airflow field and nasal airway. Chin J Otorhinolaryngol Head Neck Surg, 2011, 46(2): 96-100 (in Chinese))

Lindemann J, Leiacker R, Rettinger G, et al. Nasal mucosal temperature during respiration. Clin Otolaryngol, 2002, 27(3): 135-139

Keck T, Leiacker R, Riechelmann H, et al. Temperature profile in the nasal cavity. Laryngoscope, 2000, 110(4): 651-654

Naftali S, Schroter RC, Shiner RJ, et al. Transport phenomena in the human nasal cavity: a computational model. Annals of Biomedical Engineering, 1998. 26(5): 831-839

Lindemann J, Keck T, Wiesmiller K, et al. A numerical simulation of intranasal air temperature during inspiration. Laryngoscope, 2004, 114(6): 1037-1041

Naftali S, Rosenfeld M, Wolf M, et al. The air-conditioning capacity of the human nose. Annals of Biomedical Engineering, 2005, 33(4): 545-553

王刚, 辛岳芝, 胡松涛. 低气压条件下人体与环境对流和蒸发换热的实验研究. 暖通空调, 2009, 39(2): 5-8 (Wang Gang, Xin Yuezhi, Hu Songtao. Experimental study on convection and evaporation heat transfer between human body and environment under low atmospheric pressure. Heating Ventilating & Air Conditioning, 2009, 39(2): 5-8 (in Chinese))

黄选兆, 汪吉宝, 孔维佳. 实用耳鼻咽喉头颈外科学. 第2版. 北京: 人民卫生出版社, 2010. 50-55 (Huang Xuanzhao, Wang Jizhao, Kong Weijia. Practice of Otorhinolaryngology Head and Neck Surgery. 2nd edn. Beijing: People's Medical Publishing House, 2010. 50-55 (in Chinese))

Ravi P, Subramania M, Regina B, et al. Computational fluid dynamics simulations of inspiratory airflow in the human nose and nasopharynx. Inhal Toxicol, 1998, 10: 473-450
