沟槽面湍流边界层减阻的TRPIV测量

李山; 杨绍琼; 姜楠

doi:10.6052/0459-1879-12-262

沟槽面湍流边界层减阻的TRPIV测量

李山¹,
杨绍琼¹,
姜楠^1,2,3, ,

1.
天津大学力学系,天津300072
2. 天津市现代工程力学重点实验室,天津300072
3. 中国科学院力学研究所非线性力学国家重点实验室,北京100190

基金项目: 国家自然科学基金(11272233),国家重点基础研究发展计划(2012CB720101)和中国科学院力学研究所非线性力学国家重点实验室开放基金资助项目.

详细信息

通讯作者:
姜楠,教授,主要研究方向:湍流、流动稳定性、实验流体力学.E-mail:nanj@tju.edu.cn

中图分类号: O357.5
计量
- 文章访问数: 2236
- HTML全文浏览量: 107
- PDF下载量: 888
出版历程
- 收稿日期: 2012-09-27
- 修回日期: 2012-11-21
- 刊出日期: 2013-03-17

TRPIV MEASUREMENT OF DRAG-REDUCTION IN THE TURBULENT BOUNDARY LAYER OVER RIBLETS PLATE

1.
Department of Mechanics of Tianjin University, Tianjin 300072, China
2. Tianjin Key Laboratory of Modern Engineering Mechanics, Tianjin 300072, China
3. State Key Laboratory of Nonlinear Mechanics, Institute of Mechanics, CAS, Beijing 100190, China

Funds: The project was supported by the National Natural Science Foundation of China (11272233), the National Fundamental Research Program of China (2012CB720101) and Opening Fund of the State Key Laboratory of Nonlinear Mechanics (LNM), Institute of Mechanics, Chinese Academy of Sciences.

摘要

摘要: 采用高时间分辨率粒子图像测速技术对沟槽壁面平板湍流边界层速度矢量场的时间序列及其统计量进行了实验测量,讨论了在同一来流速度下沟槽壁面对平均速度剖面﹑雷诺切应力及湍流强度的影响. 用流向速度分量的多尺度空间局部平均结构函数辨识壁湍流多尺度相干结构,用条件采样和相位平均技术提取壁湍流多尺度相干结构喷射和扫掠事件的脉动速度、展向涡量的二维空间拓扑形态. 结果表明,与同材料光滑壁面对比,沟槽壁面实现了10.73%的摩阻减小量;沟槽壁面湍流边界层湍流强度及雷诺切应力皆比光滑平板湍流边界层对应统计量小,说明沟槽壁面有效降低了湍流边界层内流体的脉动. 通过比较壁湍流相干结构猝发事件各脉动速度分量与展向涡量的空间分布特征,肯定了沟槽壁面的减阻效果,发现沟槽壁面通过抑制相干结构猝发事件实现减阻.
- 湍流边界层 /
- 沟槽壁面 /
- 减阻 /
- 相干结构 /
- 多尺度空间局部平均结构函数 /
- 高时间分辨率粒子图像测速
Abstract: Time series of velocity vector field and statistics in the turbulent boundary layer(TBL) over the riblets surface and smooth one were measured utilizing the time-resolved particle image velocimetry (TRPIV); Several characteristic parameters in the TBL, such as the mean velocity profile, the Reynolds shear stress and the turbulent intensity, etc. were compared at the same free-stream velocity(0.19m/s) for the different surface plates. We firstly detected the coherent structures using multi-scale spatial locally-averaged structure function of the streamwise velocity component at different scales. Then, we utilized the conditional sampling and phase-average method to extract the spatial topologies of physical quantities, such as the velocity fluctuation and the spanwise vorticity, etc. based on the ejection or sweep events of coherent structures in the TBL. Results reveal that a drag-reduction of nearly 10.73 percent was acquired over the riblets surface when we compared the skin friction coe cient of such two Acrylic Plexiglas plates at the same free-stream velocity. In addition, that the streamwise turbulent intensity and the Reynolds shear stress of the TBL over riblets surface are both smaller than the ones over smooth surface at the same wall-normal position indicates riblets surface weaken the flow turbulence reducing the momentum exchange and energy loss in the flow. Lastly, we compared several statistic characteristics, mentioned above, based on the ejection and sweep events of coherent structures to clarify the effect of the drag-reduction over the riblets surface with triangle cross-section. More importantly, we find that the drag-reduction achieved by means of riblets surface suppressing the bursting events of coherent structures.
- turbulent boundary layer /
- riblets plate /
- drag reduction /
- coherent structure /
- multi-scale spatial locally-averaged structure function /
- TRPIV

HTML全文

参考文献(25)

Walsh MJ. Riblets as a viscous drag reduction technique. AIAA. Journal, 1983, 21(4): 485-486

Walsh MJ. Turbulent boundary layer drag reduction using riblets. AIAA-82-0169, 1982

Walsh MJ, Lindemann AM. Optimization and application of riblets for turbulent drag reduction. AIAA-84-0347, 1984

Brian D, Bharat B.湍流流动中鲨鱼皮表面流体减阻研究进展.力学进展, 2012, 42(6): 821-836 (Brian Dean, Bharat Bhushan. Shark-skin surfaces for fluid-drag reduction in turbulent flow: A review. Advances in Mechanics, 2012, 42(6): 821-836 (in Chinese))

Bacher EV, Smith CR. A combined visualization anemometry study of the turbulent drag reducing mechanisms of triangular micro-groove surface modification. AIAA 85-0548,1985

Gallagher JA, Thomas ASW. Turbulent boundary layer characteristics over streamwise grooves. AIAA 84-2185, 1984

Park SR, Wallace JM. Flow alteration and drag reduction by riblets in a turbulent boundary layer. AIAA Journal, 1994, 32(1): 31-38

Bechert DW, Bruse M, Hage W, et al. Experiments on drag-reducing surfaces and their optimization with an adjustable geometry. Journal of Fluid Mechanics, 1997, 338: 59-87

胡海豹, 宋保维, 潘光等. 回转体表面条纹沟槽减阻水洞实验研究. 力学季刊, 2006, 27(002): 267-272 (Hu Haibao, Song Baowei, Pan Guang, et al. Water tunnel experimental investigation on drag reduction in gyroidal objects with riblets surface. Chinese Quarterly of Mechanics, 2006, 27(002): 267-272 (in Chinese))

王晋军, 兰世隆. 沟槽面湍流边界层减阻特性研究.中国造船, 2001, 42(4): 1-5 (Wang Jinjun, Lan Shilong. Drag reduction characteristics of turbulent boundary layer flow over riblets surfaces. Shipbuilding of China, 2001, 42(4): 1-5 (in Chinese))

李新华, 董守平, 赵志勇. 平板及减阻沟槽表面雷诺切应力的实验研究. 实验流体力学, 2006, 20(1): 40-44 (Li Xinhua, Dong Shouping, Zhao Zhiyong. Experimental study on Reynolds shear stress in turbulent boundary layers over smooth and drag reduction grooved surface. Journal of Experiment in Fluid Mechanics, 2006, 20(1): 40-44 (in Chinese))

宫武旗, 李新宏, 黄淑娟. 沟槽壁面减阻机理实验研究.工程热物理学报, 2002, 23(5): 579-582 (Gong Wuqi, Li Xinhong, Huang Shujuan. Experiment sturdy on the mechanism of riblets drag reduction. Journal of Engineering Thermo Physics, 2002, 23(5): 579-582 (in Chinese))

李育斌, 乔志德, 王志岐. 运七飞机外表面沟纹膜减阻的实验研究.气动实验与测量控制, 1995, 9(3): 21-26 (Li Yubin, Qiao Zhide, Wang Zhiqi. An experimental research of drag reduction using riblets for the Y-7 airplane. Aerodynamic Experiment and Measurement {& Control, 1995, 9(3): 21-26 (in Chinese))

潘家正. 湍流减阻新概念的实验检索. 空气动力学学报, 1996, 14(3): 305-310 (Pan Jiazheng. The experimental approach to drag reduction of the transverse ribbons on turbulent flow. Acta Aerodynamica Sinica,1996, 14(3): 305-310 (in Chinese))

王晋军. 沟槽面湍流边界层减阻研究综述.北京航空航天大学学报1998, 24(1): 31-34 (Wang Jinjun. Reviews and prospects in turbulent drag reduction over riblets surface. Journal of Beijing University of Aeronautics and Astronautics, 1998, 24(1): 31-34 (in Chinese))

Nitschke P. Experimental investigation of turbulent flow in smooth and longitudinal grooved tubes. NASA TM, 1984: 77480

Tang YP, Clark DG. On near-wall turbulence-generating events in a turbulent boundary layer on a riblet surface. Applied Scientific Research, 1993, 50: 215-232

Wang JJ, Lan SL, Chen G. Experimental study on the turbulent boundary layer flow over riblets surface. Fluid Dynamics Research, 2000, 27: 217-229

Choi KS. Near-wall structure of a turbulent boundary layer with riblets. Journal of Fluid Mechanics, 1989, 208: 417-458

Hooshmand D, Youngs RA, Wallace JM, et a1. An experimental study of changes in the structure of a turbulent boundary layer due to surface geometry changes. AIAA 83-0230,1983

Debisschop JR, Nieuwstadt FTM. Turbulent boundary layer in an adverse pressure gradient: effectiveness of riblets. AIAA Journal, 1996, 34: 932-937

Zhao ZY, Dong SP, Du YN. An experimental study of the turbulent boundary layer characteristic over streamwise riblets. Journal of Hydrodynamics, 2004, 16(3): 350-355

姜楠, 管新蕾, 于培宁. 雷诺应力各向异性涡黏模型的层析TRPIV测量. 力学学报, 2012, 44(2): 1037-1042 (Jiang Nan, Guan Xinlei, Yu Peining. Tomographic TRPIV measurement of anisotropic eddy-viscosity model for coherent structure Reynolds Stress. Chinese Journal of Theoretical and Applied Mechanics, 2012, 44(2): 1037-1042 (in Chinese))

Yang SQ, Jiang N. Tomographic TR-PIV measurement of coherent structure spatial topology utilizing an improved quadrant splitting method. Sci China-Phy Mech Astron, 2012, 55: 1863-1872

姜楠, 于培宁, 管新蕾. 湍流边界层相干结构空间拓扑形态的层析TRPIV测量. 航空动力学报, 2012, 27(5): 1113-1121 (Jiang Nan, Yu Peining, Guan Xinlei. Tomo-TRPIV measurement of coherent structure spatial topology in turbulent boundary layer. Journal of Aerospace Power, 2012, 27(5): 1113-1121 (in Chinese))
