孤立波与淹没平板相互作用的三维波面和水动力实验研究

王千; 刘桦; 房詠柳; 邵奇

doi:10.6052/0459-1879-19-244

孤立波与淹没平板相互作用的三维波面和水动力实验研究

上海交通大学水动力学教育部重点实验室, 上海 200240

基金项目: 1) 国家自然科学基金(11632012);国家自然科学基金(41861144024);上海交通大学海洋工程国家重点实验室资助项目(GKZD010075)

详细信息

通讯作者:
刘桦

中图分类号: O342
计量
- 文章访问数: 1359
- HTML全文浏览量: 197
- PDF下载量: 105
出版历程
- 收稿日期: 2019-09-01
- 刊出日期: 2019-11-17

AN EXPERIMENTAL STUDY OF 3-D WAVE SURFACE AND HYDRODYNAMIC LOADS FOR INTERACTION BETWEEN SOLITARY WAVE AND SUBMERGED HORIZONTAL PLATE

Key Laboratory of Hydrodynamics (MOE), Shanghai Jiao Tong University, Shanghai 200240, China

摘要

摘要: 在波浪水池中进行了孤立波作用下有限长度和有限宽度淹没平板的三维模型水池实验. 首次应用多目视觉立体重构技术测量局部三维自由表面变形, 该系统的有效测量水平范围为1.7 m$\times $1.6 m. 用4个三分力测力传感器组成水下测力系统, 在不影响波面的情况下测量孤立波对平板的作用力和力矩. 针对波浪不破碎的情况, 选择0.4 m水深和0.16 m波高的来波条件, 平板淹没深度为0.1 m. 实验结果表明, 孤立波经过淹没平板时自由面有明显的三维变形, 导致孤立波波幅的时空变化. 波幅在平板尾缘中心线处达到最大值, 并沿展向逐渐减小. 利用多目视觉立体重构系统得到的波面变化过程与浪高仪给出定点波面时间序列相互印证, 表明建立标识码波面测量方法是有效的. 孤立波对淹没平板作用的水动力载荷变化分为6个典型阶段, 并与利用波面三维重构得到的波面测量标识码并讨论. 基于多目视觉立体重构技术得到了垂向力和俯仰力矩极值点出现时的三维波面形态. 建立的多目视觉立体重构系统将为海洋工程结构物的水池物理模型实验提供新的波面测量手段.
- 物理实验 /
- 孤立波 /
- 淹没平板 /
- 波面重构 /
- 波浪载荷
Abstract: An experiment of interaction between a solitary wave and a submerged plate with finite length and finite width is conducted in a wave basin. A new system of the multi-lens stereo reconstruction is proposed to measure the local deformation of the free surface in the horizontal area of 1.7 m$\times $1.6 m in the experiment. A set of underwater force measuring system consisted of four force balances is designed to obtain the wave loads on the submerged plate, without the interference on the surface elevation measurement. A solitary wave is generated in a wave basin of uniform water depth. The wave amplitude is 0.16 m and the still water depth is 0.4 m. The submerged depth of the horizontal plate is 0.1 m. No wave breaking occurs during the wave propagation. The three-dimensional deformations of the free surface elevation lead to the spatial and temporal variation of the solitary wave amplitude. It is found that, for the case of the present wave condition and the submerged plate, the surface elevation reaches the highest at the centerline of the plate near its trailing edge, and decreases along the span direction. The time series of the surface elevation measured by the multi-lens stereo reconstruction method agree well with the wave elevations measured by the wave gauges, which validates the new wave surface measurement system. The loading processes of the horizontal force, vertical force and the pitch moment are proposed as 6 typical phases in which the characteristics of the measured wave surface elevation are discussed. The wave surfaces measured by the multi-lens stereo reconstruction method are given at the corresponding time as the peaks of the vertical force and the pitch moment occurs. The multi-lens stereo reconstruction method could be used to measure the wave field for physical model experiments in a wave basin as a new tool.
- physical experiment /
- solitary wave /
- submerged plate /
- stereo reconstruction /
- wave load

HTML全文

参考文献(1)

1	Yu X . Functional performance of a submerged and essentially horizontal plate for offshore wave control: A review. Coastal Engineering Journal, 2002,44(2):127-147
2	Zhao X, Wang BL, Liu H . Characteristics of tsunami motion and energy budget during runup and rundown processes over a plane beach. Physics of Fluids, 2012,24:062107
3	Li ZS, Zhao X, An C , et al. Wave profiles of a virtual extreme tsunami in the northern region of South China Sea. Journal of Earthquake and Tsunami, 2018,12(2):1840004
4	Hsiao SC, Lin TC . Tsunami-like solitary waves impinging and overtopping an impermeable seawall: Experiment and RANS modeling. Coastal Engineering, 2010,57(1):1-18
5	Zhao X, Liu H, Wang BL . Tsunami waveforms and runup of undular bores in coastal water. Journal of Engineering Mechanics, ASCE, 2016,142(7):06016003
6	Hayatdavoodi M, Ertekin RC . Review of wave loads on coastal bridge decks. Applied Mechanics Reviews, 2016,68(3):030802
7	French JA . Wave uplift pressures on horizontal platforms. [PhD Thesis]. Pasadena, USA: California Institute of Technology, 1970
8	Lo HY, Liu PLF . Solitary waves incident on a submerged horizontal plate. Journal of Waterway, Port, Coastal, and Ocean Engineering, 2013,140(3):04014009
9	Hayatdavoodi M, Seiffert B, Ertekin RC . Experiments and computations of solitary-wave forces on a coastal-bridge deck. Part II: Deck with girders. Coastal Engineering, 2014,88:210-228
10	Poupardin A, Perret G, Pinon G , et al. Vortex kinematic around a submerged plate under water waves. Part I: Experimental analysis. European Journal of Mechanics B/Fluids, 2012,34:47-55
11	Dong J. Dong J, Wang BL , et al. Wave forces on a submerged horizontal plate over a sloping beach due to a solitary wave. Proc. of the 12th PACOMS, Australia, 2016
12	耿添, 刘桦 . 孤立波对浸没平板作用的二维边界元数值分析. 水动力学研究与进展, 2019,34(3):275-282
12	( Geng Tian, Liu Hua . Numerical analysis of hydrodynamic loads on submerged plate in solitary wave with 2-D boundary integral element method. Chinese Journal of Hydrodynamics, 2019,34(3):275-282 (in Chinese))
13	Bechle AJ, Wu CH . Virtual wave gauges based upon stereo imaging for measuring surface wave characteristics. Coastal Engineering, 2011,58(4):305-316
14	Zhang Z . A flexible new technique for camera calibration. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2000,22(11):1330-1334
15	Holman R, Haller MC . Remote sensing of the nearshore. Annual Review of Marine Science, 2013,5:95-113
16	Chatellier L, Jarny S, Gibouin F , et al. A parametric PIV/DIC method for the measurement of free surface flows. Experiments in Fluids, 2013,54(3):1488
17	Przadka A, Cabane B, Pagneux V , et al. Fourier transform profilometry for water waves: How to achieve clean water attenuation with diffusive reflection at the water surface? Experiments in Fluids, 2012,52(2):519-527
18	Watanabe Y, Mitobe Y, Oshima K . An imaging technique for measuring wave surface shapes. Coastal Engineering Journal, 2011,53(04):549-565
19	Holland KT, Holman RA, Lippmann TC , et al. Practical use of video imagery in nearshore oceanographic field studies. IEEE Journal of Oceanic Engineering, 1997,22(1):81-92
20	De Vries S, Hill DF, De Schipper MA , et al. Remote sensing of surf zone waves using stereo imaging. Coastal Engineering, 2011,58(3):239-250
21	Benetazzo A . Measurements of short water waves using stereo matched image sequences. Coastal Engineering, 2006,53(12):1013-1032
22	Astruc D, Cazin S, Cid E , et al. A stereoscopic method for rapid monitoring of the spatio-temporal evolution of the sand-bed elevation in the swash zone. Coastal Engineering, 2012,60:11-20
23	Wang Q, Fang YL, Liu H . Multi-lens stereo reconstruction of water waves in a basin. Journal of Hydrodynamics, 2019, accepted.
24	Malek-Mohammadi S, Testik FY . New methodology for laboratory generation of solitary waves. Journal of Waterway, Port, Coastal, and Ocean Engineering, 2010,136(5):286-294
25	Xuan RT, Wu W, Liu H . An experimental study on runup of two solitary waves on plane beaches. Journal of Hydrodynamics, 2013,25(2):317-320
26	Wang Q, Fang YL, Liu H . Physical generation of tsunami waves in offshore region. Journal of Earthquake and Tsunami, 2018,12(2):1840003
27	刘利琴, 郭颖, 赵海祥等. 浮式垂直轴风机的动力学建模、仿真与实验研究. 力学学报, 2017,49(2):299-307
27	( Liu Liqin, Guo Ying, Zhao Haixiang , et al. Dynamic modeling, simulation and model tests research on the floating VAWT. Chinese Journal of Theoretical and Applied Mechanics, 2017,49(2):299-307 (in Chinese))
28	李翔, 张崇伟, 宁德志等. 非周期波浪与直墙作用的非线性数值研究. 力学学报, 2017,49(5):1042-1049
28	( Li Xiang, Zhang Chongwei, Ning Dezhi , et al. Nonlinear numerical study of non-periodic waves acting on a vertical cliff. Chinese Journal of Theoretical and Applied Mechanics, 2017,49(5):1042-1049 (in Chinese))
29	Ren Z, Zhao X, Liu H . Numerical study of the landslide tsunami in the South China Sea using Herschel-Bulkley rheological theory. Physics of Fluids, 2019,31:056601
30	Dong J, Wang BL, Zhao X , et al. Wave forces exerted on a submerged horizontal plate over an uneven bottom. Journal of Engineering Mechanics, ASCE, 2018,144(6):04018030
