爆炸冲击载荷作用下流固耦合数值模拟

郭攀; 刘君; 武文华

doi:10.6052/0459-1879-12-118

爆炸冲击载荷作用下流固耦合数值模拟

郭攀¹,
刘君²,
武文华^1, ,

1.
大连理工大学运载工程与力学学部工程力学系,工业装备结构分析国家重点实验室,大连116024
2. 大连理工大学运载工程与力学学部航空航天学院,工业装备结构分析国家重点实验室,大连116024

基金项目: 国家重点基础发展规划(2011CB013705),国家重大专项(2011ZX05026-02)和创新研究群体研究基金(50921001)资助项目.

详细信息

通讯作者:
武文华,副教授,主要研究方向:计算力学.E-mail:lxyuhua@dlut.edu.cn

中图分类号: TK121
计量
- 文章访问数: 2402
- HTML全文浏览量: 77
- PDF下载量: 1356
出版历程
- 收稿日期: 2012-05-02
- 修回日期: 2012-12-05
- 刊出日期: 2013-03-17

NUMERICAL MODELING FOR FLUID-STRUCTURE INTERACTION UNDER BLAST AND IMPACT LOADING RESPONSE

1.
The State Key Laboratory for Structural Analysis of Industrial Equipment, Department of Engineering Mechanics, Faculty of Vehicle Engineering and Mechanics, Dalian University of Technology, Dalian 116024, China
2. The State Key Laboratory for Structural Analysis of Industrial Equipment, School of Aeronautics and Astronautics, Faculty of Vehicle Engineering and Mechanics, Dalian University of Technology, Dalian 116024, China

Funds: The project was supported by the National Basic Research Program of China (973 Program) (2011CB013705), National Science and Technology Major Project of the Ministry of Science and Technology of China (2011ZX05026-002-02) and Innovation Research Group Research Fund (50921001).

摘要

摘要: 建立了基于位移相等条件的流固耦合数值模拟程序框架,通过串联弱耦合方式对爆炸冲击波作用下流固耦合效应进行数值模拟. 其中非线性固体位移场采用基于Lagrange方法描述的时域间断伽辽金有限元方法进行处理. 基于修正弹簧近似的非结构动网格新技术,非定常流场采用格心格式的有限体积方法进行求解. 数值模拟结果表明: 该文所发展的弱耦合分析程序在流固耦合数值模拟过程中具有可靠的计算精度. 同时,程序对于爆炸强间断气动冲击载荷冲击作用下固体变形引起流场的反射和叠加效应, 以及流场变化引起复杂的固体响应具有良好的耦合求解能力.
- 时域间断伽辽金有限元法 /
- 爆炸冲击波 /
- 有限体积法 /
- 非结构动网格
Abstract: In this paper, a framework for numerical modeling of fluid and structure interaction (FSI) under blast shock wave has been developed and implement by loose coupling method on the basis of the equivalence of displacement condition. The nonlinear displacement of solid field is simulated by Discontinuous Galerkin Finite Element Method (DGFEM) which is based on the Lagrange method. The flow field is computed by using the cell-centered finite-volume scheme on the assumption of the improved spring analogy. Compared to the analytical results of one-dimensional spring piston problem, the present loose coupling method shows the good performance in computational accuracy in simulating fluid-structure interaction problem. Furthermore, the program framework exhibits the good abilities in simulating the coupling interacting behavior of the reflection and superposition of flow field due to the complex solid deformations.
- time discontinuous galerkin finite element method (DGFEM) /
- blast wave /
- finite volume method /
- unstructured dynamic mesh

HTML全文

参考文献(7)

Taylor GI. The pressure and impulse of submarine explosion waves on plates. Aerodynamics and the mechanics of projectiles and explosions. In: The Scientific Papers of Sir Geoffrey Ingram Taylor, vol. III. Cambridge: Cambridge University Press, 1963. 287-303

Rabczuk T, Samaniego E, Belytschko T. Simplified model for predicting impulsive loads on submerged structures to account for fluid-structure interaction. International Journal of Impact Engineering, 2007, 34: 163-177

Subramaniam KV, Nian WM, Andreopoulos Y. Blast response simulation of an elastic structure: Evaluation of the fluid--structure interaction effect. International Journal of Impact Engineering, 2009, 36: 965-974

钱若军,董石麟,袁行飞.流固耦合理论研究进展. 空间结构, 2008,14: 1-13 (Qian Ruojun, Dong Shilin, Yuan Xingfei. Advances in research on fluid-structure interaction theory. Spatial Structure, 2008, 14: 1-13 (in Chinese))

王彬,杨庆山.弱耦合算法的实现及其应用. 工程力学, 2008, 25(12): 48-52 (Wang Bin, Yang Qingshan. The realization and application of loosely coupled algorithm. Engineering Mechanics, 2008, 25(12): 48-52 (in Chinese))

刘君, 白晓征,郭正. 非结构动网格计算方法.长沙:国防科技大学出版社, 2009 (Liu Jun, Bai Xiaozheng, Guo Zheng. Dynamic Unstructured Grid Method. Changsha: National University of Defence Technology Press, 2009 (in Chinese))

Li XK, Yao DM, Lewis RW. A discontinuous Galerkin finite element method for dynamic and wave propagation problems in non-linear solids and saturated porous media. Int J Numer Meth Eng, 2003, 57(3): 1775-1800
